2015 Lexus ES300h seats

ES350_300h_OM_OM33B99U_(U)
4696-1. Using the air conditioning system and defogger
6
Interior features
■Using the automatic mode
Press the “AUTO” button.
Adjust the temperature setting.
To stop the operation, press the “OFF” button.
■Automatic mode indicator
If the fan speed setting or air flo w modes are operated, the automatic
mode indicator goes off. However, automatic mode for functions other
than that operated are maintained.
■Adjusting the temperature for driver and passenger seats separately
(“DUAL” mode)
To turn on the “DUAL” mode, perform any of the following procedures:
●Press the “DUAL” button.
●Select “DUAL” on the option control screen.
●Adjust the passenger’s side temperature setting.
The indicator comes on when the “DUAL” mode is on.
Air conditioning controls
1
2
3

477
ES350_300h_OM_OM33B99U_(U)
6-1. Using the air conditioning system and defogger
6
Interior features
Heated steering wheel/seat heaters/
seat ventilators


: If equipped
Heated steering wheel and seat heaters heat the side grips of the steer-
ing wheel and seats, respectively. Seat ventilators maintain good air-
flow by blowing air from the seats.
CAUTION
●Care should be taken to prevent injury if anyone in the following categories
comes in contact with the steering wheel and seats when the heater is on:
• Babies, small children, the elderly, the sick and the physically challenged
• Persons with sensitive skin
• Persons who are fatigued
• Persons who have taken alcohol or drugs that induce sleep (sleeping drugs, cold remedies, etc.)
●Observe the following precautions to prevent minor burns or overheating:
• Do not cover the seat with a blanket or cushion when using the seat heater.
• Do not use seat heater more than necessary.
NOTICE
●Do not put heavy objects that have an unev en surface on the seat and do not stick
sharp objects (needles, nail s, etc.) into the seat.
●To prevent 12-volt battery discharge, do not use the functions when the hybrid
system is off.

528
ES350_300h_OM_OM33B99U_(U)
7-1. Maintenance and care
NOTICE
■Cleaning detergents
●Do not use the following types of detergent, as they may discolor the vehicle inte-
rior or cause streaks or damage to painted surfaces:
• Non-seat portions: Organic substances such as benzene or gasoline, alkalineor acidic solutions, dye, and bleach
• Seats: Alkaline or acidic solutions, such as thinner, benzene, and alcohol
●Do not use polish wax or polish cleaner. The instrument panel’s or other interior
part’s painted surf ace may be damaged.
■Preventing damage to leather surfaces
Observe the following precautions to avoid damage to and deterioration of
leather surfaces:
●Remove any dust or dirt from leather surfaces immediately.
●Do not expose the vehicle to direct sunlight for extended periods of time. Park
the vehicle in the shade, especially during summer.
●Do not place items made of vinyl, plastic, or containing wax on the upholstery, as
they may stick to the leather surface if the vehicle interior heats up significantly.
■Water on the floor
Do not wash the vehicle floor with water.
Vehicle systems such as the audio syst em may be damaged if water comes into
contact with electrical components such as the audio system above or under the
floor of the vehicle. Water may also cause the body to rust.
■When cleaning the inside of the windshield (vehicles with LDA [Lane Departure
Alert] and Automatic High Beam)
Be careful not to touch the camera sensor ( P. 2 7 9 ) .
If the camera is accidentally scratched or hit, LDA and Automatic High Beam sys-
tem may not operate properly or may cause a malfunction.
■Cleaning the inside of the rear window
●Do not use glass cleaner to clean the rear window, as this may cause damage to
the rear window defogger heater wires or antenna. Use a cloth dampened with
lukewarm water to gently wipe the window clean. Wipe the window in strokes
running parallel to the heater wires or antenna.
●Be careful not to scratch or damage the heater wires or antenna.

534
ES350_300h_OM_OM33B99U_(U)
7-2. Maintenance
Head restraints•Do the head restraints movesmoothly and lock securely?
Indicators/buzzers• Do the indicators and buzzers func-tion properly?
Lights• Do all the lights come on?
• Are the headlights aimed correctly?
Parking brake
• Does the parking brake pedal movesmoothly?
• When parked on a slope and the parking brake is on, is the vehicle
securely stopped?
Seat belts
• Do the seat belts operate smoothly?
• The seat belts should not be dam-aged.
Seats• Do the seat controls operate prop-erly?
Steering wheel
• Does the steering wheel rotatesmoothly?
• Does the steering wheel have the correct amount of free play?
• There should not be any strange sounds coming from the steering
wheel.
ItemsCheck points

592
ES350_300h_OM_OM33B99U_(U)
7-3. Do-it-yourself maintenance
*1:Hybrid vehicles
*2: Gasoline vehicles
40
A/F*220Air intake system
EFI-MAIN
NO.2
*120Fuel system, air intake system, exhaust sys-
tem
41AM27. 5Power management system, smart access
system with push-button start
42PA N E L10
Switch illumination, audio system, multi-infor-
mation display, audio display, shift lever light,
glove box light, console box light,
Remote Touch, intuitive parking assist switch
illumination
43DOME7. 5
Clock, footwell lights, vanity lights, ornament
lights, personal lights, door courtesy lights,
outer foot lights
44ECU-B NO.110
Smart access system with push-button start,
main body ECU, steering sensor, gauges and
meters, gateway ECU, electric tilt and tele-
scopic steering column, power seats, over-
head module, outside mirror control ECU,
power trunk opener and closer ECU
45SPARE25Spare fuse
46SPARE30Spare fuse
FuseAmpereCircuit

ES350_300h_OM_OM33B99U_(U)
7259-1. Specifications
9
Vehicle specifications
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation pres-
sureTire pressure when the vehicle has been parked for
three hours or more, or has not been driven more
than 1 mile or 1.5 km under that condition
Maximum inflation pres-
sureThe maximum cold inflated pressure to which a tire
may be inflated, shown on the sidewall of the tire
Recommended inflation
pressureCold tire inflation pressure recommended by a man-
ufacturer
Accessory weight
The combined weight (in excess of those standard
items which may be replaced) of automatic transmis-
sion, power steering, power brakes, power windows,
power seats, radio and heater, to the extent that these
items are available as factory-installed equipment
(whether installed or not)
Curb weight
The weight of a motor vehicle with standard equip-
ment, including the maximum capacity of fuel, oil and
coolant, and if so equipped, air conditioning and
additional weight optional engine
Maximum loaded vehicle
weight
The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight
Normal occupant weight150 lb. (68 kg) times the number of occupants speci-
fied in the second column of Table 1
* that follows
Occupant distributionDistribution of occupants in a vehicle as specified in
the third column of Table 1
* below
Production options weight
The combined weight of installed regular production
options weighing over 5 lb. (2.3 kg) in excess of the
standard items which they replace, not previously
considered in curb weight or accessory weight,
including heavy duty brakes, ride levelers, roof rack,
heavy duty battery, and special trim
RimA metal support for a tire or a tire and tube assembly
upon which the tire beads are seated

768Alphabetical index
ES350_300h_OM_OM33B99U_(U)
CareAluminum wheels ..............................523
Exterior.................................................... 522
Interior .....................................................526
Seat belts ................................................ 527
Cargo capacity...................................... 202
Cargo hooks ..........................................488
CD player
*............................................. 387
Chains ....................................................... 343
Child restraint system Booster seats, definition ................... 58
Booster seats, installation..................68
Convertible seats, definition ........... 58
Convertible seats, installation .........65
Front passenger occupant classification system ........................ 50
Infant seats, definition ......................... 58
Infant seats, installation .......................65
Installing CRS with LATCH anchors ..................... 63
Installing CRS with seat belts ..........65
Installing CRS with top tether strap .........................69 Child safety ................................................. 57
12-volt battery precautions .......................... 559, 683
Airbag precautions................................ 41
Child restraint system......................... 58
How your child should wear the seat belt .......................................... 34
Installing child restraints .................... 62
Moon roof precautions ................... 185
Power window lock switch............. 177
Power window precautions .......... 180
Rear door child-protectors ............145
Removed electronic key battery precautions ............. 585
Seat belt extender precautions ...........................................37
Seat belt precautions ............................ 61
Seat heater precautions ..................477
Trunk precautions ............................... 152
Child-protectors .................................... 145
Cleaning Aluminum wheels .............................. 523
Exterior ................................................... 522
Interior ..................................................... 526
Seat belts................................................ 527
Clock........................................................... 491
Coat hooks ............................................. 499
Condenser.............................................. 555
Console box ........................................... 485
Console box light ................................. 485
Consumption screen ............................. 118
Cooling system Engine overheating ......................... 688
Hybrid system overheating ............691
Cruise control Cruise control ..................................... 254
Dynamic radar cruise control .....258
C

771Alphabetical index
ES350_300h_OM_OM33B99U_(U)
Enhanced VSC .......................................313
EPS (Electronic Po wer Steering)
Function ................................................... 314
Warning light ...................................... 628
Warning message ............................ 639
Event data recorder (EDR) .................... 11
Flat tire ...................................................... 659
Floor mats ................................................... 28
Fluid Automatic transaxle........................... 710
Brake ........................................................... 711
Hybrid transaxle .................................. 710
Washer .................................................... 561
Fog lights Replacing light bulbs .............602, 610
Switch....................................................... 244
Wattage ....................................................714
Footwell light .......................................... 479
Front passenger occupant classification system ............................ 50
Front personal lights............................480
Front seats Adjustment ............................................. 157
Cleaning .................................................526
Correct driving posture ....................30
Driving position memory ................ 159
Head restraints ..................................... 165
Power easy access system ............ 159
Seat heaters ..........................................478
Seat position memory....................... 159
Seat ventilators ....................................478 Front side marker lights
Light switch........................................... 233
Replacing light bulbs ...................... 606
Welcome light illumination control.................................................... 127
Wattage ................................................... 714
Front turn signal lights Replacing light bulbs .......................604
Turn signal lever ................................. 230
Wattage ................................................... 714
Fuel Capacity................................................. 704
Fuel gauge ................................................97
Fuel pump shut off system ............ 625
Information.............................................. 715
Refueling ................................................ 249
Type.......................................................... 704
Warning light ....................................... 629
Warning messages .......................... 647
Fuel filler door.........................................249 Refueling ................................................ 249
When the fuel filler door cannot be opened ......................... 252
Fuel pump shut off system ................ 625
Fuses.......................................................... 586
Garage door opener............................501
Gauges......................................................... 97
Glove box ............................................... 484
Glove box light...................................... 484
Grocery bag hooks............................. 488
F
G
