2015 LEXUS LS600H display

329
Interior features5
LS600hL_U(OM50E41U)5-1. Remote Touch screen
Remote Touch/12.3-inch display ......................................... 330
5-2. Lexus Climate Concierge Lexus Climate Concierge ..................................335
5-3. Using the air conditioning system and defogger
Front automatic air conditioning system ...............336
Rear air conditioning system ........................................... 351
Rear window and outside rear view mirror
defoggers .................................. 358
Windshield wiper de-icer..........................................359 5-4. Using the interior lights
Interior lights list .........................360• Interior lights ............................361
• Personal lights ....................... 362
5-5. Using the storage features List of storage features ............ 364• Glove box ............................... 366
• Coin holder ............................ 367
• Door pockets ......................... 367
• Cup holders ...........................368
• Console box........................... 369
• Auxiliary boxes ....................... 371
Trunk features .............................. 373
5-6. Other interior features Sun visors and vanity mirrors .......................................... 376
Clock............................................... 378
Ashtrays ......................................... 379
Cigarette lighters ...................... 380
Power outlets ...............................382
Heated steering wheel ............385
Climate control seats ............... 387
Armrest .......................................... 392
Retractable table ........................ 393
Rear sunshade............................. 395
Rear door sunshades................398
Coat hooks .................................... 401
Assist grips.................................... 402
Garage door opener................ 403
LEXUS Enform Safety Connect ....................................... 410

330
LS600hL_U(OM50E41U)
5-1. Remote Touch screen
“ • ” button
Vehicles with a navigation system
Press this button to scroll the list sc reen and to change the scale of the map.
Vehicles without a navigation system
Press this button to scroll the list screen.
“MAP/VOICE” button
Press this button to display the current position, cancel the screen scroll, start
guidance, and repeat a voice guidance.
Remote Touch knob
Move in the desired direction to select a function, letter and screen button.
Press the knob to enter the selected function, letter or screen button.
“MENU” button
Press this button to display the “Menu” screen.
button
Press this button to displa y the compass mode screen.
Remote Touch/12.3-inch display
The Remote Touch can be used to operate the Remote Touch screens.
For details, refer to “NAVIGATION AND MULTIMEDIA SYSTEM
OWNER’S MANUAL”.
Vehicles with a
navigation system Vehicles without a
navigation system
1
2
3
4
5

3315-1. Remote Touch screen
5
Interior features
LS600hL_U(OM50E41U)
Select: Move the knob in the
desired direction.
Enter: Press the knob.
■Screen display during low temperatures
When the ambient temperature is extremely low, screen response may be delayed
even if the Remote Touch is operated.
Remote Touch operation
1
2
CAUTION
■When using the Remote Touch
●Do not allow fingers, fingernails or hair to become caught in the Remote Touch as
this may cause an injury.
●Be careful when touching the Remote Touch in extreme temperatures as it may
become very hot or cold due to the temperature inside the vehicle.
NOTICE
■To prevent damage to the Remote Touch
●Do not allow the Remote Touch to come into contact with food, liquid, stickers or
lit cigarettes as doing so may cause it to change color, emit a strange odor or stop
functioning.
●Do not subject the Remote Touch to excessive pressure or strong impact as the
knob may bend or break off.
●Do not allow coins, contact lenses or other such items to become caught in the
Remote Touch as this may cau se it to stop functioning.
●Items of clothing may rip if they become caught on the Remote Touch knob.
●If your hand or any object is on the Remote Touch knob when the power switch is
turned to ACCESSORY mode, the Remote Touch knob may not operate prop-
erly.

3325-1. Remote Touch screen
LS600hL_U(OM50E41U)
■Full screen display
The initial screen and “Menu” screen fill the entirety of the display area.
12.3-inch display
SwitchFunction
Select to display the “Destination” screen.
Select to display the “LEXUS App Suite” screen.
Select to display the “Information” screen. ( P. 113, 115)
Select to display the “Setup” screen.
Select to display the radio control screen.
Select to display the media control screen.
Select to display the air conditioning control screen. ( P. 3 3 7 )
Select to display the phone top screen.
“Display”Select to adjust the contrast and brightness of the screens, turn
the screen off, etc.

3335-1. Remote Touch screen
5
Interior features
LS600hL_U(OM50E41U)
■Split-screen display
Different information can be displayed on the left and right of the
screen. For example, audio, air co nditioning system or fuel consump-
tion information screens can be d isplayed and operated while the map
screen is being displayed.
The large screen on the left of the display is called the “Main Display”,
and the small screen to the righ t is called the “Side Display”.
■Selecting the operation screen
When selecting the “Side Display”, mo ve the Remote Touch knob to the
right until is displayed at the bo undary between the “Main Display”
and the “Side Display”, and then move it further to the right.
When selecting the “Main Display”, move the Remote Touch knob to
the left until is displayed at the boundary between the “Main Dis-
play” and the “Side Display”, and then move it further to the left.
Selecting the “Main Display” will dim the “Side Display”.

3345-1. Remote Touch screen
LS600hL_U(OM50E41U)
■“Side Display”
The following functions can be displayed and operated on the “Side
Display”.
Basic screens
Audio system
Air conditioning system
( P. 3 3 8 )
Vehicle information ( P. 118)
Detailed information that is not shown on the “Side Display” can be set
to display on th e “Main Display”.
Select , or .
Interruption screens
Each of the following screens is di splayed automatically in accordance
with conditions. • Intuitive parking assist
•Phone
• Destination Assist
• Driving mode ( P. 283)
• Lexus night view (if equipped) ( P. 320)
1
2
3

336
LS600hL_U(OM50E41U)
5-3. Using the air conditioning system and defogger
■Control panel
Front automatic air conditioning system
Air outlets and fan speed are automatically adjusted according to the
temperature setting.
Press the “MENU” button on the Remote Touch, and then select
to display the air conditioning operation screen. ( P. 3 3 0 )
The air conditioning system can be di splayed and operated on the “Side
Display”. ( P. 3 3 3 )
The display and button positions will di ffer depending on the type of the
system.
Left-hand front seat side tem-
perature control
Left-hand front seat side tem-
perature display
Right-hand front seat side
temperature display
Right-hand front seat side
temperature control Outside/recirculated air mode
Windshield defogger
Air outlet selector
Fan speed control
Off
Automatic mode1
2
3
4
5
6
7
8
9
10

3375-3. Using the air conditioning system and defogger
5
Interior features
LS600hL_U(OM50E41U)
■Operation screen (“Main Display”)
Outside temperature
Air flows to the feet and the
windshield defogger operates
Rear air conditioning operation
screen
Right-hand front seat side tem-
perature display
Right-hand front seat side tem-
perature control
Option control screen
Right-hand front seat side air
outlet selector Option function on/off indica-
tors
Off
Automatic mode
Left-hand front seat side tem-
perature control
Left-hand front seat side tem-
perature display
Left-hand front seat side air out-
let selector
Fan speed control1
2
3
4
5
6
7
8
9
10
11
12
13
14
