2015 OPEL KARL Owners Manual

OPEL Karl Owner Manual (GMK-Localizing-EU RHD-9231168) - 2016 - crc -
5/7/15
8 In Brief
Exterior Mirrors
Select the relevant exterior mirror
and adjust it.
Convex exterior mirrors
0Power
Mirrors 027.
Steering Wheel
Adjustment
Unlock the lever, adjust the steering
wheel, then engage the lever and
ensure it is fully locked.
Do not adjust the steering wheel
unless the vehicle is stationary and
the steering wheel lock has been
released.
Airbag system
0Airbag
System 038,
Ignition positions
0Ignition
Positions 0135.

OPEL Karl Owner Manual (GMK-Localizing-EU RHD-9231168) - 2016 - crc -
5/7/15
In Brief 9
Instrument Panel Overview

OPEL Karl Owner Manual (GMK-Localizing-EU RHD-9231168) - 2016 - crc -
5/7/15
10 In Brief
1. Power windows on pagePower
Windows 029.
Central locking system on page
Central Locking System 022.
2. Exterior mirrors on page Convex Mirrors 027.
3. Cruise control, Speed limiter on page Driver Assistance
Systems 0148.
Heated steering wheel on page
Heated Steering Wheel 060.
4. Turn and lane-change signals, headlight flash, dipped beam
and main beam on page
Indicator and Lane-Change
Signals 087.
Exit lighting on page Exit
Lighting 091.
Parking lights on page Parking
Lights 088.
5. Side air vents on page Fixed
Air Vents 0132.
6. Instruments on page Steering
Wheel Adjustment 060. 7. Driver Information Centre on
page Driver Information Centre
(DIC) 075.
8. Steering wheel controls on page Steering Wheel
Controls 060.
9. Windscreen wiper, Windscreen washer system, rear wiper, rear
washer system on page
Windscreen Wiper/
Washer 061.
10. Centre air vents on page Adjustable Air Vents 0131.
11. Hazard warning lights on page Hazard Warning Flashers 087.
12. Info-Display on page Overview 093.
13. Infotainment system on page Operation 099.
14. Glove box on page Glove
Box 053.
15. Climate control system on page Electronic Climate
Control System 0128.
16. Selector lever, manual gearbox on page Manual
Gearbox 0141. 17. Parking brake on page
Handbrake 0142.
18. Ignition switch with steering wheel lock on page Ignition
Positions 0135.
19. Horn on page Horn061.
Driver airbag on page Airbag
System 038.
20. Steering wheel adjustment on page Steering Wheel
Adjustment 060.
21. Bonnet release lever on page Bonnet 0157.
22. Fuse box on page Fuses 0169.
23. Traction control system on page Traction Control System
(TCS) 0143.
Automatic engine start/stop on
page Automatic Engine Start/
Stop Feature 0137.
City mode on page Electronic
Stability Control (ESC) 0144.
Lane departure warning on
page Lane Departure Warning
(LDW) 0150.

OPEL Karl Owner Manual (GMK-Localizing-EU RHD-9231168) - 2016 - crc -
5/7/15
In Brief 11
24. Light switch,Headlight range adjustment,
Front fog lights,
Rear fog light,
Instrument illumination on page
Exterior Lamp Controls 085.

OPEL Karl Owner Manual (GMK-Localizing-EU RHD-9231168) - 2016 - crc -
5/7/15
12 In Brief

OPEL Karl Owner Manual (GMK-Localizing-EU RHD-9231168) - 2016 - crc -
5/7/15
In Brief 13
1. Infotainment system on pageOperation 099.
2. Info-Display on page Overview 093.
3. Hazard warning lights on page Hazard Warning Flashers 087.
4. Centre air vents on page Adjustable Air Vents 0131.
5. Turn and lane-change signals, headlight flash, dipped beam
and main beam on page
Indicator and Lane-Change
Signals 087.
Exit lighting on page Exit
Lighting 091.
Parking lights on page Parking
Lights 088.
6. Instruments on page Steering
Wheel Adjustment 060.
7. Driver Information Centre on page Driver Information Centre
(DIC) 075.
8. Cruise control, Speed limiter on page Driver Assistance
Systems 0148. Heated steering wheel on page
Heated Steering Wheel
060.
9. Windscreen wiper, Windscreen washer system, rear wiper, rear
washer system on page
Windscreen Wiper/
Washer 061.
10. Side air vents on page Fixed
Air Vents 0132.
11. Steering wheel controls on page Steering Wheel
Controls 060.
12. Exterior mirrors on page Convex Mirrors 027
13. Power windows on page Power
Windows 029.
Central locking system on page
Central Locking System 022.
14. Light switch, Headlight range adjustment,
Front fog lights,
Rear fog light,
Instrument illumination on page
Exterior Lamp Controls 085. 15. Traction control system on
page Traction Control System
(TCS) 0143.
Automatic engine start/stop on
page Automatic Engine Start/
Stop Feature 0137.
City mode on page Electronic
Stability Control (ESC) 0144.
Lane departure warning on
page Lane Departure Warning
(LDW) 0150.
16. Ignition switch with steering wheel lock on page Ignition
Positions 0135.
17. Fuse box on page Fuses 0169.
18. Bonnet release lever on page Bonnet 0157.
19. Horn on page Horn061.
Driver airbag on page Airbag
System 038.
20. Steering wheel adjustment on page Steering Wheel
Adjustment 060.
21. Parking brake on page Handbrake 0142.

OPEL Karl Owner Manual (GMK-Localizing-EU RHD-9231168) - 2016 - crc -
5/7/15
14 In Brief
22. Selector lever, manual gearboxon page Manual
Gearbox 0141.
23. Climate control system on page Electronic Climate
Control System 0128.
24. Glove box on page Glove
Box 053.
Exterior Lighting
Turn light switch.
9:Lights off
;:Sidelights
5:Dipped beam Fog lights
Press light switch.
#:
Front fog light
s:Rear fog light
Lighting
0Exterior Lamp
Controls 085.
Headlight flash, main beam
and dipped beam
Headlight flash : Pull lever
Main beam : Push lever
Dipped beam : Push or pull lever
Main beam
0Headlamp Main/
Dipped Beam Changer 086.
Turn and lane-change signals
Lever up : Right indicator
Lever down : Left indicator
Turn and lane-change signals
0
Indicator and Lane-Change
Signals 087,
Parking lights
0Parking
Lights 088.

OPEL Karl Owner Manual (GMK-Localizing-EU RHD-9231168) - 2016 - crc -
5/7/15
In Brief 15
Hazard lights
Operated with|.
Hazard warning lights
0Hazard
Warning Flashers 087.
Horn
Pressa.
Windscreen Wiper/
Washer
Windscreen wiper
2 : Fast
1 : Slow
3:Intermittent wiping
O : Off
For a single wipe when the
Windscreen wiper is off, press the
lever down to position 1x.
Windscreen wiper
0Windscreen
Wiper/Washer 061,
