2015 NISSAN SENTRA window

11
12
3
AUTOMATIC CLIMATE CONTROLS (if so equipped)
1 AUTO BUTTON

This mode may be used year-round. Press the AUTO button to turn the system on.
The system will automatically control the inside temperature (automatic \
cooling and/
or dehumidified heating), air flow distribution and fan speed. The A/C automatically
turns on when AUTO is selected.
2 DUAL BUTTON

Press the DUAL button to turn the passenger’s side temperature controls on or off.

When the indicator light is on, the climate control system is providing i\
ndividual
temperature controls for the driver’s and passenger’s side.

When the indicator light is off, the climate control system turns off the\
individual
temperature controls for the passenger side.
3 DRIVER’S SIDE TEMPERATURE CONTROL BUTTONS

Buttons are used to control the driver’s side temperature by pressing up for warmer
air or down for cooler air.
4 PASSENGER’S SIDE TEMPERATURE CONTROL BUTTONS

Buttons are used to control the passenger’s side temperature by pressing up for
warmer air or down for cooler air.
5 FAN SPEED CONTROL BUTTONS

Press - to lower the fan speed and press + to raise the fan speed.
6 DEFROSTING/DEFOGGING FRONT AND SIDE WINDOWS


Press the defroster button to turn the system on. The A/C automatically turns
on when the defroster mode is selected. This feature removes humidity from the air.
To optimally defog the side windows, direct the side vents to the side wi\
ndows.

Press the temperature control buttons
3 or 4 to set the desired temperature.

To quickly defrost ice that has formed on the outside of the windows, press the\

+ fan speed button

5 until you have reached the maximum speed and set the
temperature controls
3 and 4 to the highest temperature setting.
7 MODE BUTTON

Press the MODE button to cycle through the following air flow outlets:

Air flows from the center and side vents.

Air flows from the center, side and foot vents.

Air flows mainly from the foot vents.

Air flows from the defroster and foot vents.
5
4
6
78
9
10
1112
1911994_15c_Sentra_QRG_060815.indd 116/8/15 2:40 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

12
FIRST DRIVE FEATURES
FM/AM/SiriusXM®* SATELLITE RADIO (if so equipped)
WITH CD PLAYER
1 ON•OFF BUTTON/VOL (volume) CONTROL KNOB

Press the ON•OFF button to turn the system on or off.

Turn the VOL (volume) control knob to the right or left to increase or decrease
the volume.
56
3
1
4
2
8 REAR WINDOW AND OUTSIDE MIRROR DEFROSTER BUTTON

Press the rear window defroster button to turn the system on or off.

This function automatically turns off after a period of time.
9 AIR RECIRCULATION BUTTON

Press the air recirculation button to recirculate interior air inside the vehicle.
The indicator light on the button will illuminate. This system is used to avoid certain
outside odors and to help adjust the inside vehicle temperature more eff\
ectively.

The air recirculation mode cannot be activated when the climate control s\
ystem is
in the front defroster mode
or the front defroster and foot vent mode .
10 FRESH AIR INTAKE BUTTON

Press the fresh air intake button to draw outside air into the passenger
compartment. The indicator light on the button will illuminate.
11 A/C BUTTON

Press the A/C button to turn the air conditioner system on or off.
12 ONOFF BUTTON

Press the ONOFF button to turn the system on or off.
For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (section 4) ” of
your Owner’s Manual.
*SiriusXM
® Satellite Radio is only available on vehicles equipped with an optional s\
atellite radio subscription service.
1911994_15c_Sentra_QRG_060815.indd 126/8/15 2:40 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

17
The “Help” command can be used to hear a list
of available commands at any time.

Reduce background noise as much as possible
by closing windows and pointing HVAC vents
away from the ceiling.

Speak naturally without long pauses and without raising your voice.

When speaking phonebook names, please be aware some cellular phones requi\
re the last
name to be spoken before the first name. For example, “Michael Smith” may be spoken as
“Smith Michael”.

If you experience difficulty with the Voice Recognition System recognizing a contact
name, please try saying both the first and last name of the contact as this improves
recognition accuracy.

To cancel a Voice Recognition session, say “Exit” or press and hold the button.

To decrease or increase the volume of the voice prompts, push the volume \
control
switches
or
on the steering wheel or turn the VOL (volume) control knob on the
audio system while the system is responding.

Voice commands can be used to operate various Bluetooth® system features using the
NISSAN Voice Recognition system. See your Owner’s Manual for detailed information.

For more detailed information and instructions, refer to your cellular phone’s Owner’s
Manual and visit www.nissanusa.com/bluetooth.
BLUETOOTH® SYSTEM WITHOUT NAVIGATION ( if so equipped)
CONNECTING PROCEDURE

The vehicle must be stationary when connecting the phone.
1. Press the
button on the steering wheel. The
system announces the available commands.
2. Say: “Add Phone”. The system acknowledges
the command and asks you to initiate connecting
from the phone handset.
3. Initiate connecting from the phone:
• The connecting procedure varies according to
each cellular phone model. For detailed
connecting instructions and a list of compatible phones, please
visit www.nissanusa.com/bluetooth.
• When prompted, confirm that the PIN on the display matches the PIN shown on
your device. If you are requested to manually input a PIN, please enter “1234” from
your handset.
1911994_15c_Sentra_QRG_060815.indd 176/8/15 2:40 PM
