Page 542 of 603
Cavity Cartridge FuseMini-FuseDescription
46—10 Amp Red Adaptive Cruise Control – If Equipped
47—10 Amp Red Adaptive Front Lighting – If Equipped
48—20 Amp Yellow Active Suspension / Spare – Police
49——Fuse — Spare
50——Fuse — Spare
51—20 Amp Yellow Front Heated Seats – If Equipped
52—10 Amp Red Heated Cupholders/Rear Heated Seat
Switches – If Equipped
53—10 Amp Red HVAC Module/In Car Temperature
Sensor
54—10 Amp Red Airbag Module
55——Fuse — Spare
56——Fuse — Spare
57——Fuse — Spare
58—10 Amp Red Airbag Module
540 MAINTAINING YOUR VEHICLE
Page 543 of 603
Cavity Cartridge FuseMini-FuseDescription
59—20 Amp Yellow Adjustable Pedals – Police
60——Fuse — Spare
61—20 Amp Yellow Cigar Lighter – If Equipped
62——Fuse — Spare
63——Fuse — Spare
64—25 Amp Clear Rear Windows
65—10 Amp Red Airbag Module
66——Fuse — Spare
67—15 Amp Blue Run Sense
68—15 Amp Blue / 10 Amp Red Illumination/Rear Sunshade/CTR Con-
sole Power Outlet – If Equipped
69——Fuse — Spare
70——Fuse — Spare
7
MAINTAINING YOUR VEHICLE 541
