2015 LEXUS LX570 remote start

501-2. Opening, closing and locking the doors
LX570_OM_OM60L96U_(U) ■
Operation signals ●
Doors: A buzzer sounds and the emergenc y flashers flash to indicate that the
doors have been locked/unlocked. (Locked: Once; Unlocked: Twice) ●
Windows and moon roof: A buzzer sounds to indicate that the windows and
moon roof are opening.■
Operating conditions
The wireless remote control will not operate when the “ENGINE START STOP”
switch is in any position other than OFF. ■
Door lock buzzer
If a door is not fully closed, a buzzer soun ds continuously for 5 seconds if an attempt
to lock the door is made. Fully close the d oor to stop the buzzer, and lock the vehi-
cle once more. ■
Power back door operation
The power back door can be opened while the vehicle is locked. (one motion) ■
Alarm
Using the wireless remote control to lock the door will set the alarm system. ■
Electronic key battery depletion
 P. 42■
Security feature
 P. 44■
If the wireless remote control does not operate properly ●
Locking and unlocking the doors: Use the mechanical key. (  P. 872)●
Starting the engine:  P. 873■
When the electronic key battery is fully depleted
 P. 784■
Conditions affecting operation
 P. 40■
Customization
Settings (e.g. unlocking fu nction) can be changed.
(Customizable features  P. 912)

841-3. Adjustable components (s eats, mirrors, steering wheel)
LX570_OM_OM60L96U_(U) Linking driving position memory with door unlock operation
Record your driving position to butto n “1”, “2” or “3” before performing
the following:
Using the wireless remote control
Turn the “ENGINE START STOP ” switch to OFF after closing
the driver’s door.
While pressing the desired button
(“1”, “2” or “3”), press on
the wireless remote control until
the signal beeps. The driving position is recalled
when the driver’s door is unlocked
using the entry function or wireless
remote control and the driver’s
door is opened.
To prevent unintended triggering of the alarm, open and close a door once after
a driving position has been recorded. (If a door is not opened within 60 seconds
after is pressed, the doors will be locked again and the alarm will auto-
matically be set.)
In case that the alarm is triggere d, immediately stop the alarm. (  P. 121)STEP 1
STEP 2

851-3. Adjustable components (s eats, mirrors, steering wheel)
1
Before driving
LX570_OM_OM60L96U_(U) Using the door lock switch
Carry only the key (including the ca rd key) to which you want to link
the driving position. If 2 or more ke ys are in the vehicle, the driving
position cannot be linked properly.
Turn the “ENGINE START STOP ” switch to OFF after closing
the driver’s door.
While pressing the desired button
(“1”, “2” or “3”), press the lock or
unlock side on the door lock
switch (either the driver or passen-
ger side) until the signal beeps. The driving position is recalled
when the driver’s door is unlocked
using the entry function or wireless
remote control and the driver’s
door is opened.STEP 1
STEP 2
■
Canceling the linked door unlock operation
Turn the “ENGINE START STOP” sw itch to OFF after closing the
driver’s door.
Using the wireless remote control: While pressing “SET” button, press
button on the wireless remote control until the signal beeps.
Using the door lock switch: While pre ssing “SET” button, press the lock or
unlock side on the door lock switch until the signal beeps.STEP 1
STEP 2

108
LX570_OM_OM60L96U_(U) 1-4. Opening and closing th e windows and moon roof
Power windows
Lock switch
Press the switch down to lock pas-
senger window switches. Use this switch to prevent children
from accidentally opening or clos-
ing a passenger window.The power windows can be opened and closed using the following
switches.
Closing
One-touch closing
*Opening
One-touch opening
*
*: To stop the window partway,
operate the switch in the oppo-
site direction.
■
The power windows can be operated when
The “ENGINE START STOP” switch is in IGNITION ON mode. ■
Door lock linked window operation
The following functions can be used if customized at your Lexus dealer. ●
The power windows can be opened and closed using the mechanical key.
(  P. 872)●
The power windows can be opened us ing the wireless remote control.
(  P. 49)●
The power windows can be closed using the entry function. (  P. 36)

1101-4. Opening and closing the windows and moon roof
LX570_OM_OM60L96U_(U) ■
Customization
Settings (e.g. linked door lock operation) can be changed.
(Customizable features  P. 912)
CAUTION■
Closing the windows
Observe the following precautions.
Failing to do so may result in death or serious injury. ●
The driver is responsible for all the powe r window operations, including the oper-
ation for the passengers. In order to preven t accidental operation, especially by a
child, do not let a child op erate the power windows. It is possible for children and
other passengers to have body parts caught in the power window. Also, when
riding with a child, it is recommended to use the window lock switch. (  P. 108)●
Check to make sure that all passengers do not have any part of their body in a
position where it could be caught when a window is being operated. ●
When using the smart access system, wireless remote co ntrol or mechanical key
and operating the power windows, operat e the power window after checking to
make sure that there is no possibility of any passenger having any of their body
parts caught in the window. Also, do not let a child operate window by the smart
access system, wireless remote control or me chanical key. It is possible for chil-
dren and other passengers to get caught in the power window. ●
When exiting the vehicle, turn the “ENG INE START STOP” switch off, carry the
key and exit the vehicle along with the child. There may be accidental operation,
due to mischief, etc., that may possibly lead to an accident.■
Jam protection function ●
Never try jamming any part of your body to activate the jam protection function
intentionally. ●
The jam protection function may not work if something gets caught just before
the window fully closes.

1151-4. Opening and closing the windows and moon roof
1
Before driving
LX570_OM_OM60L96U_(U) CAUTION■
Closing the moon roof
Observe the following precautions.
Failing to do so may result in death or serious injury. ●
The driver is responsible for moon roof opening and closing op erations. In order
to prevent accidental operation, especially by a child, do not let a child operate
the moon roof. It is possible for children and other passengers to have body parts
caught in the moon roof. ●
Check to make sure that all passengers do not have any part of their bodies in a
position where they could be caught when the moon roof is being operated. ●
When using the smart access system, wireless remote co ntrol or mechanical key
and operating the moon roof , operate the moon roof after checking to make sure
that there is no possibility of any passenger having any of their body parts caught
in the moon roof. Also, do not let a child operate moon roof by the smart access
system, wireless remote contro l or mechanical key. It is possible for children and
other passengers to get caught in the moon roof. ●
When exiting the vehicle, turn the “ENG INE START STOP” switch off, carry the
key and exit the vehicle along with the child. There may be accidental operation,
due to mischief, etc., that may possibly lead to an accident.■
Jam protection function ●
Never try jamming any part of your body to activate the jam protection function
intentionally. ●
The jam protection function may not work if something gets caught just before
the moon roof fully closes.

7223-8. Other interior features
LX570_OM_OM60L96U_(U) ■ Programming an entry gate (for U .S.A. owners)/Programming all
devices in the Canadian market
Place your transmitter 1 to 3 in. (25 to 75 mm) away from the sur-
face of the HomeLink ®
.Keep the HomeLink ®
indicator light in view while programming.
Press and hold the selected HomeLink ®
button.
Repeatedly press and release (cycle) the device’s remote control
button for two seconds each until step 4 is completed.
When the indicator light on the HomeLink ®
compatible trans-
ceiver starts to flash rapidly, release the buttons.
Test the operation of the HomeLink ®
by pressing the newly pro-
grammed button. Check to see if the gate/device operates cor-
rectly.
Repeat the steps above to program another device for each of
the remaining HomeLink ®
buttons.
■ Programming other devices
To program other devices such as home security systems, home door
locks or lighting, contact yo ur Lexus dealer for assistance.
■ Reprogramming a button
The individual HomeLink ®
buttons cannot be erased but can be
reprogrammed. To reprogram a butto n, follow the “Reprogramming a
HomeLink ®
button” instructions.STEP 1
STEP 2
STEP 3
STEP 4
STEP 5
STEP 6

7854-3. Do-it-yourself maintenance
4
Maintenance and care
LX570_OM_OM60L96U_(U) ■
If the electronic key battery is discharged
The following symptoms may occur. ●
The smart access system with push-butto n start and wireless remote control will
not function properly. ●
The operational range is reduced.■
Use a CR1632 lithium battery ●
Batteries can be purchased at your Lexus dealer, jewelers, or camera stores. ●
Replace only with the same or equiva lent type recommend ed by your Lexus
dealer. ●
Dispose of used batteries according to the local laws.■
When the card key battery needs to be replaced
The battery for the card key is available on ly at Lexus dealer. Your Lexus dealer can
replace the battery for you.
CAUTION■
Removed battery and other parts
These parts are small and if swallowed by a child, they can cause choking. Keep
away from children. Failure to do so co uld result in death or serious injury.
NOTICE■
For normal operation after replacing the battery
Observe the following precautions to prevent accidents. ●
Always work with dry hands.
Moisture may cause the battery to rust. ●
Do not touch or move any other comp onents inside the electronic key.●
Do not bend the battery terminals.
