2014 VOLKSWAGEN EOS Owners Manual

WARNING
Heavy loads will influence the way your vehicle handles and increase stopping distances. Heavy loads that are not properly stowed or secured can cause loss of control and serious injury.
x Secure the load properly to keep it from shifting.
x Always remember when transporting heavy objects that a change in the center of gravity also changes the way your vehicle handles:
– Always distribute the load as evenly as possible.
– Secure heavy objects properly as far forward in the luggage compartment as possible.
– Always tie down heavy items securely with suitable straps in the luggage compartment.
x Never exceed the Gross Axle Weight Rating or the Gross Vehicle Weight Rating on the safety compliance sticker on the left door jamb. Exceeding permissible weight can cause the vehicle to skid and handle differently.
x Always adapt your speed and driving to the heavier load and the weight distribution in the vehicle. Take road, weather, traffic, and visibility conditions into account as well.
x Always accelerate gently and avoid sudden braking and driving maneuvers.
x Always brake earlier than you would if you were not driving a loaded vehicle.
NOTICE
x When the CSC roof opens (goes down), it folds completely into the luggage compartment. The open CSC roof fills all the space above and on both sides of the cover that is installed inside the luggage compartment. When the CSC roof opens and retracts, it must be able to lower itself completely into the luggage compartment without any interference.
x When you put the roof down, items
– to the left or right of the luggage compartment cover,
– on top of the luggage compartment cover, or
– above the level of the luggage compartment cover at the rear of the vehicle will prevent the roof from folding up completely in the luggage compartment and will damage the CSC roof. Damage to the CSC roof caused by items in those areas of the luggage compartment where the CSC roof segments are stored when retracted will not be covered by any Volkswagen Limited Warranty.
x The heating wires in the rear window can be severely damaged by hard or sharp things in the area below the rear window.

Stowing luggage

Fig. 96 Luggage compartment cover in the luggage compartment.

Luggage compartment cover

Fig. 97 Lifting up the inside luggage compartment cover.

Fig. 98 Removing the inside luggage compartment cover.

Lowering the luggage compartment cover
x Using handle (A), pull back slightly on the luggage compartment cover to release the hooks from the tabs.
x Lower the cover and push it completely into its latches (magnified view), so that these engage.
Removing the luggage compartment cover
x Lift the cover up.
x Pull the latch ⇒ fig. 98 (magnified view) in the direction of the arrow to release the hinge.
x Raise the left side of the luggage compartment cover until the left locking pin lifts out of the attachment.
x Pull the luggage compartment cover slightly to the left to pull the right locking pin out of its attachment.
x Remove the luggage compartment cover. It is now impossible to open and close the CSC roof.
Installing the luggage compartment cover
To install the luggage compartment cover, perform the steps for removal in reverse order.
In order to open or close the CSC roof, the luggage compartment cover must be down and
locked in place in its latches ⇒ fig. 97 (inset).
Driving with an open luggage compartment lid

WARNING
Driving with an open luggage compartment lid can cause poisonous carbon monoxide in the engine exhaust to get into the passenger compartment.
x Carbon monoxide causes drowsiness, inattentiveness, poisoning, and loss of consciousness. It can lead to accidents and severe personal injuries.
x Always keep the luggage compartment lid closed while driving to help keep poisonous exhaust fumes from being drawn into the vehicle.
x Never transport objects that are too large to fit completely into the luggage area, because then the luggage compartment lid cannot be fully closed.
x If you absolutely must drive with the CSC roof closed and an open luggage compartment lid, do the following to reduce the risk of carbon monoxide poisoning:
– Close all windows, the CSC roof, and the sunroof.
– Switch off the climate control system's air recirculation feature.
– Open all air vents in the instrument panel.
– Set the fresh air fan to the highest speed.
NOTICE
The open luggage compartment lid changes the vehicle height.
Driving a loaded vehicle

WARNING
Heavy loads can change the way your vehicle handles and increase stopping distances. Heavy loads that are not properly stowed or secured can shift suddenly, causing loss of control and serious injury.
x Secure the load properly to keep it from shifting.
x Always remember when transporting heavy objects that they change the vehicle's center of gravity and also the way it handles.
– Always distribute the load as evenly as possible.
– Secure heavy objects as far forward in the luggage compartment as possible.
x Always tie down heavy items securely with suitable straps.
x Never exceed the Gross Axle Weight Rating or the Gross Vehicle Weight Rating on the safety compliance sticker on the left door jamb. Exceeding permissible weight can cause the vehicle to skid and handle differently.
x Always adapt speed and driving to the heavier load and the weight distribution in the vehicle. Take road, weather, traffic, and visibility conditions into account as well.
x Always accelerate gently and avoid sudden braking and driving maneuvers.
x Always brake earlier than you would if you were not driving a loaded vehicle.
Weights and axle weights

WARNING
Exceeding maximum permissible weight ratings can result in vehicle damage, accidents, and serious personal injury.
x Never let the actual weights at the front and rear axles exceed the permissible Gross Axle Weight Rating. Also, never let the total of these actual weights exceed the Gross Vehicle Weight Rating.
x Always remember that the vehicle's handling and braking will be affected by extra load and the distribution of this load. Adjust your speed accordingly.
NOTICE
x Always distribute the load evenly and as low as possible in the vehicle. The vehicle capacity weight figures apply when the load is distributed evenly in the vehicle (passengers and luggage).
x When transporting a heavy load in the luggage compartment, carry the load as close to the rear axle (as far forward) as possible so that the vehicle's handling and braking are affected as little as possible.

Luggage compartment
