2015 INFINITI Q70 Quick Reference Guide

23
*Some jurisdictions prohibit the use of cellular telephones while drivin\
g.


For vehicles equipped with Navigation:
•
Refer to the “Voice recognition (section 9)” of your Navigation System Owner’s Manual
for more information.

The “Help” command can be used to hear a list of available command\
s at any time.

Reduce background noise as much as possible by closing windows and point\
ing HVAC vents
away from the ceiling.

Speak naturally without long pauses and without raising your voice.

When speaking phonebook names, please be aware some phones require the l\
ast name to be
spoken before the first name. For example, “Michael Smith” may be \
spoken as “Smith Michael”.

To cancel a Voice Recognition session, say “Cancel” or “Quit”\
or press and hold the
or

button for 5 seconds.

To go back to the previous command, say “Go back” or “Correctio\
n”.

If the Voice Recognition system does not recognize your voice commands, \
train the system
using the Speaker Adaptation Mode. See your Owner’s Manual for detail\
ed information.

For more detailed information and instructions, refer to your cellular p\
hone’s Owner’s Manual and
visit www.InfinitiUSA.com/bluetooth.
Bluetooth® System with Navigation* (if so equipped)
CONNECTING PROCEDURE


The vehicle must be stationary when connecting
the phone.*
1. Press the

button on the steering wheel and select
the “Connect Phone” key.



2. Initiate connecting from the phone.
• The connecting procedure varies according to each
cellular phone model. For detailed connecting
instructions and a list of compatible phones,
please visit www.InfinitiUSA.com/bluetooth.
• When prompted for a PIN code, enter “1234”
from the handset. (The PIN code is assigned
by INFINITI and cannot be changed.)
3. When connecting is complete, the screen will
return to the Phone menu.
1727653‎_15b_Infiniti_Q70_QRG_100814.indd 2310/8/14 11:38 AM

24
system guide
PHONEBOOK SETUP

Depending on your cellular phone, the system may
automatically download your cellular phone’s
entire phonebook to the vehicle’s Bluetooth system.

If the phonebook does not download automatically,
the vehicle’s phonebook may be set for up to
40 entries.

To manually download entries:
1. Press the
button and select the “Quick Dial” key.
2. Select the “Add New” key at the top of the display.
There are different methods to input a phone
number. Select one of the following options:
• “Copy from Call History”- to save a number from
the Outgoing, Incoming or Missed Calls lists.
• “Copy from the Phonebook”- to save a number that has been downloaded from your
handset to the vehicle.
• “Enter Number by Keypad”- to input the number and name manually.
MAKING A CALL
To make a call, follow this procedure:
1. Press the

button on the steering wheel. The “Phone”

menu will appear on the control panel display.
2. Select the “Quick Dial”, “Call History”, “Phonebook”
or “Dial Number” key.
3. Select the desired entry from the list.
4. Select “Call” to start dialing the number.
RECEIVING/ENDING A CALL

To accept the call, press the button on the steering

wheel or touch the “Answer” key. To reject the call,
touch the “Reject Call” key.


To hang-up, press the button or touch the

“Hang up” key.
1727653‎_15b_Infiniti_Q70_QRG_100814.indd 2410/8/14 11:38 AM

25
Bluetooth® System without Navigation* (if so equipped)
PAIRING PROCEDURE
1. Press the

button on the steering wheel. The

system announces the available commands.
2. Say: “Connect Phone”. The system acknowledges
the command and announces the next set of
available commands.
3. Say: “Add Phone”. The system acknowledges the
command and asks you to initiate connecting from
the phone handset.
4. Initiate pairing from the phone.
• The connecting procedure varies according to each cellular phone model.
For detailed connecting instructions and a list of compatible phones, pl\
ease
visit www.InfinitiUSA.com/bluetooth.
• When prompted for a PIN code, enter “1234” from the handset. (The\
PIN code is assigned
by INFINITI and cannot be changed.
5. Say a name for the phone when the system asks to provide one. You can gi\
ve the phone a
name of your choice.
PHONEBOOK REGISTRATION

When the cellular phone is connected to the in-vehicle module, the data \
stored in the cellular
phone, such as the phonebook, outgoing call logs, incoming call logs and\
missed call logs, is
automatically transferred and registered to the system.

The availability of this function depends on each cellular phone. The co\
pying procedure
also varies according to each cellular phone. See your cellular phone’\
s Owner’s Manual for
more information.

Up to 1,000 entries per registered cellular phone can be stored in the p\
honebook.
MAKING A CALL
1. Push the

button on the steering wheel. A tone will sound.
2. Say: “Call”. The system acknowledges the command and announces the\
next set of
available commands.
3. Say the registered person’s name. The system acknowledges the command\
and announces
the next set of available commands.
4. Say: “Yes”. The system acknowledges the command and makes the call\
.
RECEIVING/ENDING A CALL

To accept the call, press the
button on the steering wheel. To reject the call, press the button.

To hang-up, press the button.
*Some jurisdictions prohibit the use of cellular telephones while drivin\
g.
For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (secti\
on 4)” of your Owner’s Manual
or visit www.InfinitiUSA.com/bluetooth.
1727653‎_15b_Infiniti_Q70_QRG_100814.indd 2510/8/14 11:38 AM

26
system guide
Navigation System (if so equipped)
1 Touch-screen display
2 DEST (Destination)– Press to enter a destination.
3 INFO
(Information) – Press to display the vehicle, traffic (if so equip\
ped), weather (if so
equipped) or Voice Recognition information.
4 SETTING – Press to access the system settings.
5 Multi-Function Controller

• ENTER – Press the ENTER button to select the highlighted item on the screen.
• Center Dial – Turn the dial to highlight an item on the screen, adjus\
t a setting or adjust
the map scale.
• Slide the controller (push upward/downward/leftward/rightward) to sele\
ct an item on the
screen, to adjust a setting or scroll the map in eight directions.
6 ROUTE – Press to access guidance control functions, such as guidance cance\
llation, route

priority or waypoint setting on the route.
7 MAP – Press to display the map. While following a programed route, press\
multiple times to
change the type of route information.
23
5
4
98
1110
76
1
1727653‎_15b_Infiniti_Q70_QRG_100814.indd 2610/8/14 11:38 AM

27
8 STATUS – Press multiple times to display audio information, air conditioner\
status, fuel

economy or navigation directions.
9 – Press to switch between the day screen (bright) and the night sc\
reen (dark). Press and

hold the button to turn the display off. Press again to turn the display\
on.
10
BACK – Press to return to the previous screen. In a settings screen, this\
button can also
be used to apply the setting. In a character input screen, this button can \
also delete the char-
acters that have been entered.
11 VOICE – Press to hear the current voice guidance for a programed route.
For more information, please refer to your Navigation System Owner’s \
Manual.
DVD Player (if so equipped)

This system allows you to play video files via DVD
or CD from the front display.

To view movies on the front display, stop the vehicle
in a safe location, move the shift lever to the P (PARK)
position and apply the parking brake.

To reduce driver distraction, movies will not be shown
on the front display while the vehicle is in any
drive position.
For more information, refer to the “Monitor, climate, audio, phone and voice
recognition systems (section 4)” of your Owner’s Manual.
1727653‎_15b_Infiniti_Q70_QRG_100814.indd 2710/8/14 11:38 AM

28

HomeLink® Universal Transceiver
The HomeLink® Universal Transceiver can learn and consolidate the functions of up to \
three different hand-held transmitters, operating items such as garage d\
oors, property
gates, outdoor and indoor lights or alarm systems.

To program the HomeLink Universal Transceiver:
• Position the handheld transceiver 1-3 in (26-76 mm) away from the Home\
Link surface,
keeping the HomeLink indicator light in view.
• Press and hold the desired HomeLink button and the handheld transmitter \
button
simultaneously until the HomeLink indicator light flashes slowly and the\
n rapidly.
• Both buttons may be released when the indicator light flashes rapidly.

To verify the programing is complete, press and hold the HomeLink button\
and observe the
indicator light:
• A solid, continuous light indicates the programing is complete, and the \
HomeLink button
will activate your device.
• A blinking light that turns to a solid, continuous light after 2 seconds\
indicates additional
steps are required to complete the programing.

An additional person may make the remaining steps easier. To complete th\
e
programing process:
• At the receiver of the device that you are programing to the HomeLink bu\
tton, press
and release the learn or smart button (the name may vary by manufacture\
r, but it is
usually located near where the hanging antenna wire is attached to the u\
nit). You have
approximately 30 seconds to initiate the following step.
• Press and hold the programed HomeLink button for 2 seconds and release.

You may have to repeat the previous two steps up to three times to compl\
ete the
programing process. HomeLink should now activate your device.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual, the HomeLink website at
www.homelink.com or call 1-800-355-3515.
HOMELINK
system guide
1727653‎_15b_Infiniti_Q70_QRG_100814.indd 2810/8/14 11:38 AM

memo
1727653‎_15b_Infiniti_Q70_QRG_100814.indd 2910/8/14 11:38 AM

To view detailed instructional videos,
go to www.infinitiownersinfo.mobi/2015/q70
or snap this barcode with an appropriate
barcode reader.
Printing: November 2014 (06) / QR15EA 0Y51U1 / Printed in USA
This Quick Reference Guide is intended to provide an overview of some of\
the unique features of
your new vehicle. Please see your Owner’s Manual for important safety\
information and system
operation limitations. Features and equipment in your vehicle may vary d\
epending on model,
trim level, options selected, order, date of production, region or avail\
ability. Therefore, you may
find information about features or equipment that are not included or in\
stalled on your vehicle.
All information, specifications and illustrations in this Quick Referenc\
e Guide are those in
effect at the time of printing. NISSAN reserves the right to change spec\
ifications, performance,
design or component suppliers without notice and without obligation. Fro\
m time to time, NISSAN
may update or revise this Quick Reference Guide to provide owners with t\
he most accurate
information currently available. Please carefully read and retain, with \
this Quick Reference Guide,
all revision updates sent to you by NISSAN to ensure you have access to \
accurate and up-to-date
information regarding your vehicle. Current versions of vehicle Quick Re\
ference Guides, Owner’s
Manuals and any updates can also be found in the Owner section of the IN\
FINITI website at
https://owners.infinitiusa.com/iowners/navigation/manualsAndGuides. If you have questions
concerning any information in your Owner’s Manual, contact INFINITI C\
onsumer Affairs. See the
INFINITI CUSTOMER CARE PROGRAM page in the Owner’s Manual for contact\
information.
1727653‎_15b_Infiniti_Q70_QRG_100814.indd 110/8/14 11:35 AM
