2015 LEXUS LX570 light

1291-7. Safety information
1
Before driving
LX570_OM_OM60L96U_(U) Your vehicle is equipped with AD VANCED AIRBAGS designed based
on the US motor vehicle safety stan dards (FMVSS208). The airbag sen-
sor assembly (ECU) co ntrols airbag deploy ment based on information
obtained from the sensors etc. shown in the system components diagram
above. This information includes crash severity and occupant informa-
tion. As the airbags deploy, a chemica l reaction in the inflators quickly fills
the airbags with nontoxic gas to help restrain th e motion of the occu-
pants. ■
If the SRS airbag s deploy (inflate)●
Bruising and slight abrasions may result from contact with a deploying (inflat-
ing) SRS airbag. ●
A loud noise and white powder will be emitted. ●
Parts of the airbag module (steering wh eel hub, airbag cover and inflator) as
well as the front seats, second seats, an d parts of the front, center and rear pil-
lars, and roof side rail, may be hot for se veral minutes. The airbag itself may also
be hot. ●
The windshield may crack. ●
For Safety Connect subscribers, if the SRS airbags deploy or in the event of a
severe rear-end collision, the system is designed to send an emergency call to
the response center, notifying them of th e vehicle’s location (without needing to
push the “SOS” button) and an agent will attempt to speak with the occupants
to ascertain the level of emergency and assistance required. If the occupants
are unable to communicate, the agent auto matically treats the call as an emer-
gency and helps to dispatch the necessary emergency services. (  P. 726)

1341-7. Safety information
LX570_OM_OM60L96U_(U) CAUTION■
SRS airbag precautions
Observe the following precautions regarding the SRS airbags.
Failure to do so may caus e death or serious injury.●
The driver and all passengers in the vehicl e must wear their seat belts properly.
The SRS airbags are supplemental device s to be used with the seat belts.●
The SRS driver airbag deploys with considerable force, and can cause death or
serious injury especially if the driver is very close to the airbag. The National
Highway Traffic Safety Administration (“NHTSA”) advises:
Since the risk zone for the dr iver’s airbag is the first 2 - 3 in. (50 - 75 mm) of infla-
tion, placing yourself 10 in. (250 mm) from your driver airbag provides you with a
clear margin of safety. This distance is measured from the center of the steering
wheel to your breastbone. If you sit less than 10 in. (250 mm) away now, you can
change your driving position in several ways:
• Move your seat to the rear as far as you can while still reaching the pedals
comfortably.
• Slightly recline the back of the seat.
Although vehicle designs vary, many dr ivers can achieve the 10 in. (250 mm)
distance, even with the driver seat all the way forward, simply by reclining the
back of the seat somewhat. If reclining the back of your seat makes it hard to
see the road, raise yourself by using a fi rm, non-slippery cushion, or raise the
seat if your vehicle has that feature.
• If your steering wheel is adjustable, ti lt it downward. This points the airbag
toward your chest instead of your head and neck.
The seat should be adjusted as recomme nded by NHTSA above, while still main-
taining control of the foot pedals, steeri ng wheel, and your view of the instrument
panel controls. ●
The portion of the front, side and rear pil-
lars or roof side rail garnishes (padding)
containing the curtain shield airbags is
inside scratched, cr acked, or otherwise
damaged.

1401-7. Safety information
LX570_OM_OM60L96U_(U) Front passenger occupant classification system Your vehicle is equipped with a fron t passenger occupant classification
system. This system detects the conditions of the front passenger seat and
activates or deactivates the devices for front passenger.
SRS warning light
AIR BAG OFF indicator light
AIR BAG ON indicator light
Front passenger’s seat belt reminder light

1411-7. Safety information
1
Before driving
LX570_OM_OM60L96U_(U) Condition and operation in the front passenger occupant classification
system
■ Adult
* 1
■ Child
* 3
or child restraint system
* 4Indicator/
warning light AIR BAG ON and AIR BAG OFF
indicator lights “AIR BAG
ON”
SRS warning light Off
Front passenger’s seat belt reminder light
Flashing
* 2
Devices Front passenger airb ag and knee airbag
ActivatedSide airbag in the front passenger seat
Curtain shield airbag
on the front passenger side
Front passenger’s seat belt pretensioner
Indicator/
warning light AIR BAG ON and AIR BAG OFF
indicator lights “AIR BAG
OFF”
* 5
SRS warning light Off
Front passenger’s seat belt reminder light
Flashing
* 2
Devices Front passenger airbag and knee airbag Deactivated
Side airbag in the front passenger seat
ActivatedCurtain shield airbag
on the front passenger side
Front passenger’s seat belt pretensioner

1421-7. Safety information
LX570_OM_OM60L96U_(U) ■ Unoccupied Indicator/
warning light AIR BAG ON and AIR BAG OFF
indicator lights Not illumi-
nated
SRS warning light
Off
Front passenger’s seat belt reminder light
Devices Front passenger airbag and knee airbag Deactivated
Side airbag in the front passenger seat
Activated
Curtain shield airbag
on the front passenger side
Front passenger’s seat be lt pretensioner Deactivated

1431-7. Safety information
1
Before driving
LX570_OM_OM60L96U_(U) ■ System malfunction
* 1
: The system judges a person of adult size as an adult. When a smaller
adult sits in the front passenger se at, the system may recognize him/
her as a child depending on his/her physique and posture.
* 2
: In the event the front passenger does not wear a seat belt.
* 3
: When a larger child who has outgro wn a child restraint system sits in
the front passenger seat, the sys tem may recognize him/her as an
adult depending on his/her physique or posture.
* 4
: Never install a real-faci ng child restraint system on the front passen-
ger seat. A rear-facing child restraint system should only be installed
on the front passenger seat when it is unavoidable. (  P. 146)
* 5
: In case the indicator is not illum inated, consult this manual as for
installing the child restraint system properly. (  P. 151)Indicator/
warning light AIR BAG ON and AIR BAG OFF
indicator lights “AIR BAG
OFF”
SRS warning light On
Front passenger’s seat belt reminder light Off
Devices Front passenger airbag and knee airbag Deactivated
Side airbag in the front passenger seat
ActivatedCurtain shield airbag
on the front passenger side
Front passenger’s seat belt pretensioner

1441-7. Safety information
LX570_OM_OM60L96U_(U) CAUTION■
Front passenger occupant classification system precautions
Observe the following precautions regardin g front passenger occupant classifica-
tion system.
Failure to do so may caus e death or serious injury.●
Wear the seat belt properly. ●
Make sure the front passenger ’s seat belt tab has not been left inserted into the
buckle before someone sits in the front passenger seat.●
Make sure the AIR BAG OFF indicator light is not illuminated when using the
seat belt extender for the front passe nger seat. If the AIR BAG OFF indicator
light is illuminated, disconnect the extender tongue from the seat belt buckle,
then reconnect the seat belt. Reconnect th e seat belt extender after making sure
the AIR BAG ON indicator light is illuminated. If you use the seat belt extender
while the AIR BAG OFF indicator light is illuminated, the SRS airbags for the
passenger may not activate correctly, whic h could cause death or serious injury
in the event of collision. ●
Do not apply a heavy load to the front passenger seat. ●
Do not put weight on the front passenger seat by putting your hands or feet on
the front passenger seat seatback from the second seat.●
Do not let a second seat pa ssenger lift the front passenger seat with their feet or
press on the seatback with their legs. ●
Do not put objects under the front passenger seat. ●
Do not recline the front passenger seatback so far that it touches a second seat.
This may cause the AIR BAG OFF indicator light to be illumin ated, which indi-
cates that the passenger’s airbags will no t deploy in the event of a severe acci-
dent. If the seatback touches the second seat, return the seatback to a position
where it does not touch the second seat . Keep the front passenger seatback as
upright as possible when the vehicle is moving. Reclining the seatback exces-
sively may lessen the effectiven ess of the seat belt system.

1451-7. Safety information
1
Before driving
LX570_OM_OM60L96U_(U) CAUTION■
Front passenger occupant classification system precautions ●
If an adult sits in the front passenger se at, the AIR BAG ON indicator light is illu-
minated. If the AIR BAG OFF indicator is illuminated, ask the passenger to sit up
straight, well back in the seat, feet on the floor, and with the seat belt worn cor-
rectly. If the AIR BAG OFF in dicator still remain illumi nated, either ask the pas-
senger to move to the second seat, or if that is not possible, move the front
passenger seat fully rearward.●
When it is unavoidable to install the forw ard-facing child restraint system on the
front passenger seat, install the child restraint syst em on the front passenger seat
in the proper order. (  P. 151)●
Do not modify or remove the front seat. ●
Do not kick the front passeng er seat or subject it to severe impact. Otherwise,
the SRS warning light may come on to indicate a malfunction in the detection sys-
tem. In this case, contact your Lexus dealer immediately. ●
Do not use a seat accessory, such as a cushion or seat cover, that covers the seat
cushion surface. ●
Child restraint systems installed on the se cond seat should not contact the front
seatbacks.
