2015 NISSAN PATHFINDER lights

5
TIRE PRESSURE MONITORING SYSTEM (TPMS)WITH EASY FILL TIRE ALERT
A Tire Pressure Low – Add Air warning
message will appear in the vehicle information
display
1 and the low tire pressure warning light
2 will illuminate when one or more tires
are low in pressure and air is needed.
• The tire pressures should be checked when
the tires are cold. The tires are considered cold
after the vehicle has been parked for 3 hours
or more or driven less than 1 mi (1.6 km) at
moderate speeds.

When adding air to an under-inflated tire, the
TPMS with Easy Fill Tire Alert provides visual and
audible signals to help you inflate the tire to the recommended COLD tire pressure.
To use the Easy Fill Tire Alert:
1. Move the shift lever to the P (PARK) position and apply the parking brake.
2. Place the ignition switch in the ON position. Do not start the engine.
3. Add air to the under-inflated tire, and within a few seconds, the haza\
rd warning lights
will start flashing.
4. When the designated tire pressure is reached, the horn will beep once and the
hazard warning lights will stop flashing.
5. Repeat this procedure for any additional under-inflated tires.

After tire pressures are adjusted, drive the vehicle at speeds above 16 \
mph (25 km/h).
The Tire Pressure Low – Add Air warning message and low tire pressure warning
light will extinguish.

When the low tire pressure warning light flashes for approximately 1 minute and then
remains on, the TPMS is not functioning properly. Have the system checked by a
NISSAN dealer.

Tire pressure rises and falls depending on the heat caused by the vehicle\
’s operation
and the outside temperature. Low outside temperature can lower the tempe\
rature of the
air inside the tire, which can cause a lower tire inflation pressure. This may cause the
low tire pressure warning light to illuminate. If the warning light illu\
minates, check the tire
pressure in your tires.
• Check the tire pressure (including the spare tire) often and always prior \
to long
distance trips.

The Tire and Loading Information label contains valuable information. Please refer
to “Technical and consumer information (section 9)” in your Owner’s Manual for the
location of the Tire and Loading Information label.
For more information, refer to the “Instruments and controls (section 2)”, the “Starting and driving (section 5)” and
the “Maintenance and do-it-yourself (section 8)” of your Owner’s Manual.
2
1
ESSE NTIAL I N FOR MATION
1904703_15c_Pathfinder_QRG_031315.indd 53/13/15 12:52 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

8
NISSAN INTELLIGENT KEY® SYSTEM (if so equipped)
The NISSAN Intelligent Key® system allows you to
lock or unlock your vehicle, open your liftgate and
remotely start the engine. It is important to make sure
the Intelligent Key is with you (that is, in your pocket
or purse).
REMOTE ENGINE START* (if so equipped)

The remote start operating range is approximately
200 ft (60 m) from the vehicle. The effective operating range may be shorter if there are
walls or other obstructions between the key and the vehicle.

For the remote start to function, the vehicle must be in P (PARK) with the ignition off
and all doors must be closed and locked. Please see your Owner’s Manual for
additional information.

To start your vehicle remotely:
1. Press the
button 1.
2. Within 5 seconds, press and hold the engine start
button 2 for at
least 2 seconds.

The engine will start, and the parking lights will turn on.

Automatic climate control will begin heating or cooling the vehicle depe\
nding on the last
used mode.

The engine will run for 10 minutes and then turn off.

Repeat steps 1 and 2 to extend the time for an additional 10 minute period.
• After two remote starts, the ignition switch must be cycled before the remote start
can be used again.

To start driving, depress the brake pedal and push the ignition switch
START/STOP button.
LOCKING AND UNLOCKING THE VEHICLE

The lock and unlock operating range of the
Intelligent Key is within 31.5 in (80 cm) from
each request switch.

To lock the vehicle, push either door handle
request switch
3 once or press the button
1 on the Intelligent Key.

To unlock the vehicle, perform one of the following procedures:
• Push either door handle request switch
3 once; the corresponding door will unlock.
Push the door handle request switch again within 30 seconds; all other doors will unlock,
or
• Press the
button 4 on the Intelligent Key to unlock the driver’s side door. Press the button 4 again; all other doors will unlock.
*Laws in some communities may restrict the use of remote starters. Check local regulations before using this feature.
5124
6
FIRST DRIVE FEATURES
3
1904703_15c_Pathfinder_QRG_031315.indd 83/13/15 12:52 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

9
POWER LIFTGATE (if so equipped)
When the liftgate is closed and locked, the liftgate
will open automatically by:
• Pushing the power liftgate switch
1 on the
instrument panel.
• Pushing the liftgate opener switch
2,
the liftgate must be unlocked, or you must
have the Intelligent Key with you
(that is in your pocket or purse).
• Pressing the

button 3 on the NISSAN
Intelligent Key® for more than 1 second.

The power liftgate operation can be turned on or
off by the power liftgate main switch
4 on the
instrument panel.
• When the power liftgate main switch
4 is
pushed to the OFF position, power operation is
not available using the power liftgate switch on
the liftgate
5 or the liftgate opener switch 2.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
14
53
LIFTGATE RELEASE

To open the rear liftgate, press the
button 5 for longer than 1 second.

To close the rear liftgate, press the
button 5 again for longer than 1 second.
PANIC ALARM

The Intelligent Key can also be used to activate the panic alarm by pressing and
holding the button 6 for more than 1 second. Once activated, the panic alarm and
headlights will stay on for a period of time.
INTELLIGENT KEY BATTERY DISCHARGE

If the battery of the Intelligent Key is discharged
or environmental conditions interfere with
the Intelligent Key operation, start the engine
according to the following procedure:
1. Move the shift lever to the P (PARK) position.
2. Firmly apply the foot brake.
3. Touch the ignition switch with the Intelligent
Key, and a chime will sound.
4. Within 10 seconds after the chime sounds, push the ignition switch while depressing
the brake pedal and the engine will start.
For more information, refer to the “Pre-driving checks and adjustments (section 3)”, the “Starting and driving
(section 5)” and the “Maintenance and do-it-yourself (section 8)” of your Owner’s Manual.
2
1904703_15c_Pathfinder_QRG_031315.indd 93/13/15 12:52 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

13
HEADLIGHT CONTROL SWITCH
HEADLIGHT CONTROL

Turn the headlight control switch to the
position
1 to turn on the front parking, tail,
license plate and instrument panel lights. Turn
the switch to the
position 2 to turn on
the headlights.
AUTOLIGHT SYSTEM (if so equipped)

The autolight system will automatically turn the
headlights on when it is dark and off when it
is light. The system will keep the headlights on for a period of time after you tur\
n the
ignition off and all doors are closed.

To activate the autolight system, turn the headlight control switch to the AUTO position
3 then push the ignition switch to ON. To deactivate the autolight system, turn the
headlight control switch to the OFF,
position 1 or position 2.
HIGH BEAM SELECT

Push the headlight control switch forward 4 to select the high beam function. The blue
indicator light
illuminates in the instrument panel. Pull the headlight switch back to
the original position to select the low beam. The blue indicator light extinguishes.

Pull and release the headlight control switch 5 to flash the headlight high beams on
and off.
FOG LIGHT SWITCH

The headlights must be on and the low beams selected for the fog lights to operate.

Turn the switch (inside collar) to the position 6 to turn the fog lights on.

Turn the switch (inside collar) to the OFF position to turn the fog lights off.
LANE CHANGE SIGNAL

Move the lever up or down until the turn signal begins to flash, but t\
he lever does not
latch, to signal a lane change. Hold the lever until the lane change is completed.

Move the lever up or down until the turn signal begins to flash, but t\
he lever does not
latch, and release the lever. The turn signal will automatically flash 3 times.

Choose the appropriate method to signal a lane change based on the road and
traffic conditions.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
3
1
2
4
56
1904703_15c_Pathfinder_QRG_031315.indd 133/13/15 12:52 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

29
HOMELINK® UNIVERSAL TRANSCEIVER (if so equipped)
The HomeLink® Universal Transceiver system can
learn and consolidate the functions of up to 3
different hand-held transmitters, operating items
such as garage doors, property gates, outdoor
and indoor lights or alarm systems.

To program the HomeLink® Universal Transceiver:
• Position the handheld transceiver 1-3 in (26-76
mm) away from the HomeLink surface, keeping
the HomeLink indicator light in view.
• Press and hold the desired HomeLink button and the handheld transmitter \
button
simultaneously until the HomeLink indicator light flashes slowly and then ra\
pidly.
• Both buttons may be released when the indicator light flashes rapidly.

To verify the programing is complete, press and hold the HomeLink button \
and observe
the indicator light:
• A solid, continuous light indicates the programing is complete and the H\
omeLink
button will activate your device.
• A blinking light that turns to a solid, continuous light after 2 seconds\
indicates
additional steps are required to complete the programing.

An additional person may make the remaining steps easier. To complete the
programing process:
• At the receiver of the device that you are programing to the HomeLink bu\
tton, press
and release the learn or smart button (the name may vary by manufacture\
r, but it is
usually located near where the hanging antenna wire is attached to the unit). You have
approximately 30 seconds to initiate the following step.
• Press and hold the programed HomeLink button for 2 seconds and release.

You may have to repeat the previous two steps up to 3 times to complete t\
he
programing process. HomeLink should now activate your device.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual, the HomeLink website at
www.homelink.com or call 1-800-355-3515.
HOMELINK
To watch or control videos on the front display, make sure the vehicle is in the P
(PARK) position and the parking brake is applied.

To reduce driver distraction, the wireless headphones will not operate wh\
ile located in
the front seats and movies will not be shown on the front display while \
the vehicle is in
any drive position.

To access standard DVD controls on the front display while playing a DVD on the rear
display, press the DISC•AUX button on the audio control panel while the vehicle is in
the P (PARK) position and the parking brake is applied.
For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (section 4)” \
of
your Owner’s Manual.
