2015 NISSAN JUKE Quick Reference Guide

7
CLOCK SET/ADJUSTMENT (Type B – if so equipped)
To adjust the time and the appearance of the clock
on the display:
1. Press the
button 1.

2. Touch the “Settings” key.
3. Touch the “System” key.
4. Touch the “Clock” key.

The following settings can be adjusted:
• Time Format: The clock can be set to 12 hours
or 24 hours.
• Date Format: The date can be changed to 1 of
5 different formats.
• Clock Mode: From here, the clock mode
options are:
· Manual: Allows for the option “Set Clock
Manually”. Touch this to begin setting the
clock manually using the “+” or “–” to adjust the hours, minu\
tes, day, and month up
or down.
· Time Zone: Touch the “Time Zone” key

2 to choose from the applicable time
zone list and/or touch the “Daylight Savings Time” key to switch between on and off.
· Auto: Automatically sets the clock to the vehicle’s current location.

Press the BACK button 3 to return to the previous screen.
For more information, refer to the “Heater, air conditioner, audio and phone systems (section 4)” of your Owner’s Manual.
1
2
3
1705381_15a_Juke_QRG_091814.indd 79/18/14 4:46 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

8
FIRST DRIVE FEATURES
NISSAN INTELLIGENT KEY® SYSTE M
The NISSAN Intelligent Key® System allows you to
lock or unlock the vehicle, open your liftgate and start
the engine. It is important to make sure the Intelligent
Key is with you (that is, in your pocket or purse).

The operating range of the Intelligent Key is within
31.5 in (80 cm) from each request switch.

To lock the vehicle, push either door handle request
switch

1, push the liftgate request switch 2 or
press the
button
3 on the key fob.

To unlock the vehicle, perform one of the
following procedures:
• Push any door handle request switch
1 once;

the corresponding door will unlock. Push
the request switch
1 again within 1 minute;

all other doors will unlock, or
• Press the

button
4 on the key fob to
unlock the driver’s side door. Press the

button 4 again; all other doors will unlock.

The Intelligent Key can also be used to activate
the panic alarm by pressing and holding the

button
5 for more than 1 second. Once
activated, the panic alarm and headlights will stay
on for a period of time.
INTELLIGENT KEY BATTERY DISCHARGE

If the battery of the Intelligent Key is discharged
or environmental conditions interfere with the
Intelligent Key operation, start the engine
according to the following procedure:
1. Move the shift lever to the P (PARK) position
(Continuously Variable Transmission) or to the
N (NEUTRAL) position (manual transmission).
2. Firmly apply the foot brake.
3. Touch the ignition switch with the Intelligent
Key, and a chime will sound.
4. Within 10 seconds after the chime sounds,
push the ignition switch while depressing the
brake pedal and the engine will start.
For more information, refer to the “Pre-driving checks and
adjustments (section 3)”, the “Starting and driving (section 5)”
and the “Maintenance and do-it-yourself (section 8)” of your Owner’s Manual.
1
3
4
5
2
1705381_15a_Juke_QRG_091814.indd 89/18/14 4:46 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

9
LIFTGATE RELEASE
It is important to make sure the Intelligent Key is
with you (that is, in your pocket or purse).

To open the liftgate, first unlock the liftgate using
one of the following methods:
• Press the
button 1 on the key fob twice.
• Push the liftgate request switch
2.

Then push the liftgate release switch 3 and pull
the liftgate up.
For more information, refer to the “Pre-driving
checks and adjustments (section 3)”
of your Owner’s Manual.
HEATED SEATS ( if so equipped)
The seats are warmed by built-in heaters. The
switches
1, located on the center console, can

be operated independently of each other.

Push the HI (high) side of the switch for high heat.
Push the LO (low) side of the switch for low heat.

The indicator light on the switch will illuminate when the heater is on.
The indicator light will remain on as long as the switch is on.

To turn off the heater, return the switch to the level position. Be
certain the indicator light turns off.

The heater is controlled by a thermostat, automatically turning the heating element on and off.

When the vehicle’s interior is warmed or before you leave the vehicle, be sure to turn
the switch off.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
1
SEAT ADJUSTMENTS
To slide the seat forward or backward, pull up on
the lever
1 under the front of the seat and slide

forward or backward. Release the lever to lock
the seat in position.

To recline the seatback, pull up on the lever 2
and lean back. To bring the seatback forward, pull
the lever up and lean your body forward. Release the lever to lock the seatback in position.
SEAT LIFTER (driver’s seat only)

To adjust the seat height, pull up or push down on the adjusting lever 3 repeatedly.
For more information, refer to the “Safety — Seats, seat belts and supplemental restraint system (se\
ction 1)” of
your Owner’s Manual.
123
1
23
1705381_15a_Juke_QRG_091814.indd 99/18/14 4:46 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

10
FIRST DRIVE FEATURES
STARTING/STOPPING THE ENGINE
CONTINUOUSLY VARIABLE TRANSMISSION
(if so equipped)

It is important to make sure the NISSAN Intelligent
Key® is with you (that is, in your pocket or purse).

Depress the brake pedal.

Move the shift lever to the P (PARK) position.

Push the ignition switch to start the engine.
MANUAL TRANSMISSION (if so equipped)

Depress the brake pedal.

Move the shift lever to the N ( NEUTRAL) position.

Depress the clutch pedal to the floor while pushing the ignition switch to start the engine.
TURNING THE ENGINE OFF

For a Continuously Variable Transmission, move the shift lever to the P (PARK) position,
apply the parking brake and push the ignition switch.

For a manual transmission, apply the foot brake and place the vehicle in \
1st gear, then
apply the parking brake and push the ignition switch.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
2
1
OUTSIDE MIRROR CONTROL SWITCH
The outside mirror control switch is located on the
left side of the instrument panel.

To select the left or right mirror, move the switch
1.

Adjust each mirror to the desired position using
the control switch
2.

To prevent accidentally moving the mirror, move the
switch
1 to the center (neutral) position.For more information, refer to the “Pre-driving checks and adjustments
(section 3)” of your Owner’s Manual.
1705381_15a_Juke_QRG_091814.indd 109/18/14 4:46 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

11
HEADLIGHT CONTROL SWITCH
HEADLIGHT CONTROL

Turn the headlight control switch to the

position 1 to turn on the front parking, side

marker, tail, license plate and instrument panel
lights. Turn the switch to the
position
2 to

turn on the headlights.
AUTOLIGHT SYSTEM (if so equipped)

The autolight system will automatically turn the headlights on when it is\
dark and off
when it is light. The system will keep the headlights on for a period of time after you tur\
n
the ignition off and all doors are closed.

To activate the autolight system, turn the headlight control switch to the AUTO position

3 then push the ignition switch to ON. To deactivate the autolight system, turn the
headlight control switch to the OFF, position
1 or
position
2.
HIGH BEAM SELECT

Push the headlight control switch forward
4 to

select the high beam function. The blue indicator
light
illuminates in the instrument panel. Pull
the headlight switch back to the original position
to select the low beam. The blue indicator light
will extinguish.

Pull and release the headlight control switch
5
to flash the headlight high beams on and off.
FOG LIGHT SWITCH (if so equipped)

The headlights must be on and the low beams

selected for the fog lights to operate.

Turn the switch (inside collar) to the position

6 to turn the fog lights on.

Turn the switch (inside collar)
to the OFF position

to turn the fog lights off.
LANE CHANGE SIGNAL

Move the lever up or down until the turn signal begins to flash but th\
e lever does not
latch to signal a lane change. Hold the lever until the lane change is completed.

Move the lever up or down until the turn signal begins to flash but th\
e lever does not
latch and release the lever. The turn signal will automatically flash 3 times.

Choose the appropriate method to signal a lane change based on the road and
traffic conditions.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
3
1
2
45
6
1705381_15a_Juke_QRG_091814.indd 119/18/14 4:46 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

12
FIRST DRIVE FEATURES
WINDSHIELD WIPER AND WASHER SWITCH
Move the lever to one of the following positions to operate the windshie\
ld wipers:

1 Mist (MIST) - One sweep operation of the
front wipers.

2 Intermittent (INT) - Wipers operate
intermittently. The intermittent speed can be
adjusted by rotating the control ring
3 to
increase or decrease wiper speed.

4 Low (LO) - Front wipers operate at a
continuous low-speed.

5 High (HI) - Front wipers operate at a
continuous high-speed.

6 Pull the lever toward you to activate the
front washer. The front wipers will operate
several times.
REAR WINDSHIELD WIPER AND WASHER

7 Intermittent (INT) - Rear wiper operates
intermittently.

8 Low (ON) - Rear wiper operates at a
continuous low-speed.

9 Push the lever forward to activate the
rear washer. The rear wiper will operate
several times.
WIPER BLADE REPLACEMENT PROCEDURE
The windshield wipers must be in the service position in order to replace\
the wiper blades.
To move the wiper blades to the service position, follow this procedure:

When the ignition switch is in the ON position or within 60 seconds of placing the
ignition switch to the OFF position, lift the windshield wiper and washer lever up to the
Mist
position 1 two times in less than 0.5 seconds. The windshield wipers will
move to the service position automatically, and the wiper blades can now be replaced.
To move the wiper blades back to the original position:

Lift the windshield wiper and washer lever
up or lower the lever down to operate at any
wiper speed.
For more information, refer to the “Instruments and controls (section
2)” and the “Maintenance and do-it-yourself (section 8)” of your
Owner’s Manual.
69
1
2
4
5
MIST
OFF
INT
LO
HI3
INT
ON7
8
1705381_15a_Juke_QRG_091814.indd 129/18/14 4:46 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

13
AUTOMATIC CLIMATE CONTROLS
(with Integrated Control System) (if so equipped)
1 CLIMATE
BUTTON

Press the CLIMATE button to access the Climate Control Mode.

When in Climate Control Mode, the selected temperature, air flow and au\
tomatic
mode or manual mode are indicated on the display.
2 AUTO BUTTON/TEMPERATURE CONTROL DIAL

The automatic mode can be used year-round. Press the AUTO button to turn the system
on, and the fan speed, air flow distribution and temperature will be a\
utomatically maintained.
Turn the temperature control dial left for cooler air or right for warmer\
air.
3 FAN SPEED CONTROL DIAL

Turn the fan speed control dial to the left to decrease fan speed or to the right to
increase fan speed.
4 AIR FLOW CONTROL BUTTONS

Press the preferred air flow control button to select one of the follo\
wing air flow outlets:
Air flows from the center and side vents.

Air flows from the center, side and foot vents.

Air flows mainly from the foot vents.

Air flows from the defroster and foot vents.
5 DEFROSTING/DEFOGGING FRONT AND SIDE WINDOWS

Press the front window defroster button
to turn the system on. The A/C
automatically turns on when the defroster mode is selected. This feature removes
humidity from the air.

Use the temperature control dial
2 to set the desired temperature.
To set the defroster on high, turn the fan speed control dial 3 to increase the fan
speed to the maximum setting.
6 REAR WINDOW DEFROSTER SWITCH
Push the rear window defroster switch to turn the system on or off.

The rear window defroster automatically turns off after approximately 15 minutes.
32
1
8
9
756
4
1705381_15a_Juke_QRG_091814.indd 139/18/14 4:46 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

14
FIRST DRIVE FEATURES
2
1
3
4
DRIVE MODE (with Integrated Control System) (if so equipped)
1 DRIVE MODE SELECT BUTTON

Press the D-MODE select button 1 to switch the display to the Drive mode. While
in the Drive mode, set-up functions, drive information and ECO information can be
displayed and adjusted.

Your vehicle’s Integrated Control System allows vehicle performance to be adjusted
by selecting from three drive modes: NORMAL, SPORT or ECO.

NORMAL
2 drive mode is recommended for normal, everyday driving.

SPORT
3 drive mode is recommended for an enhanced performance feel. Fuel

economy may be reduced.

ECO
4 drive mode is recommended for maximum fuel economy. Performance may
be reduced.
For more information, refer to the “Instruments and controls (section 2)” , the “Heater, air conditioner, audio and
phone systems (section 4)” and the “Starting and driving (section 5)” of your Owner’s Manual.
7 AIR INTAKE BUTTON

Press the air intake button to change the air circulation from the air recirculation mode
to the outside air circulation mode.

When the air recirculation indicator light illuminates, the flowing air is
recirculated inside the vehicle. This system is used to avoid outside odors and to help
adjust the inside vehicle temperature more effectively.

The air recirculation mode cannot be activated when the climate control s\
ystem is in
the front defroster mode
or the front defroster and foot outlet mode .

When the outside air circulation indicator light
illuminates, the flowing air is

drawn from outside the vehicle.
8 A/C BUTTON

Press the A/C button to manually turn the A/C on or off.
9 OFF BUTTON

Press the OFF button to turn the climate control system off.
For more information, refer to the “Instruments and controls (section 2)” , the “Heater, air conditioner, audio and
phone systems (section 4)” and the “Starting and driving (section 5)” of your Owner’s Manual.
1705381_15a_Juke_QRG_091814.indd 149/18/14 4:46 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
