2014 VOLKSWAGEN BEETLE Owners Manual

Lower center console

Fig. 8 Overview of the lower center console.
Key to fig. 8:
(1) Lever for:
– Manual transmission
– Automatic transmission
(2) Parking brake lever
(3) Storage compartment with cup holders in the center console
(4) Storage compartment
(5) Starter button for the Keyless Access locking and starting system (if equipped)
(6) Center armrest with storage compartment (if equipped)
(7) 12 Volt socket

Applicable only in the United States
Front passenger side overview

Fig. 9 Overview of the front passenger side.
Key to fig. 9:
(1) Passenger front airbag location in the instrument panel (approximate)
(2) Opening handle for the upper glove compartment (if equipped)
(3) Air vents  –

(3) Air vents  –

Symbols on the roof console

Symbol Meaning
* / s   Interior and reading lights
g c h Power sunroof

/ a 3-button module (if equipped) ⇒ booklet Mobile Phone Package

Instrument cluster

WARNING
Driving on today's roads demands the full attention of the driver at all times. Driver distrac-tion causes accidents, collisions and serious personal injury!
x Never set the stopwatch when the vehicle is moving.
NOTICE
To help prevent engine damage, always avoid high engine speeds, full throttle acceleration and heavy engine loads when the engine is cold.
The digital clock is set using the buttons in the instrument cluster, Instrument overview.
Displays and warning lights (Basic version)

Fig. 13 In the instrument cluster display (examples): A: Open engine hood, B: Open rear hatch, C: Open driver door.
