Instruments and controls
Berlingo-2-VP_en_Chap03_Pret-a-partir_ed02-2015
Under-inflation alert
This is given by fixed illumination  of   this   warning   lamp, accompanied

  by   an   audible   signal
 and,

  depending   on   equipment,
 the

  display   of   a   message.
Before
  reinitialising   the   system,
ensure that the pressures of
the four tyres are correct for the
use of the vehicle and in line with the
recommendations

  on   the   tyre   pressure
label.
The

  under-inflation   alert   can   only   be
relied on if the reinitialisation of the
system

  has   done   with   the   pressures   in
the

  four   tyres   correctly   adjusted.
The
  under-inflation   detection   system
does not give a warning if a pressure is
incorrect

  at   the   time   of   reinitialisation.
The loss of pressure detected
does not always cause visible
bulging
  of   the   tyre.   Do   not   satisfy
yourself

  with   just   a   visual   check. The
  alert   is   maintained   until   the
system

  is   reinitialised.
F

Reduce
  speed   immediately,   avoid
excessive

  steering   movements   and
sudden

  braking
F

Stop the vehicle as soon as it is
safe

  to   do   so. F
In the event of a puncture, use
the
  temporary   puncture   repair   kit
or the spare wheel (depending on
equipment),
or
F


if
  you   have   a   compressor,   such   as
the

  one   in   the   temporary   puncture
repair

  kit,   check   the   pressures   of
the four tyres when cold,
or
F


if
  it   is   not   possible   to   make   this
check

  immediately,   drive   carefully
at

  reduced   speed.
Reinitialisation
It is necessary to reinitialise the system every  time   one   or   more   tyre   pressures
are

  adjusted,   and   after   changing   one
or

  more   wheels.
A


label   attached   to   the   middle   pillar,
driver's

  side,   gives   a   reminder   of   this.

45
Berlingo-2-VP_en_Chap03_Pret-a-partir_ed02-2015
Instruments and controls
Berlingo-2-VP_en_Chap03_Pret-a-partir_ed02-2015
Reinitialisation of the system must be done with the ignition on and the vehicle
stationary:
-

in
  the   vehicle   configuration   menu   for   vehicle   fitted   with   a   display   screen,
-

using
  the   button   on   the   dashboard,   for   vehicles   without   display   screen.
Screen A
F

Press the
MENU button for access
to
  the   main   menu.
F

Press the "
5" or "6" button to
select
  the   menu   Veh config, then
confirm
  by   pressing   the   OK   button.
F

Press the "
5" or "6" button to
select the "Reinit inflat",
  menu,
then

  confirm   by   pressing   the   OK
button.
 A

message   is   displayed   to   confirm
the

  instruction.
F

Confirm
  by   pressing   the   OK   button.Screen C
F

Press the
MENU button for access
to
  the   main   menu.
F

Press the "
5" or "6" button to
select the "Personalisation-
configuration"
  menu,   then   confirm
by pressing the

OK   button.
F

Press the "
5" or "6" button
to select the "Define vehicle
parameters"
  menu,   then   confirm
by pressing the

OK   button.
F

Press the "
5" or "6" button to
select the "Tyre pressures"
  menu,
then the "

Reinitialisation"   menu,
then

  confirming   by   pressing   the
OK

 button.
 A

message   confirms   the
reinitialisation.T

ouch screen tablet
F

Press the
MENU   button.
F

Select the "
Driving"   menu.
F

In the secondary page, select
"

Under-inflation initialisation".
A


message   is   displayed   to   confirm   the
reinitialisation

  instruction.
F

Select "
Ye s" or "No",
  then   confirm.
 A

message   confirms   the
reinitialisation.
REadY To Go
3

47
Berlingo-2-VP_en_Chap03_Pret-a-partir_ed02-2015
Instruments and controls
Berlingo-2-VP_en_Chap03_Pret-a-partir_ed02-2015
SERVICE INDICATOR
This programmes service intervals according  to   the   use   of   the   vehicle.More than 1 000 miles/km before the
next service is due
Example:
  4   800   miles/km   remain
before

  the   next   service   is   due.   When
the ignition is switched on and for a
few

  seconds,   the   screen   shows:
a few seconds after the ignition is
switched on, the oil level is displayed
(depending on version), then the total
distance

  recorder   resumes   normal
operation showing the total and trip
distances.
Less than 1 000 miles/km before the
next service is due
Each time the ignition is switched on and for a few seconds,  the   spanner   flashes   and   the   number   of miles/kilometres

  remaining   is   displayed:
a few seconds after the ignition is
switched on, the oil level is displayed
(depending on version), then the total
distance
  recorder   resumes   normal
operation

  and   the   spanner   remains   on.
This indicates that a service should be
carried

  out   shortly.
Service overdue
Operation
A


few

moments

after

the

ignition

has been switched on, the spanner
indicating


a

service

operation

comes

on; the display for the total distance
recorder


gives

(in

round

figures)

the

distance


remaining

before

the

next

service.
The points at which a service is due
are


calculated

from

the

last

indicator

zero


reset.
The point at which a service is due is
determined

by

two

parameters:
-

the distance travelled,
-


the


time

which

has

elapsed

since

the


last

service.
The

distance

remaining

before

the

next


service

may

be

weighted

by

the


time

factor,

depending

on

the

type


of

driving. With the engine running the spanner
remains
  on   until   the   service   has   been
carried

  out.
For BlueH
d i d iesel versions, this
alert
  is   also   accompanied   by   the   fixed
illu

mination   of   the   Service   warning
lamp,

  on   switching   on   the   ignition.
Each
  time   the   ignition   is
switched on and for a few
seconds, the spanner
flashes

  and   the   excess
distance

  is   displayed.
For BlueH
d i d iesel versions, the
spanner
  can   also   come   on   early,
according the level of deterioration
of

  the   engine   oil.   Deterioration   of   the
engine oil depends on the conditions of
use

  of   the   vehicle.
REadY To Go
3

48
Berlingo-2-VP_en_Chap03_Pret-a-partir_ed02-2015
Instruments and controls
Berlingo-2-VP_en_Chap03_Pret-a-partir_ed02-2015
Trip recorder zero
reset button
after this operation, if you wish to
disconnect   the   battery,   lock   the
vehicle

  and   wait   for   at   least   five
minutes,

  otherwise   the   zero   re-set   will
not


be   registered.
Engine oil level indicator
depending on your vehicle's engine,
when the ignition is switched on,
the engine oil level is indicated for
a few
seconds, after the service
information. Oil level
correct
Low oil level
Flashing of "OIL",
linked
  with   the
service

  warning   lamp,
accompanied

  by   an
audible

  signal   and   a   message   in   the
screen, indicates a low oil level which
could

  damage   the   engine.
If   the   low   oil   level   is   confirmed   by   a
check

  using   the   dipstick,   it   is   essential
that

  the   level   is   topped   up.
Oil level gauge fault
Flashing of "OIL--"
indicates a
malfunction   of   the
engine oil level
indicator
.   Contact   a   CITROËN   dealer
or

  a   qualified   workshop.
The level read will only be correct
if the vehicle is on level ground
and the engine has been off for
more   than   30   minutes.Dipstick
A
  =   maximum,   never   exceed
this level as a surplus of oil
may

  damage   the   engine.
Contact a CITR o Ë n dealer
or   a   qualified   workshop
without

  delay.
B
=

minimum,

top

up

the

level

via

  the   oil   filler   cap,   using   the
grade of oil suited to your
engine.
Lighting dimmer
With the ignition on, press
the button until the zeros
appear.
With the lighting on,
press the button to vary
the brightness of the
instruments
  and   controls.
When the lighting
reaches

  the   minimum   (or
maximum)


setting,   release   the   button
then press it again to increase (or
reduce)


the

brightness.
a

s soon as the lighting is of the
required

brightness,   release   the   button.
Zero reset
Your CITROËN dealer or a qualified workshop  carries   out   this   operation
after

  each   service.
However, if you carry out the service
yourself, the re-set procedure is as
follows:
-

switch of
f the ignition,
-

press and hold the trip recorder
reset button,
-


switch
  on   the   ignition.
The
  display   begins   a   countdown.
When the display shows "=0", release
the
  button;   the   spanner   disappears.

54
Berlingo-2-VP_en_Chap03_Pret-a-partir_ed02-2015Berlingo-2-VP_en_Chap03_Pret-a-partir_ed02-2015
Going into engine START mode
The "ECO" warning lamp goes  off   and   the   engine   starts:
- with a manual gearbox , when you
fully depress the clutch pedal,
-

with
a 6-speed electronic
gearbox:
●

gear
  lever   in   position   A or M,
when
  you   release   the   brake
pedal,
●


or
  gear   lever   in   position   N and
the
  brake   pedal   released,   when
you

  move   the   gear   lever   to
position

A or M,
●

or
  when   you   engage   reverse
gear

.
With
  a   manual   gearbox   in   STOP
 mode,

  if   a   gear   is   engaged   without
fully depressing the clutch pedal, a
warning

  lamp   comes   on   or   a   message
is

  displayed   asking   you   to   depress   the
clutch

  pedal   to   restart   the   engine.Special cases: START invoked
automatically
For
  your   safety   and   comfort,   START

is
invoked

  automatically   when:
-
you open the driver's door
,
-
you unfasten the driver's seat belt,
-
the speed of the vehicle exceeds
15
  mph   (25   km/h)   with   a   manual
gearbox

  or   7   mph   (11   km/h)   with
the

  6-speed   electronic   gearbox
system,
-


some
  special   conditions   (battery
charge,

  engine   temperature,
braking

  assistance,   ambient
temperature...)

  where   the   engine
is needed to assure control of a
system.In this case the

"ECO"
warning
  lamp   flashes   for
few seconds,

  then   goes   off.
This operation is perfectly normal.
Deactivation
At any time, press the "ECO
OFF" switch to deactivate the
system.
This

is

confirmed   by   the   switch   warning
lamp


coming   on   accompanied   by   a
message

  in   the   screen.
If

the

system   has   been   deactivated
in


STOP


mode,   the   engine   restarts
immediately

.
Reactivation
Press the "ECO OFF" switch again.
The   system   is   active   again;   this   is
confirmed

  by   the   switch   warning
lamp

  going   off   and   a   message   in   the
instrument

  panel.
The
  system   is   reactivated
automatically

  at   every   new   start
using

  the   key.
Operating fault
In the event of a malfunction with  the   system,   the   "ECO
OFF"
  switch   warning   lamp
flashes,

  then   comes   on
continuously

.
have

it

checked   by   a   CITROËN   dealer
or


a

qualified   workshop.
In

the

event   of   a   fault   in   STOP

mode,
the


vehicle   may   stall.
All
  of   the   warning
lamps


in

the   instrument   panel   come
on.


It

is

then   necessary   to   switch   off
the ignition and start the engine again
using


the
  key.
Stop & Start

 63
Berlingo-2-VP_en_Chap04_Ergonomie_ed02-2015
TRIP COMPUTER
A

few definitions
Range: displays the distance which
can  travelled   with   the   remaining   fuel
detected

  in   the   tank,   basd   on   the
average

  consumption   over   the   last   few
miles

  (kilometres).
This
  displayed   value   may   vary
significantly

  following   a   change   in   the
vehicle

  speed   or   the   relief   of   the   route.Current fuel consumption:
only
calculated and displayed above
20   mph   (30   km/h).
Average fuel consumption: this is the
average   fuel   consumption   since   the
last

  trip   computer   zero   reset.
Distance travelled: calculated since
the   last   trip   computer   zero   reset.
Distance remaining to the
destination: calculated with reference to
the   final   destination,   entered   by   the   user.
 If guidance is activated, the navigation


system   calculates   it   as   a   current   value.
Average speed: this is the average
speed calculated since the last trip
computer
  zero   reset   (ignition   on).
Each press of the button, located at
the

end

of

the

wiper

stalk,

displays

the

dif

ferent

trip

computer

information

in

turn,


depending

on

the

screen.
When the required trip is displayed,
press  the   control   for   more   than
two seconds. When
  the   range   falls   below   20   miles
(30

  km),   dashes   are   displayed.
After

fillin

g   with   at   least   10   litres   of   fuel,   the
range is recalculated and is displayed
when

  it   exceeds   60   miles   (100   km).
If, whilst driving, dashes are displayed
continuously in place of the digits,
contact   a   CITROËN   dealer.
The "vehicle" tab with the range,
current

fuel

consumption

and

the
 remaining

distance

to

run.
The "1" tab (trip 1) with the average
speed,

the

average

fuel

consumption

and the distance travelled in trip

"1".
The

"2"

tab

(trip

2)

with

the

same

information


for

a

2
nd trip.
Reset
Steering mounted controls
EASE OF USE and COMFORT
4

64
Berlingo-2-VP_en_Chap04_Ergonomie_ed02-2015
CRUISE CONTROL
"CRUISE"
"This is the speed at which the driver
wishes  to   drive".
This
  aid   to   driving   in   free-flowing
traffic

  enables   the   vehicle   to   maintain
the

  speed   programmed   by   the   driver,
unless

  a   steep   gradient   makes   this
impossible.
For

  the   system   to   be   programmed   or
activated,

  the   vehicle   speed   must   be
greater

  than   25   mph   (40   km/h)   with
4th gear

  or   higher   engaged. The
  state   of   the   cruise   control   system
can

  be   seen   in   the   instrument   panel
together

  with   the   the   programmed
speed

  setting.
Function selected,
display of the "Cruise
Control"   symbol.
Function off,
OFF
Function   on.
Vehicle speed above,
the   programmed
speed

  flashes.
o

perating fault
detected,
OFF - the dashes
flash.
1.
 Cruise

control

mode

On

/

Off.
2.

Reduce


cruise

speed

setting.
3.

Increase


cruise

speed

setting.
4.

Pause


/

Resume

cruise

control.
Steering mounted controls

 67
Berlingo-2-VP_en_Chap04_Ergonomie_ed02-2015
The speed of the vehicle responds to
the pressure of the driver's foot, up
to the the accelerator pedal's point of
resistance, which indicates that the
programmed  speed   has   been   reached.
However, pressing the pedal beyond
this
  point   of   resistance   to   the   floor
allows

  the   programmed   speed   to   be
exceeded.


T
o   resume   use   of   the   limiter,
simply

  reduce   the   pressure   on   the
accelerator pedal gradually and return
to

  a   speed   below   that   programmed.
Adjustments can be carried out
when stationary, with the engine
running, or with the vehicle moving. This
  speed   limiter   shows   the   function
selection

  status   in   the   instrument   panel
and

  displays   the   programmed   speed:SPEED LIMITER
"LIMIT"
Function selected,
displaying of the
"Speed
  Limiter"
symbol.
Function of

f,
last
  programmed
speed -

OFF.
Function
  on.
Vehicle speed above,
the
  programmed
speed setting is
displayed

  flashing.
o

perating fault
detected,
OFF - the dashes
flash.
1.

Limiter


mode

On

/

Off.
2.

Reduce


programmed

speed

setting.
3.


Increase


programmed

speed

setting.
4.


Speed


limiter

On

/

Pause.
"This is the selected speed which the
driver

does

not

wish

to

exceed".
This

selection

is

made

with

the

engine
 running while stationary or with the vehicle


moving.

The


minimum

speed

which

can
 be


programmed

is

20

mph

(30

km/h).
Steering mounted controls
EaSE oF USE and CoMFoRT
4
