2015.75 VAUXHALL CORSA glove box

In brief11
1Power windows .....................30
2 Exterior mirrors .....................28
3 Cruise control .....................150
Speed limiter ...................... 152
Forward collision alert ........153
4 Turn and lane-change
signals, headlight flash,
low beam and high beam ....114
Exit lighting ......................... 118
Parking lights ...................... 115
Buttons for Driver
Information Centre ................95
5 Instruments .......................... 83
6 Forward collision alert
indicator ............................. 153
7 Driver Information Centre ...... 95
8 Infotainment controls ...........75
9 Windscreen wiper,
windscreen washer
system, rear window
wiper, rear window washer
system ................................... 7710 Central locking system ..........22
City mode ............................ 149
Fuel selector ......................... 85
Eco button for stop-start
system ................................. 133
Traction Control system .....147
Electronic Stability Control . 148
Parking assist ..................... 156
Seat heating .......................... 39
Heated steering wheel ..........76
11 Anti-theft alarm system
status LED ........................... 26
12 Hazard warning flashers ....114
Control indicator for airbag deactivation .......................... 90
Control indicator for front
passenger seat belt .............89
13 Colour-Info-Display ............101
Graphic-Info-Display ...........102
14 Centre air vents .................. 128
15 Side air vents, passenger
side ..................................... 12816Airbag deactivation switch
(behind glovebox cover) ......47
17 Glovebox .............................. 56
Fuse box ............................ 203
18 Climate control system ........ 120
19 Power outlet .......................... 82
20 AUX input, USB input ...........10
21 Selector lever,
transmission ....................... 141
22 Parking brake ......................146
23 Ignition switch with
steering wheel lock ............131
24 Horn ..................................... 76
Driver airbag ........................ 45
25 Bonnet release lever ..........185
26 Steering wheel adjustment ..75
27 Light switch ........................ 110
Headlight range
adjustment ......................... 112
Rear fog light ...................... 115

56StorageStorageStorage compartments................56
Load compartment .......................67
Roof rack system .........................72
Loading information .....................73Storage compartments9Warning
Do not store heavy or sharp
objects in the storage
compartments. Otherwise, the
storage compartment lid could
open and vehicle occupants could be injured by objects being thrown
around in the event of hard
braking, a sudden change in
direction or an accident.
Glovebox
Pull lever to open the glovebox cover.
The glovebox features a coin holder
and an adapter for the locking wheel
bolts.
The glovebox should be closed whilst
driving.
Cupholders
Cupholders are located in the centre
console.

200Vehicle careElectrical systemFuses
Data on the replacement fuse must
match the data on the defective fuse.
There are two fuse boxes in the
vehicle:
■ in the front left of the engine compartment
■ in left-hand drive vehicles behind the light switch, or, in right-hand
drive vehicles, behind the glovebox
Before replacing a fuse, turn off the
respective switch and the ignition.There are different kinds of fuses in
the vehicle.
Depending on the type of fuse, a
blown fuse can be recognized by its
melted wire. Do not replace the fuse until the cause of the fault has been
remedied.
Some functions are protected by
several fuses.
Fuses may also be inserted without existence of a function.
Fuse extractor A fuse extractor may be located in the fuse box in the engine compartment.
Place the fuse extractor on the
various types of fuse from the top, and
withdraw fuse.

Vehicle care203
No.Circuit1ABS pump2Front wiper3Blower4Instrument panel5–6Diesel fuel heater7Transmission8Cooling fan low9Cooling fan high10Cooling fan11Starter
After having changed defective fuses
close the fuse box cover and press
until it engages.
If the fuse box cover is not closed
correctly, malfunction may occur.
Instrument panel fuse box
The fuse box is located behind a
cover in the glovebox. Open the
glovebox, then open the cover and
fold it down.

220Vehicle care
Alloy wheels with centre cap:
Insert extractor in the open slot of
the centre cap and withdraw the
cap from the wheel. Vehicle tools
3 205.
2. Install the wheel wrench ensuring
that it locates securely and loosen
each wheel bolt by half a turn.
The wheels might be protected by
locking wheel bolts. To loosen
these specific bolts, first attach
the adapter for the locking wheel
bolts onto the head of the bolt
before installing the wheel
wrench. The adapter is located in
the glovebox.
3. Ensure the jack is correctly positioned under the relevant
vehicle jacking point.
On versions with sill panelling or
retrofitted sill panelling, no jack
must be used. The vehicle may be damaged.
4. Set the jack to the necessary height. Position it directly below
the jacking point in a manner that
prevents it from slipping.

255
Control indicators.......................... 87
Control of the vehicle .................130
Controls ........................................ 75
Convex shape .............................. 28
Coolant and antifreeze ...............232
Corner lighting ............................ 113
Cruise control ...................... 94, 150
Cupholders .................................. 56
Curtain airbag system .................. 47
D Danger, Warnings and Cautions ...4
Daytime running lights ...............112
Declaration of conformity ............251
Diesel fuel system bleeding .......191
Diesel particle filter ...............93, 136
Door open .................................... 95
Doors ............................................ 25
Driver assistance systems ..........150
Driver Information Centre .............95
Driving characteristics and towing tips .............................. 177
Driving hints ................................ 130
E Easy entry..................................... 37
Electric adjustment ......................28
Electrical system......................... 200
Electronic climate control system 123Electronic driving programmes .
........................................ 140, 144
Electronic Stability Control.......... 148
Electronic Stability Control and Traction Control system ............92
Electronic Stability Control off....... 92 End-of-life vehicle recovery .......184
Engine compartment fuse box ...201
Engine coolant ........................... 187
Engine coolant temperature gauge ....................................... 85
Engine data ............................... 239
Engine exhaust .......................... 136
Engine identification ...................235
Engine oil ................... 185, 232, 236
Engine oil pressure ......................93
Entry lighting .............................. 118
Event data recorders ..................252
Exit lighting ................................ 118
Exterior care .............................. 227
Exterior light ................................. 94
Exterior lighting ....................12, 110
Exterior mirrors ............................. 28
F
Fault ................................... 140, 145
First aid ......................................... 72
First aid kit ................................... 72
Fixed air vents ........................... 128
Flex-Fix system ............................ 58Fog light ....................................... 94
Fog lights ................................... 195
Folding mirrors ............................. 28
Following distance indication ......155
Forward collision alert................. 153
Front airbag system .....................45
Front fog lights ........................... 115
Front seats.................................... 35
Front storage ................................ 57
Front turn signal lights ...............195
Fuel............................................. 171
Fuel consumption - CO 2-
Emissions ............................... 177
Fuel for diesel engines ..............171
Fuel for liquid gas operation .......172
Fuel for petrol engines ...............171
Fuel gauge ................................... 84
Fuel selector ................................ 85
Fuses ......................................... 200
G Gauges ......................................... 83
Gear shifting ................................. 91
General information ...................177
Glovebox ..................................... 56
Graphic-Info-Display ...................102
H Halogen headlights ....................191
Hand brake ......................... 145, 146
