2015 Citroen C4 display

04
C4-2_en_Chap13b_SMEGplus_ed01-2015
C4-2_en_Chap13b_SMEGplus_ed01-2015
Preset a station
Press on "Preset".
Select   a   radio   station   or   frequency
(refer   to   the   corresponding   section).
Select   a   number   in   the   list   to   preset   the
previously

  chosen   radio   station.
A


long   press   on   a   number   presets   (memorises)
the

  station.
o

r
a press on this button presets all of the stations
one

  after   the   other.
Recall pre-set stations
Press on Media
  to   display   the   primary   page
then select "

Save".
RADIO
302

04
303
C4-2_en_Chap13b_SMEGplus_ed01-2015
C4-2_en_Chap13b_SMEGplus_ed01-2015
RADIO
Activate/ Deactivate RDS
Select "Settings". Press on Media  to   display   the   primary   page
then

  go   to   the   secondary   page.
Select "Radio".
Activate/deactivate
  "RDS options".
RDS,
  if   activated,   allows   you   to   continue   listening   to   the   same
station

  by   automatic   retuning   to   alternative   frequencies.   However,   in
certain

  conditions,   coverage   of   an   RDS   station   may   not   be   assured
throughout

  the   entire   country   as   radio   stations   do   not   cover   100   %   of
the

  territory.
This
  explains   the   loss   of   reception   of   the   station   during
a

  journey.

04
304
C4-2_en_Chap13b_SMEGplus_ed01-2015
C4-2_en_Chap13b_SMEGplus_ed01-2015
RADIO
Display of options:
if   active   but   not   available,   the   display   will   be   greyed   out,
if
  active   and   available,   the   display   will   be   blank. Display
  of   "Radiotext"   for   the
current

  station.
Manage   the   Jukebox.
Display   current   action.
Select   the   audio   source.
Display   the   "DAB"   band.
d
isplay of the
name   of   the   current
station.
Short-cut:
  access   to   the   choice   of
audio

  source   and   the   list   of   stations   (or
titles,

  depending   on   the   source).
Select the radio
station.
If   the   "DAB"   radio   station   being  listened to is not available on
"FM", the "
dab FM" option is
greyed
  out.
Any
  thumbnail   broadcast   by
the

  station.
Preset stations, buttons 1
to 15
Short   press:   select   the
preset

  radio   station.
Long   press:   preset   a   radio
station. Next
  "Multiplex".
Next   radio   station.
Secondary   page.
Display   the   name   and
number

  of   the   multiplex
service

  being   used.
Previous   "Multiplex".
Previous   radio   station.
Journaline
® is a text-based information service designed for digital radio systems.
It

provides

text-based   information   structured   around   topics   and   sub-topics.
This

service   is   available   from   the   "LIST

OF   DAB   STATIONS"   page.

04
305
C4-2_en_Chap13b_SMEGplus_ed01-2015
C4-2_en_Chap13b_SMEGplus_ed01-2015
RADIO
If "DAB / FM auto tracking" is activated, there is a difference of a few  seconds   when   the   system   switches   to   "FM"   analogue   radio   with
sometimes

  a   variation   in   volume.
When
  the   digital   signal   is   restored,   the   system   automatically
changes

  back   to   "DAB".
Select

change

of

source.
Press on Media

to

display

the

primary

page.
Select "DAB Radio".
Select "List"

in

the

primary

page.
or
Select "Radio list"

in

the

secondary

page.
Select

the

radio

station

from

the

list

offered.
Digital

radio

provides

higher

quality

reception

and

also

the

graphical


display

of

current

information

on

the

radio

station

being

listened


to.

Select

"List"

in

the

primary

page.
The

range

of

multiplexes

available

is

displayed

in

alphabetical

order

.
Press Media  to   display   the   primary   page   then
press

  on   the   secondary   page.
Select "Settings".
Select "RADIO".
Select "Digital/FM auto tracking " then
"Confirm". "DAB"   does   not   cover   100%   of   the   territory.
When   the   digital   radio   signal   is   weak,   "DAB / FM   auto   tracking"
allows

  you   to   continue   listening   to   the   same   station,   by
automatically

  switching   to   the   corresponding   "FM"   analogue
station

  (if   there   is   one).
If   the   "DAB"   station   being   listened   to   is   not   available   on   "FM"   ("DAB/
FM"
  option   greyed   out),   or   "DAB / FM   auto   tracking"   is   not   activated,
the

  sound   will   cut   out   while   the   digital   signal   is   too   weak.
Digital radio - DAB / FM auto tracking
DAB (Digital Audio Broadcasting)
Digital radio

04
306
C4-2_en_Chap13b_SMEGplus_ed01-2015
C4-2_en_Chap13b_SMEGplus_ed01-2015
CD, MP3 CD, USB player, auxiliary input
Insert the CD in the player, insert the USB memory  stick   in   the   USB   player   or   connect   the
USB

  peripheral   to   the   USB   port   using   a   suitable
cable

  (not   supplied)
The
  system   builds   playlists   (in   temporary
memory),

  an   operation   which   can   take   from
a

  few   seconds   to   several   minutes   at   the   first
connection.
Reduce

  the   number   of   non-music   files   and   the
number

  of   folders   to   reduce   the   waiting   time.
The
  playlists   are   updated   every   time   the   ignition
is

  switched   off   or   connection   of   a   USB   memory
stick.

  However,   the   system   memorises   these
lists

  and   if   they   are   not   modified,   the   loading
time

  will   be   shorter. Selection of source
The
  steering   mounted
SRC
  (source)   button   can   be   used   to   go   to   the
next

  media   source,   available   if   the   source   is   active.
Press OK
  to   confirm   the   selection.
"CD / CD MP3"
"USB, iPod"
"Bluetooth (streaming)"
"Auxiliary"
"Radio" Select
  change   of   source   then   choose   the
source. Press on
Media   to   display   the   primary   page.
MUSIC

04
307
C4-2_en_Chap13b_SMEGplus_ed01-2015
C4-2_en_Chap13b_SMEGplus_ed01-2015
CD, MP3 CD / USB player
The audio equipment will only play audio files with".wma, .aac, .flac, .ogg  and   .mp3"   file   extensions   and   with   a   bit   rate   of   between   32Kbps
and

  320   Kbps.
It
  also   supports   VBR   (Variable   Bit   Rate)   mode.
No
  other   type   of   file   (.mp4, ...)   can   be   played.
WMA


files   must   be   of   the   standard   wma   9   type.
The
  sampling   rates   supported   are   11,   22,   44   and   48   KHz.
It
  is   advisable   to   restrict   file   names   to   20   characters,   without   using   of
special

  characters   (e.g.:   "   "   ?   ;   ù)   to   avoid   any   playing   and   displaying
problems.
In order to be able to play a recorded C

d R or C d RW, when
recording
  it   is   preferable   to   select   the   ISO   9660   level   1,   2   or   Joliet
standard.
If

  the   disc   is   recorded   in   another   format   it   may   not   be   played
correctly

.
It
  is   recommended   that   the   same   recording   standard   is   always   used
for

  an   individual   disc,   with   as   low   a   speed   as   possible   (4x   maximum)
for

  optimum   sound   quality.
In
  the   particular   case   of   a   multi-session   CD,   the   Joliet   standard   is
recommended. Information and advice The
  system   supports   USB   mass   storage   devices,   BlackBerry®
devices or
a
pple® players via USB ports. The   adaptor   cable   not  supplied.
Control

of

the

peripheral   device   is   with   the   audio   system   controls.
Other

peripherals,   not   recognised   on   connection,   must   be   connected
to


the

auxiliary

socket   using   a   Jack   cable   (not   supplied).
Use

only

USB

memory   sticks   formatted   FAT

32   (28-bit   file   allocation
table).
MUSIC
The system does not support two identical devices connected at the same  time   (two   memory   sticks,   two  Apple® players) but it is possible to

connect

one

memory

stick

and

one
 Apple® player at the same time.
It

is

recommended

that

genuine

Apple® USB cables are used to ensure

correct

operation.

04
C4-2_en_Chap13b_SMEGplus_ed01-2015
C4-2_en_Chap13b_SMEGplus_ed01-2015
Using the auxiliary input (AUX)
(cable not supplied)
Connect the portable device (MP3 player…) to the auxiliary JACK socket  using   an   audio   cable.
First
  adjust   the   volume   of   your   portable   device   (to   a   high   level).
Then

adjust

  the   volume   of   your   audio   system.
Display
  and   management   of   the   controls   are   via   the   portable   device.
Select
  change   the   source.
Select Media
  to   display   the   primary   page.
Select the AUXILIARY
  source.
MUSIC
310

313
C4-2_en_Chap13b_SMEGplus_ed01-2015
C4-2_en_Chap13b_SMEGplus_ed01-2015
Level 1Level 2 Level 3 Comments
Navigation Settings
Navigation Enter destination
Display recent destinations.
Calculatory criteria
Fastest
Choose the navigation criteria.
The   map   displays   the   route   chosen   according   to   these
criteria.
Shortest
Time/distance
Ecological
Tolls
Ferries
Strict - Close
Show
  route   on   map
Display the map and start navigation.
ConfirmSave the options.
SaveSave the current address.
Stop navigationDelete the navigation information.
VoiceChoose the volume for voice and announcement of street names.
DiversionDetour from your initial route by a certain distance.
Navigation
Display in text mode.
Zoom   in.
Zoom
  out.
Display
  in   full   screen   mode.
Use
  the   arrows   to   move   the   map.
Switch
  to   2D   map.
