PERIODIC MAINTENANCE AND ADJUSTMENT
6-17
1
2
3
4
56
7
8
9
EAU21385
Checking the throttle grip free
playThe throttle grip free play should mea-
sure 3.0–5.0 mm (0.12–0.20 in) at the
inner edge of the throttle grip. Periodi-
cally check the throttle grip free play
and, if necessary, have a Yamaha
dealer adjust it.
EAU21402
Valve clearanceThe valve clearance changes with use,
resulting in improper air-fuel mixture
and/or engine noise. To prevent this
from occurring, the valve clearance
must be adjusted by a Yamaha dealer
at the intervals specified in the periodic
maintenance and lubrication chart.
EAU51972
TiresTires are the only contact between the
vehicle and the road. Safety in all con-
ditions of riding depends on a relatively
small area of road contact. Therefore, it
is essential to maintain the tires in good
condition at all times and replace them
at the appropriate time with the speci-
fied tires.
Tire air pressure
The tire air pressure should be checked
and, if necessary, adjusted before each
ride.
WARNING
EWA10504
Operation of this vehicle with im-
proper tire pressure may cause se-
vere injury or death from loss of
control.
The tire air pressure must be
checked and adjusted on cold
tires (i.e., when the temperature
of the tires equals the ambient
temperature).

The tire air pressure must be ad-
justed in accordance with the
riding speed and with the total
1. Throttle grip free play
1
59C-9-E2.book 17 ページ ２０１３年６月１８日　火曜日　午後１時３３分

PERIODIC MAINTENANCE AND ADJUSTMENT
6-37
1
2
3
4
56
7
8
9
EAU42505
Troubleshooting chartsStarting problems or poor engine performance
Check the fuel level in
the fuel tank.1. Fuel
There is enough fuel.There is no fuel.
Check the battery.
Supply fuel.
The engine does not start.
Check the battery.
Remove the spark plugs
and check the electrodes.3. Ignition
Wipe off with a dry cloth and correct the
spark plug gaps, or replace the spark plugs.
Have a Yamaha dealer check the vehicle.
Operate the electric starter.4. Compression
There is compression.
There is no compression.
The engine does not start.
Have a Yamaha dealer check the vehicle.Have a Yamaha dealer check the vehicle.
The engine does not start.
Check the compression.
Operate the electric starter.2. Battery
The engine turns over
quickly.
The engine turns over
slowly.
The engine does not start.
Check the ignition.
The battery is good.Check the battery lead connections,
and have a Yamaha dealer charge
the battery if necessary.
DryWet
Operate the electric starter.
59C-9-E2.book 37 ページ ２０１３年６月１８日　火曜日　午後１時３３分

PERIODIC MAINTENANCE AND ADJUSTMENT
6-38
2
3
4
567
8
9
Engine overheating
WARNING
EWAT1041

Do not remove the radiator cap when the engine and radiator are hot. Scalding hot fluid and steam may be
blown out under pressure, which could cause serious injury. Be sure to wait until the engine has cooled.

Place a thick rag, like a towel, over the radiator cap, and then slowly rotate the cap counterclockwise to the de-
tent to allow any residual pressure to escape. When the hissing sound has stopped, press down on the capwhile turning it counterclockwise, and then remove the cap.
TIPIf coolant is not available, tap water can be temporarily
used instead, provided that it is changed to the recommended coolantas soon as possible.
Wait until the
engine has cooled.
Check the coolant level in the
reservoir and radiator.
The coolant level
is OK.The coolant level is low.
Check the cooling system
for leakage.
Have a Yamaha dealer checkand repair the cooling system.Add coolant. (See TIP.)
Start the engine. If the engine overheats again,
have a
Yamaha dealer check
and repair the cooling system.
There is
leakage.
There is
no leakage.
59C-9-E2.book 38 ページ ２０１３年６月１８日　火曜日　午後１時３３分

SCOOTER CARE AND STORAGE
7-4
2
3
4
5
678
9
stabilizer (if available) to prevent
the fuel tank from rusting and the
fuel from deteriorating.
3. Perform the following steps to pro- tect the cylinders, piston rings, etc.
from corrosion.
a. Remove the spark plug caps and the spark plugs.
b. Pour a teaspoonful of engine oil into the spark plug bores.
c. Install the spark plug caps onto the spark plugs, and then place
the spark plugs on the cylinder
head so that the electrodes are
grounded. (This will limit spark-
ing during the next step.)
d. Turn the engine over several times with the starter. (This will
coat the cylinder walls with oil.)
e. Remove the spark plug caps from the spark plugs, and then
install the spark plugs and the
spark plug caps. WARNING!
To prevent damage or injury
from sparking, make sure to
ground the spark plug elec-
trodes while turning the en-
gine over.
[EWA10952]
4. Lubricate all control cables and the pivoting points of all levers and
pedals as well as of the sidestand/
centerstand.
5. Check and, if necessary, correct the tire air pressure, and then lift
the scooter so that both of its
wheels are off the ground. Alterna-
tively, turn the wheels a little every
month in order to prevent the tires
from becoming degraded in one
spot.
6. Cover the muffler outlet with a plastic bag to prevent moisture
from entering it.
7. Remove the battery and fully charge it. Store it in a cool, dry
place and charge it once a month.
Do not store the battery in an ex-
cessively cold or warm place [less
than 0 C (30 F) or more than 30
 C (90 F)]. For more information
on storing the battery, see page
6-28.
TIPMake any necessary repairs beforestoring the scooter.
59C-9-E2.book 4 ページ ２０１３年６月１８日　火曜日　午後１時３３分

INDEXAABS (for ABS models) .............................3-15
ABS warning light (for ABS models) ..........3-3
Acceleration and deceleration....................5-3
Air filter element, replacing ......................6-15
Auxiliary light bulb, replacing ...................6-35BBattery......................................................6-28
Brake fluid, changing ...............................6-24
Brake fluid level, checking .......................6-23
Brake lever, front......................................3-13
Brake lever, rear ......................................3-14
Brake levers, lubricating...........................6-25
Braking .......................................................5-3CCables, checking and lubricating .............6-24
Care ...........................................................7-1
Catalytic converter ...................................3-19
Centerstand and sidestand, checking and lubricating .......................................6-26
Coolant.....................................................6-14DDimmer switch .........................................3-12
Drive belt slack.........................................6-24EEngine break-in ..........................................5-4
Engine idling speed..................................6-16
Engine oil and oil filter cartridge ...............6-11
Engine stop switch ...................................3-13
Engine trouble warning light.......................3-3FFront and rear brak e lever free play,
checking ................................................6-20
Front and rear brake pads, checking .......6-22 Front fork, checking ................................. 6-26
Fuel.......................................................... 3-17
Fuel consumption, tips
for reducing........... 5-4
Fuel tank cap ........................................... 3-16
Fuses, replacing ...................................... 6-30
HHandlebar switches ................................. 3-12
Hazard switch .......................................... 3-13
Headlight bulb, replacing ......................... 6-32
Helmet holder .......................................... 3-21
High beam indicator light ........................... 3-3
Horn switch .............................................. 3-13IIdentification numbers ............................... 9-1
Ignition circuit cut-off system ................... 3-26
Immobilizer system .................................... 3-1
Immobilizer system indicator light.............. 3-4
Indicator lights and warning lights ............. 3-3LLicense plate light bulb, replacing ........... 6-34MMain switch/steering lock........................... 3-2
Maintenance and lubrication, periodic ....... 6-4
Maintenance, emission control system...... 6-3
Matte color, caution ................................... 7-1
Model label ................................................ 9-1
Multi-function display ................................. 3-5PPanels, removing and installing ................. 6-8
Parking ...................................................... 5-5
Part locations ............................................. 2-1
Pass switch.............................................. 3-12RRear brake lock cable, adjusting ............. 6-21 Rear brake lock, checking ....................... 6-21
Rear brake lock lever .............................. 3-15
Rear view mirrors .................................... 3-25
Rider backrest, adjusting......................... 3-20
SSafe-riding points ...................................... 1-5
Safety information ..................................... 1-1
Seat ......................................................... 3-19
Shock absorber assembly ....................... 3-25
Sidestand ................................................ 3-26
Spark plugs, checking ............................. 6-10
Specifications ............................................ 8-1
Speedometer............................................. 3-5
Starting off ................................................. 5-2
Starting the engine .................................... 5-1
Start switch.............................................. 3-13
Steering, checking................................... 6-27
Storage...................................................... 7-3
Storage compartments ............................ 3-21TTachometer ............................................... 3-5
Tail/brake light ......................................... 6-33
Throttle grip and cable, checking and
lubricating ............................................. 6-25
Throttle grip free play, checking .............. 6-17
Tires ........................................................ 6-17
Tool kit....................................................... 6-2
Troubleshooting ...................................... 6-35
Troubleshooting charts............................ 6-37
Turn signal indicator lights ........................ 3-3
Turn signal light bulb (f ront), replacing .... 6-33
Turn signal switch ................................... 3-12VValve clearance....................................... 6-17
