6
FIRST DRIVE FEATURES
POWER FRONT SEAT ADJUSTMENTS
To slide the seat forward or backward, push the
switch
1 forward or backward.
To adjust the angle of the seatback, push the
switch
2 forward or backward.
SEAT LIFTER (driver’s seat)
To adjust the angle and height of the seat
cushion, push the front or rear end of the switch
1 up or down.
POWER LUMBAR SUPPORT (driver’s seat)
To adjust the lumbar area, push the front or back end of the switch
3.
For more information, refer to the “Safety –– Seats, seat belts and supplemental restraint system (section 1)” of
your Owner’s Manual.
123
2ND ROW SEAT ADJUSTMENTS
To recline the seatback, pull up on the recline
handle
1 and lean back. To bring the seatback
forward, pull the handle up and lean your body
forward. Release the handle to lock the seatback
in position.
TIP UP FOR EASY ENTRY/EXIT OF THE 3
RD ROW
1. Raise the armrest (captain’s chairs) so it is parallel
to the seatback and in the stowed position.
2. Then lift up on the seatback latch
2 located
on the upper corner of the seatback and fold the
seatback forward onto the seat base.
3. Finally, lift up on the lower corner of the seat
base and fold the seat forward.
For more information, refer to the “Safety –– Seats, seat belts
and supplemental restraint system (section 1)” of your
Owner’s Manual.
1
2
1904705_15c_Armada_QRG_072315.indd 67/23/15 8:58 AM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
