2015 MAZDA MODEL CX-5 Smart Start Guide (in English)

2015 M{zd{ cx-5
SMART START GUIDE
1610469_15b_Mazda_CX-5_SSG_021714.indd 12/17/14 11:03 AM

KEYLESS ENTRY SYSTEM
• This system allows you to lock and unlock the
doors by pushing the desired buttons.
CAUTION: RED Key Indicator Light may illuminate if either advance
key or keyless entry key is placed in the cup holder. The key can sometimes
not be detected in the cup holder.
CAUTION:
• Make sure vehicle is OFF and take the keyless entry system key with
you when leaving the vehicle.
• There is no warning beep if the IGN or ACC is ON and the key is taken
out of the vehicle, OR if the key is locked inside the vehicle.
1
Key
Unlock
• Push once
to unlock
driver’s door
or all the doors
(depending on
personalization
setting).
• Push twice
(within three
seconds) to
unlock all doors
and lif tgate.
Panic Alarm
• Push for one
second or more
to activate alarm.
• Push Lock,
Unlock, or Panic
Alarm to turn
alarm of f.
Lock
• Push once to
lock all doors
and lif tgate.
• Push twice
(within five
seconds) for
horn sound
verification
that all doors
are locked.
NOTE: Refer to your Owner’s Manual for additional details about
“Personalization Features”.
1610469_15b_Mazda_CX-5_SSG_021714.indd 12/17/14 11:03 AM

www.MazdaUSA.com
2
Electric Liftgate Opener
Advanced Key
Lock
UnlockPanic Alarm
ADVANCED KEYLESS
ENTRY SYSTEM
• This system allows you to lock
and unlock the doors without
taking the key out.
While Carrying the
Advanced Key…
• Unlock the driver’s door by
pushing the driver’s door request
switch once.
• Unlock all doors (and liftgate)
by pushing the driver’s door request
switch once or twice (depending
on personalization setting, page 8)
OR by pushing the passenger’s
door request switch once.
• Lock all doors (and liftgate) by
pushing any request switch once.
• Open the liftgate by pushing
the electric liftgate opener when
ignition is OFF. With ignition ON,
vehicle must be in Park (A / T) or
have parking brake set (M/ T).
NOTE:
When the liftgate opener switch is
pushed, the liftgate will open slightly. If the
liftgate is not opened within 1.5 seconds, the
liftgate latch locks (you will hear it lock) and
the liftgate cannot be opened or closed from
this slightly raised position. To open/close
the liftgate, push the liftgate opener switch,
open the liftgate within 1.5 seconds, then
close it. The door/liftgate ajar warning light
will be on if the liftgate is not fully closed.
Door Request Switch
Liftgate Request Switch
NOTE: Vehicles equipped with the Advanced Keyless Entry System and the
Keyless Entry System both use the same type of keyless entry transmitter.
However, only vehicles equipped with the Advanced Keyless Entry System allow
you to lock and unlock the doors/liftgate with the door/liftgate request switches
(without taking the key out of your purse or pocket).
Vehicles equipped with the Keyless Entry System do not have request switches
on the doors/liftgate. To lock and unlock the doors/liftgate, the corresponding
transmitter button must be pushed.
1610469_15b_Mazda_CX-5_SSG_021714.indd 22/17/14 11:03 AM

3
ACCELERATED WARM-UP SYSTEM (AWS)
Vehicle Starting:
Your vehicle is equipped with SKYACTIV combustion technology. This
technology includes AWS (Accelerated Warm-up System) for optimal
emission performance during cold starting conditions.
Cold Start (e.g., First start of the day on cold mornings):
Depress the brake (Automatic Trans.) or clutch (Manual Trans.), when the
key indicator light turns green
push the START/STOP button.
What you will notice: On start-up, the engine speed and sound are
higher (1500 RPM) for 30 seconds to 1 minute to quickly bring the catalyst
to efficient operating temperature. The RPM will reduce to idle once the
temperature is achieved. This is normal engine operation under cold
start conditions.
NOTE:
Yo u can drive the vehicle during AWS activation, no need to wait.
Normal Start
(Emission components within optimal temperature range):
Depress the brake (Automatic Trans.) or clutch (Manual Trans.), when the
key indicator light turns green
push the START/STOP button.
Key
STARTING THE ENGINE
While Carrying the Key…
• Start the engine by pushing the START/STOP button, while
pushing the clutch pedal (manual transmission) or the brake pedal
(automatic transmission).
• Shut the engine OFF by placing the vehicle in Park, then push the
S TA R T/ S TO P b u t t o n .
• Activate Accessories (ACC) by pushing the START/STOP button
once without pushing the clutch or brake pedal.
• To turn the ignition to the ON position, push the START/STOP
button twice without pushing the clutch or brake pedal.
The key indicator light
in the instrument cluster will show GREEN
(engine ready to start) when the key is detected and the clutch pedal (M/ T)
or the brake pedal (A / T) is pushed. If the KEY warning light illuminates
RED , or the START/STOP button indicator light flashes AMBER , this
could indicate a problem with the engine starting system and the inability
to start the engine or switch the ignition to ACC or ON. Have your vehicle
inspecte d at an Authorized Mazda Dealer as soon as possible.
1610469_15b_Mazda_CX-5_SSG_021714.indd 32/17/14 11:03 AM

4
www.MazdaUSA.com
Transmitter
Emergency Engine Stop
Pushing and holding the
START/STOP button or repeatedly
pushing the button while the engine
is running will turn the engine OFF.
Use only in case of an emergency.
Emergency Vehicle Entry
If the key cannot be used due to
a malfunction or dead key battery,
use the auxiliary key (below) to
lock or unlock the doors.
Emergency Engine Start
If the engine cannot be started
due to a dead key battery:
1 Push the brake pedal (A / T)
or the clutch pedal (M/ T).
2 While the indicator light
flashes GREEN , touch
the START/STOP button
using the back side of the
transmitter (as shown).
3 After the GREEN indicator
light illuminates constantly,
push the START/STOP
button with your finger
to start the engine.
START/STOP Button
Indicator Light
Auxiliary Key Release
Auxiliary Key
Key (Rear)
1610469_15b_Mazda_CX-5_SSG_021714.indd 42/17/14 11:03 AM

Slide/Tilt Switch
Seat can be moved back
and forth, raised, lowered,
or tilted with this control.Recline Switch
Push forward or backward

to adjust seatback angle.
ELECTRONICALLY OPERATED DRIVER SEAT CONTROLS
(if equipped)
Lumbar Support
Adjustment
To increase firmness ,
push and hold the front
part of the switch. Release
at desired firmness.
To decrease firmness ,
push and hold the rear part
of the switch.
Slide Release Lever
Pull lever up to move seat
backward or forward. Recline Lever
Pull up to adjust seatback angle.
MANUAL SEAT CONTROLS
Height Adjustment Lever
Raise or lower seat height
by repeatedly pulling up or
pushing down on the lever.
5
Seats
NOTE: 8-way power seat shown above. 6-way power seat also available.
1610469_15b_Mazda_CX-5_SSG_021714.indd 52/17/14 11:03 AM

FRONT SEAT WARMER
The driver and front passenger seats can be warmed by pushing the
applicable seat warmer button while the ignition is ON.
Seat temperature increases with the number of illuminated indicator lights
(0-OFF, 1-Low, 2-Mid, 3-High).
www.MazdaUSA.com
6
Seats
Seatback Knob
FOLDING SECOND-ROW SEATS
1 Support the seatback with your hand.
2 Push the rear seatback knob down (red indicator is visible when seat
is in the unlocked position).
3 Bring the seatback forward. Low
High
1610469_15b_Mazda_CX-5_SSG_021714.indd 62/17/14 11:03 AM

Folding Rear Seatbacks Down
OR
Returning rear seats to upright position
1 Raise seatbacks until they lock into position (red indicator is not visible
when seat is in the locked position).
2 Pull on the top of the seatbacks from inside the vehicle to make sure
they are locked.
3 Check that all seat belts are routed properly for passenger use.
Folding Only Center Seat Down
NOTE: 4:2:4 type rear seats shown.
Using remote handle:
1 Check that rear seats are clear
of objects.
2 Open the liftgate and pull
the left and right side remote
handle levers.
Using remote handle:
1 Store center seat
head restraint.
2 Check that rear seats are clear.
3 Open the liftgate and pull only
the smaller of the left side
remote handle levers.
7
Seats
1610469_15b_Mazda_CX-5_SSG_021714.indd 72/17/14 11:03 AM
