2015 Lexus ES300h Opening, closing and locking the doors and trunk / Owner's Manual Quick Guide (OM33B53U)

105
ES300h_QG_OM33B53U_(U)
Moon Roof
■Opening and closing
Opens the moon roof*
The moon roof stops slightly before the
fully open position to reduce wind
noise.
Press the switch again to fully open the
moon roof.
Closes the moon roof
*
*
: Lightly press either of the moon roof
switches to stop the moon roof partway.
■ Tilting up and down
Tilts the moon roof up*
Tilts the moon roof down*
*
: Lightly press either of the moon roof
switches to stop the moon roof partway.
1
2
1
2

106
ES300h_QG_OM33B53U_(U)
Fuel Tank Cap
■Before refueling the vehicle
● Close all the doors and windows, and turn the “POWER” switch off.
● Confirm the type of fuel.
■Opening the fuel tank cap
Press the opener switch to open the
fuel filler door.
Turn the fuel tank cap slowly to open.
Hang the fuel tank cap on the back of
the fuel filler door.1
2
3

107
ES300h_QG_OM33B53U_(U)
Tr u n k
■Opening the trunk
● From inside the vehicle
Press the opener switch.If the vehicle is equipped with a power
trunk opener and closer, the trunk lid
automatically opens fully
Turn the main switch in the glove box off to
disable the trunk opener. On
Off
The trunk lid cannot be opened even with
the wireless remote control or the trunk
release button.
● From outside the vehicle
• Trunk release button
While carrying the electronic key, press the
button on the trunk lid.When all the doors are unlocked with
the power door lock system, the trunk
can be opened without carrying the
electronic key.
• Wireless remote control  P.1 9
1
2

108
ES300h_QG_OM33B53U_(U)
■Trunk easy closer (vehicles with power trunk opener and closer)
In the event that the trunk lid is left slightly open, the trunk easy closer will automatically
close it to the fully closed position.
■Trunk closer switch (vehicles with power trunk opener and closer)
Pressing the switch closes the trunk lid
automatically. (A buzzer sounds.)
Pressing the switch while the trunk lid is
closing opens the trunk lid again.

What to do if...
109
ES300h_QG_OM33B53U_(U)
List of Warning/Indicator Lights
Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous.
(U.S.A.)
Brake system warning light
(Canada)
Stop the vehicle immediately.
Charging system warning light
Have the vehicle inspected immediately.
(U.S.A.)Malfunction
indicator lamp(Flashes)
“PCS” warning light
(if equipped)
(Canada)Slip indicator
SRS warning lightBrake system warning light
(U.S.A.)
ABS warning light(Blinking and then continu-
ously on)
Tire pressure warning light
(Canada)
Electric power steering
system warning lightAutomatic headlight leveling
system warning light
(if equipped)
For further information, refer to the OWNER’S MANUAL.

110
What to do if...
ES300h_QG_OM33B53U_(U)
*: It also comes on due to natural causes such as natural air leaks and tire inflation pressure changes caused by temperature. Adjust the tire inflation pressure to the specified level.
The light will turn off after a few minutes. In case the light does not turn off even if the tire
inflation pressure is adjusted, have th e system checked by your Lexus dealer.
Follow the correction procedures.
Open door warning lightMaster warning light
Low fuel level warning light
(Illuminates
without
blinking)
Tire pressure warning light*
Seat belt reminder light
For further information, re fer to the OWNER’S MANUAL.

What to do if...
111
ES300h_QG_OM33B53U_(U)
See the OWNER’S MANUAL
Turn signal indicatorCruise control “SET” indicator
Headlight indicator (U.S.A.)“LDA” (Lane Departure Alert)
indicator (if equipped)
Tail light indicator (Canada)Intuitive parking assist
indicator (if equipped)
Headlight high beam indicator
(Flashes)
Slip indicator
Automatic High Beam
indicator (if equipped)VSC OFF indicator
Fog light indicator(Flashes faster)
“PCS” warning light
(if equipped)
“READY” indicator BSM outside rear view mirror
indicators (if equipped)
EV indicator “AIR BAG ON/OFF”
indicator
Cruise control indicator
Radar cruise control
indicator (if equipped)
For further information, refer to the OWNER’S MANUAL.

112
What to do if...
ES300h_QG_OM33B53U_(U)
If the electronic key does not operate properly
■Unlocking and locking the doors
Use the mechanical key ( P.1 8 ) i n o r d e r t o
perform the following operations:
Locks all the doors
Closes the windows and moon roof
*
(turn and hold)
Unlocks the door
Turning the key rearward unlocks the
driver’s door. Turning the key once
again within 5 seconds unlocks the
other doors.
Opens the windows and moon roof
*
(turn and hold)
*: This setting must be customized at yourLexus dealer.
■ Unlocking the trunk
Turn the mechanical key clockwise to open.
1
2
3
4
