2014 VOLKSWAGEN JETTA GLI Owners Manual

A confirmation message appears in the display. Confirm request with the OK button on the multi-function steering wheel.
Switch off the emergency flashers.
Do not reset the service reminder between service intervals; otherwise incorrect information will be displayed.
The service reminder disappears after a few seconds or the OK button on the multi-function steering wheel has been pushed.

Volkswagen Information System

Menu structure – overview

Back
– Factory setting
– Back
▪ Lights & Vision
– Conv. turn sig. (convenience turn signal)
– Factory setting
– Back
▪ Time
– Hours
– Minutes
– 24 hr. mode
– Daylight save
– Back
▪ Snow tires (winter tires)
– On
– + 5 mph
– - 5 mph
– Back
▪ Compass (vehicles without navigation system)
– Zone
– Calibrate
– Back
▪ Units
– Temperature
– Consump./dist.
– Back
▪ Service
– Info
– Back
▪ Factory setting
Using the instrument cluster menus

Fig. 14 Right side of the multi-function steering wheel: Controls for menus in the instrument cluster.

The instrument cluster menus are controlled with buttons on the right side of the steering wheel
⇒ fig. 14.
Accessing the instrument cluster menus
x Switch on the ignition. You will see the vehicle icon or a message in the instrument cluster display.
x Push the OK button on the right side of the multi-function steering wheel until a main menu appears in the instrument cluster display. For a list of main menus, see Menu structure – overview, Menu structure – overview.
x Push buttons # or ∃ to move to another main menu, and push the arrow up and down buttons * and +to navigate inside the current main menu. For example, in the Settings main menu, press the arrow down button + to navigate to the MFI data submenu.
Displaying a submenu
x Press the OK button to display submenu items. For instance, after scrolling to MFI data in the Settings main menu, press the OK button to display items available under the MFI data submenu.
Selecting a setting
x Some menus are used to select settings for certain features. Push the OK button to select a setting.
x Use the arrow up and down buttons * and +on the multi-function steering wheel to navigate through the available options.
x The selected menu item is located between the 2 horizontal lines. There may also be a triangle (Å) on the right.
x Push the OK button to select the setting.
Returning to the main menu
x Via menu: Use the arrow down button + to select Back and then press the OK button .
x For operation with multi-function steering wheel: Press E
Main menu

Menu Function See
Vehicle status
Current warning and information messages. This menu item is only displayed when warning or infor-mation messages are available. The number of available messages is shown in the display. Example: 1/1 or 2/2.
Settings Includes the Convenience and Lights & Vision submenus, as well as many settings such as time, speed warning for winter tires, language, and units.

MFI menu (Multi-Function Indicator)

Display Function
Av. consumption --.- l/100 km about 330 feet (100 m). Until then, dashes appear instead of a number. The value displayed is updated every 5 seconds.
Range  -- mi Estimated distance in miles (km) that the vehicle can go with the fuel left in the tank the way you are currently driving. Takes account of the cur-rent fuel consumption, among other things. Range  -- km
Route -- mi Distance driven in miles (km) per trip memories 1 and 2 (toggle). Route -- km
Average speed -- mph Average speed on trips per trip memories 1 and 2 (toggle). Displayed once the vehicle has been driven about 300 feet (100 m). Until then, dashes may appear instead of a number. The value displayed is updated every 5 seconds. Average speed -- km/h
-- mph Digital display of the current vehicle speed. -- km/h
Speed warning --- mph When the set speed (from 20–155 mph or 30–250 km/h) is exceeded, an acoustic warning sounds and a visual message may also appear in the instrument cluster display. Speed warning --- km/h
Switching between the displays
x Use the arrow up and down buttons (* and +) on the multi-function steering wheel.
Storing speed for the speed warning
x Select the Speed warning -- mph or Speed warning -- km/h display.
x Press the OK button to save the current speed and to activate the warning.
x If the speed is not right, press buttons * or + on the multi-function steering wheel to set a different speed within about 5 seconds. Then press the OK button a second time or just wait a few seconds. The speed is saved and the warning is activated.
x To deactivate, toggle to --- mph or --- km/h and press the OK button. The set speed is deleted.
Manually erasing trip memory 1 or 2
x Navigate to MFI > Route.
x Select the memory to be erased.
x Press the OK button for about 2 seconds.
Enabling and disabling displays
Use the Settings menu, submenu MFI data to enable displays you want to be available under the MFI menu in the instrument cluster display. The units in which data is displayed can also be changed, Settings menu, Settings menu.
Settings menu

Settings menu Function
LanguageSet the language for messages in the display and navigation system.
MFI data Select the features you want to have displayed in the MFI menu in the instrument cluster display
Convenience Convenience function settings.
Lights & Vision Vehicle lighting settings
Time Set hours and minutes for the instrument cluster clock and the Radio & Navigation System clock. The time can be displayed in 12 or 24 hour format, and can also be set to daylight savings time.
Snow tires Set up a visual and acoustic speed warning. Use the feature only when winter tires are installed that have a speed rating less than top vehicle speed.
Compass Calibrate the compass on vehicles without a factory-installed navigation system. To calibrate, follow the instructions in the instrument cluster display
Units Set the units in which temperature, fuel consumption, and distances should be displayed (for example, whether to show distance driven in miles or kilometers).
Service View the service reminder display
Factory setting Reset the functions in the Settings menu back to the factory settings.
Convenience submenu
