6. Rotate the backup lamp socket counter clockwise 1/4turn to remove the backup lamp socket from the trunk
lid lamp housing.
Backup Lamp Socket
7. Remove the bulb from the socket and install thereplacement bulb.
8. Install the backup lamp socket into the trunk lid lamp housing.
Inner Deck Panel
7
MAINTAINING YOUR VEHICLE 647

9. Rotate backup lamp socket clockwise 1/4 turn to lockit into place.
10. Reposition the inner deck panel and secure with a push pin if removed.
11. Install access cover.
Backup Lamps (Driver Side)
1. Open trunk lid.
2. Remove the drivers side access cover.
3. Remove inner deck lid support push pin.
NOTE: If necessary remove any additional inner deck lid
trim push pins to gain access.
4. Gently pull back the inner deck panel behind the trunk lid lamp housing to expose the backup lamp socket.
NOTE: passenger side shown the drivers side is similar.
Backup Lamp Socket
5. Rotate the backup lamp socket counter clockwise 1/4
turn to remove the backup lamp socket from the trunk
lid lamp housing.
6. Remove the bulb from the socket and install the replacement bulb.
648 MAINTAINING YOUR VEHICLE

7. Install the backup lamp socket into the trunk lid lamphousing.
8. Rotate backup lamp socket clockwise 1/4 turn to lock it into place.
9. Reposition the inner deck panel and secure with a push pin if removed.
10. Install the access cover.
Stop/Rear Turn Signal Lamp
1. Open the trunk lid.
2. Remove the tail lamp housing beauty cover by grasp- ing the top edge and pulling rearward to expose the
tail lamp housing bolts. 3. Remove the tail lamp housing bolts
Tail Lamp Beauty Cover
7
MAINTAINING YOUR VEHICLE 649

4. Pull the tail lamp housing directly rearward to dis-lodge the two out bored ball studs from the socket
fasteners.
NOTE: It may be necessary to use significant force to
remove the two out bored ball studs from the socket
fasteners to remove the tail lamp housing. 5. Rotate the stop/rear turn signal lamp socket 1/4 turn
counterclockwise and remove it from the tail lamp
housing.
6. Remove the bulb from the socket and install the replacement bulb.
7.
Install the bulb socket into the tail lamp housing and
rotate the bulb socket ¼ turn clockwise to lock it in place.
8. Install the tail lamp housing.
9. Install the tail lamp housing beauty cover.
License Plate Lamp
1. Remove the screw of the license plate lamp assembly and pull down on the license plate lamp assembly to
remove.
2. Remove the bulb from the socket and install the replacement bulb.
3. Install the license plate lamp assembly.
Tail Lamp Bolts
