2015.5 VAUXHALL CORSA buttons

In brief11
1Power windows .....................30
2 Exterior mirrors .....................28
3 Cruise control .....................147
Speed limiter ...................... 149
Forward collision alert ........150
4 Turn and lane-change
signals, headlight flash,
low beam and high beam ....112
Exit lighting ......................... 116
Parking lights ...................... 113
Buttons for Driver
Information Centre ................93
5 Instruments .......................... 82
6 Forward collision alert
indicator ............................. 150
7 Driver Information Centre ...... 93
8 Infotainment controls ...........74
9 Windscreen wiper,
windscreen washer
system, rear window
wiper, rear window washer
system ................................... 7610 Central locking system ..........22
City mode ............................ 146
Eco button for stop-start
system ................................. 131
Parking assist ..................... 153
Seat heating .......................... 38
Heated steering wheel ..........75
11 Anti-theft alarm system
status LED ........................... 26
12 Hazard warning flashers ....112
Control indicator for airbag
deactivation .......................... 88
Control indicator for front
passenger seat belt .............87
13 Colour-Info-Display ..............98
Graphic-Info-Display .............99
14 Centre air vents .................. 126
15 Side air vents, passenger
side ..................................... 126
16 Airbag deactivation switch
(behind glovebox cover) ......46
17 Glovebox .............................. 56
Fuse box ............................ 19618Climate control system ........ 118
19 Power outlet .......................... 81
20 AUX input, USB input ...........10
21 Selector lever,
transmission ....................... 139
22 Parking brake ......................144
23 Ignition switch with
steering wheel lock ............129
24 Horn ..................................... 75
Driver airbag ........................ 44
25 Bonnet release lever ..........178
26 Steering wheel adjustment ..74
27 Light switch ........................ 108
Headlight range
adjustment ......................... 110
Rear fog light ...................... 113
Fuse box ............................ 196
Brightness of instrument
panel illumination ................114

12In briefExterior lighting
Light switch
Turn light switch:
7=lights off8=sidelights9=headlights
Fog lights Press buttons in light switch
>=front fog lightsr=rear fog lightLight switch with automatic light
controlAUTO=automatic light control:
exterior lighting is switched
on and off automaticallym=activation or deactivation of
the automatic light control8=sidelights9=headlights
Automatic light control 3 109.
Headlight flash, high beam and
low beamheadlight flash=pull leverhigh beam=push leverlow beam=push or pull lever
High beam 3 109, Headlight flash
3 109, High beam assist 3 111.

Keys, doors and windows23
Memorised settings 3 22.
Unlocking and opening the tailgate 3 25.
Locking Close doors, load compartment and
fuel filler flap.
Press button e.
If the driver's door is not closed
properly, the central locking system will not work.
Central locking buttons
Locks or unlocks doors, the load
compartment and fuel filler flap from
inside the passenger compartment.
Press the e button to lock.
Press the c button to unlock.
Delayed door lock
Switch off engine and remove key
from the lock. Press the e button with
at least one door opened and three
chimes will sound. When the last door is closed, the vehicle will
automatically lock all doors after
five seconds and a feedback is given.
After 10 minutes, the vehicle will
automatically lock all doors even if a
door is still open. This function may be
activated or deactivated in the Info-
Display. Vehicle personalisation
3 103.
Fault in radio remote control
system
Unlocking
Manually unlock the driver's door by
turning the key in the lock. Switch on
the ignition and press the central
locking button c to unlock the other
doors, load compartment and fuel
filler flap.
By switching on the ignition, the anti-
theft locking system is deactivated.

80Instruments and controls
Set date format
To switch between the available
options, repeatedly press the
MENU-TUNE knob.
RDS clock synchronization
The RDS signal of most VHF
transmitters automatically sets the
time. RDS time synchronisation can
take a few minutes. Some
transmitters do not send a correct
time signal. In such cases, it is
recommended to switch off the
automatic time synchronisation.
To switch between the options On
and Off, repeatedly press the
MENU-TUNE knob.
Colour-Info Display
Press the ; button and then select
the Settings screen button.
Select Time & date settings to display
the respective submenu.
Notice
For a detailed description of menu
operation, refer to the Infotainment
system manual.
Set time format
To select the desired time format, tap
on the screen buttons 12 h or 24 h .
Set date format
To select the desired date format, tap on the < and > screen buttons and
choose between the available
options.
Set time and date
To adjust the time and date settings,
tap on the H and I screen buttons.
RDS clock synchronization
The RDS signal of most VHF
transmitters automatically sets the
time. RDS time synchronisation can take a few minutes. Some
transmitters do not send a correct
time signal. In such cases, it is
recommended to switch off the
automatic time synchronisation.
To activate or deactivate RDS clock
synchronization , tap on the screen
buttons On or Off.

84Instruments and controlsEngine coolant
temperature gauge
Number of LEDs displays the coolant temperature.
up to 3 LEDs=engine operating
temperature not
yet reached4 to 6 LEDs=normal operating
temperaturemore than 6
LEDs=temperature too
highCaution
If engine coolant temperature is
too high, stop vehicle, switch off
engine. Danger to engine. Check
coolant level.
Service display
The engine oil life system lets you
know when to change the engine oil
and filter. Based on driving
conditions, the interval at which an
engine oil and filter change will be
indicated can vary considerably.
To display the remaining engine oil
life duration use turn signal lever
buttons:
Press the MENU button to select the
Vehicle Information Menu .
Turn the adjuster wheel to select Remaining Oil Life .

Instruments and controls93
A vehicle ahead is detected in the
same lane.
Forward collision alert 3 150.
Speed limiter L illuminates in the Driver
Information Centre when Speed
limiter is active. Set speed is indicated near L symbol.
Speed limiter 3 149.
Traffic sign assistant
L displays detected traffic signs as
control indicator.
Traffic sign assistant 3 164.
Door open h illuminates.
A door or the tailgate is open.Information displays
Driver Information Centre The Driver Information Centre (DIC)
is located in the instrument cluster.
Depending on the version and
equipment, the Driver Information
Centre (DIC) is available as Baselevel
display, Midlevel display or Uplevel
display.
Following pages are selectable in the DIC using the buttons on the turn
signal lever:
■ trip odometer 3 82
■ vehicle information and settings, see below
■ trip/fuel information, see below ■ economic information, see below
■ navigation information
Following indication appears if
required:
■ warning messages 3 100
■ gear shift indication 3 89
■ drive mode indication 3 136,
3 140■ tyre pressure warning 3 200
■ seat belt reminder indication 3 87
■ autostop indication 3 131
■ service information 3 89
Baselevel-Display
Select subpages by turning the
adjuster wheel on turn signal lever.
Selectable subpages are:
■ engine oil life indication
■ tyre pressure indication
■ tyre loading
■ unit setting

94Instruments and controls
■language setting, if no Infotainment
system is available
■ clock, if no Infotainment system is available
■ outside temperature, if no Infotainment system is available
Some of the displayed functions differ when the vehicle is being driven or at
a standstill.
Midlevel display
The menu pages of the Midlevel
display are selected by pressing the
MENU button on the turn signal lever.
Selectable menu pages of Midlevel
display are:
■ Trip menu, see below
■ Vehicle menu, see below
Some of the displayed functions differ when the vehicle is being driven or at
a standstill. Some functions are only
available when the vehicle is being
driven.
Uplevel-DisplayThe menu pages of the Uplevel
display are selected by pressing the
MENU button on the turn signal lever.
Main menu symbols are indicated in
the top line of the display:
■ Trip menu, see below
■ Vehicle menu, see below
■ Eco menu, see below
Some of the displayed functions differ when the vehicle is being driven or at
a standstill. Some functions are only
available when the vehicle is being
driven.
Selecting menus and functions
The menus and functions can be
selected via the buttons on the turn
signal lever.

116LightingReading lights
Operated with 2 buttons for left and
right side.
Lighting features
Entry lighting
Welcome lighting
The following lights are switched on
for a short time by unlocking the
vehicle with the radio remote control:
■ headlights
■ tail lights
■ number plate lights
■ instrument panel light
■ interior lights
Some functions are only operable
when it is dark outside to facilitate locating the vehicle.
The lighting switches off immediately
when the ignition key is turned to
position 1 3 129.
Activation or deactivation of this
function can be changed in the
Info-Display.
Vehicle personalisation 3 103.
The settings can be saved for the key being used 3 22.The following lights will additionally
switch on when the driver's door is
opened:
■ all switches
■ Driver Information Centre
Exit lighting
The following lights switch on if the
key is removed from the ignition
switch:
■ interior lights
■ instrument panel light (only when it is dark)
They will switch off automatically after
a delay and will be activated again if
the driver's door is opened.
Path lightingHeadlights, tail lights and number
plate lights illuminate the surrounding
area for an adjustable time after
leaving the vehicle.
