2015 LEXUS RX450h fold seats

8911-4. Adjustable components (s eats, mirrors, steering wheel)
Before driving Rear seats
Folding down the rear seatbacks
■ Before folding down the rear seatbacks
Stow all the head restraints and the
rear center seat belt buckle.Seat position adjustment lever
Seatback angle adjustment lever

901-4. Adjustable components (s eats, mirrors, steering wheel)
■ Folding down the rear seatbacks
From inside
Pull the seatback angle adjustment
lever. To return the rear seatbacks to
their original positions, lift them up
until they lock.
From outside
Pull the levers.
Left side lever: Folds down the
left side rear seat
Right side lever: Folds down the
right side and
center rear seatsTo return the rear seatbacks to
their original positions, lift them up
until they lock.
■ Folding down the rear center seatback
Pull the center seatback angle
lever behind the seatback and fold
the seatback down.
To return the rear center seatback
to its original position, lift it up until
it locks.

911-4. Adjustable components (seats, mirrors, steering wheel)
1
Before driving CAUTION■
When folding the rear seatbacks down
Observe the following precautions. Failure to do so may result in death or serious
injury. ●
Do not fold the seatbacks down while driving.●
Do not fold seatbacks down while passenge rs are seated or luggage is placed on
the seats.●
Stop the vehicle on level ground, set the parking brake and shift the shift lever to
P.●
After folding the seatback, lightly move the seat back and forth to lock it in place.●
Do not allow anyone to sit on a folded seatback or in the luggage compartment
while driving.●
Do not allow children to en ter the luggage compartment.■
Seat adjustment ●
To reduce the risk of sliding under the lap belt during a collision, do not recline the
seat more than necessary.
If the seat is too reclined, the lap belt may slide past the hips and apply restraint
forces directly to the abdomen, or yo ur neck may contact the shoulder belt,
increasing the risk of death or seriou s injury in the event of an accident.●
Adjustments should not be made while driving as the seat may unexpectedly
move and cause the driver to lose control of the vehicle.■
After returning the rear seatback to the upright position
Observe the following precautions. Failure to do so may result in death or serious
injury. ●
Make sure the seatback is securely locked by pushing it forward and rearward on
the top.
●
Check that the seat belts are not tw isted or caught in the seatback.

1111-4. Adjustable components (seats, mirrors, steering wheel)
1
Before driving ■
When the mirrors are fogged up
The outside rear view mirrors can be cleared using the mirror defoggers. Turn on
the rear window defogger to turn on the outside rear view mirror defoggers.
(  P. 3 5 8 )■
Automatic adjustment of the mirror angl e (vehicles with driving position mem-
ory)
A desired mirror face angle can be entered to memory and recalled automatically
by the driving position memory. (  P. 9 3 )■
Auto anti-glare function
When the anti-glare inside rear view mirr or is set to automatic mode, the outside
rear view mirrors will activate in conjunction with the anti-glare inside rear view mir-
ror to reduce reflected light. (  P. 1 0 7 )
CAUTION■
When driving the vehicle
Observe the following precautions while driving.
Failing to do so may result in loss of control of the vehicle and cause an accident,
resulting in death or serious injury. ●
Do not adjust the mirrors while driving.●
Do not drive with the mirrors folded.●
Both the driver and passenger side mirrors must be extended and properly
adjusted before driving.■
When a mirror is moving
To avoid personal injury and mirror malfunction, be careful not to get your hand
caught by the moving mirror.■
When the mirror defoggers are operating
Do not touch the rear view mirror surface s, as they can become very hot and burn
you.

868Alphabetical index
Parking assist sensors* .......................248
Parking brake .......................................... 195
Parking lights
Replacing light bulbs........................708
Switch ........................................................ 217
PCS
Function .................................................. 278
Pre-collision braking off
switch ................................................... 279
Warning light ....................................... 734
Personal lights
Switch ......................................................583
Phone*........................................... 429, 552
Power back door ..................................... 75
Power control unit coolant
Capacity ................................................ 804
Checking ...............................................659
Preparing and checking
before winter .................................... 302
Power easy access system................... 95
Power outlet............................................. 601
“POWER” switch.................................... 177
Power windows ........................................ 112
Pre-collision system
Function .................................................. 278
Pre-collision braking off
switch ................................................... 279
Warning light ....................................... 734 Radar cruise control............................ 236
Radiator ......................................................661
Radio* ............................................ 365, 477
Rear seat entert ainment system*
Rear seats
Folding down ......................................... 89
Seat adjustment..................................... 89
Rear turn signal lights
Replacing light bulbs ....................... 708
Wattage .................................................809
Rear view mirror
Compass ................................................622
Inside rear view mirror ..................... 107
Outside rear view mirrors ..............109
Rear view monitor
system* ...................................... 258, 266
Rear window defogger* ....................358
Rear window wiper.............................. 229
Remote Touch*
Replacing
Electronic key battery ..................... 687
Fuses ........................................................ 689
Light bulbs ............................................ 708
Tires...........................................................764
Wireless remote control
battery ................................................. 687
Reporting safety defects for
U.S. owners..........................................840
Reset the maintenance data ..............641
Roof luggage carrier........................... 296P R

869Alphabetical index
Safety Connect* ....................................626
Scuff lights ............................................... 582
Seat belts
Adjusting the seat belt ..................... 100
Automatic locking retractor............ 101
Child restraint system
installation ............................................ 154
Cleaning and maintaining
the seat belts..................................... 638
Emergency locking retractor ........ 101
How to wear your seat belt............. 99
How your child should wear
the seat belt.......................................... 101
Pregnant women,
proper seat belt use........................ 102
Reminder light..................................... 736
Seat belt extender ................................ 101
Seat belt pretensioners.................... 100
Seat heaters............................................ 605
Seat position memory ............................93
Seat ventilators...................................... 605
Seating capacity .....................................301 Seats
Adjustment .................................... 86, 89
Adjustment precautions ............ 88, 91
Child seats/child restraint
system installation............................ 154
Cleaning ................................................. 637
Flatting seat backs ................................ 87
Head restraint ......................................... 97
Power easy access system ..............95
Properly sitting in the seat .............. 130
Seat heaters ......................................... 605
Seat position memory ........................ 93
Seat ventilators ................................... 605
Service reminder indicators ............. 201
Shift lever
Hybrid transmission........................... 186
If the shift lever cannot be
shifted from P ................................... 779
Shift lever light........................................582
Shift lock system .................................... 779
Side airbags.............................................. 132
Side marker lights
Switch......................................................... 217
Side mirror
Adjusting and folding........................ 109
Mirror position memory .................... 93
Smart access system with
push-button start
Entry function ..........................................56
Starting the hybrid system ............... 177
“SOS” button .......................................... 626S
*: For vehicles with a navigation system, refer to the “Navigation System Owner’s Manual”.
