2014 VOLKSWAGEN BEETLE light

The illustrations show the left headlight. The right headlight is the mirror image.
Replacing light bulbs in the front bumper

Fig. 173 In front left bumper: Removing the light assembly.

Fig. 174 Replacing light bulbs in the front bumper.

Please carry out each step only in the order specified:
Turn signal ⇒ fig. 174 (2) Front fog light / Cornering light (4)
6. Release the connector (1) and pull it off. Use the flat blade of the screwdriver from the vehicle tool kit, if necessary.
Release the connector (3) and pull it off.
7. Turn the bulb holder (2) as far as it goes to the left and pull it out together with the light bulb to the rear.
Turn the bulb holder (4) as far as it goes to the left and pull it out together with the light bulb to the rear.
8. Replace the burned out light bulb with a new bulb of the same type.
9. Insert the bulb holder in the headlight and turn it all the way to the right.
10. Attach the connector (1) to the bulb holder (2). The connector must latch with a “click.” Attach the connector (3) to the bulb holder (4). The connector must latch with a “click.”
11. Slide the two light assemblies together (if necessary) and slip the headlight into the mounts (small arrows) and fold rearward.
12. Tighten the fastening screw ⇒ fig. 173 (1) and (2) with the screwdriver.
13. Beginning at the outside, insert the cover into the bumper opposite the direction of the arrow .
The illustrations show the left headlight. The right headlight is the mirror image.
Different models may have different lights, and the location and design of covers, bulb holders, and bulbs may be in a different location than shown in the illustrations.
Replacing light bulbs in the front bumper (Beetle R-Line)

Fig. 175 In the left side of the front bumper: Removing the headlight.

Fig. 176 Replacing the bulb in the headlight.

Replacing taillight bulbs in the vehicle body

Fig. 178 In the side of luggage compartment: A: Open cover of the rear side panel. B: Removing the taillight assembly.

Fig. 179 Taillights: A: Removing the bulb holder. B: Removing the taillight bulbs.

Changing the light bulb

7. Unscrew the fastening screws ⇒ fig. 179 A (arrows) with the Phillips screwdriver from the vehicle tool kit
8. Remove the bulb holder from the taillight.
9. Replace the burned out light bulb with a new bulb of the same type B (arrows).
10. Insert the bulb socket into the taillight. Screw the fastening screws A (arrows) with the Phillips screwdriver from the vehicle tool kit
Installing the taillight

11. Carefully insert the taillight into the opening in the body.
12. Hold the taillight with one hand in the installation position and with the other hand, tighten
the taillight fastening screw ⇒ fig. 178 B (1).
13. Check for proper installation and secure fit of the taillight.
14. Plug connector plug B (4) into the bulb socket and push red locking tab B (2) in the direction opposite to the arrow.
15. Replace the side interior trim of the luggage compartment. Reinstall the subwoofer, if necessary
16. Close the rear hatch
Taillights with LEDs have a “standard” light bulb for the turn signal. This bulb can be replaced.
Different models may have different lights, and the location and design of covers, bulb holders, and bulbs may be in a different location than shown in the illustrations.
Replacing license plate light bulbs

Fig. 180 In the rear bumper: License plate light.

Fig. 181 License plate light: Removing the bulb holder.

Before removing the jumper cables
x Switch off the headlights (if they are on).
x In the vehicle with the dead battery, switch on the heater fan and the rear window defroster. This helps to minimize voltage spikes when the cables are disconnected.
Removing jumper cables
With the engine running, remove the jumper cables in reverse order to the way they were connected.
1. Disconnect the black (-) cable from the vehicle with the dead battery.
2. Disconnect the black (-) cable from the other vehicle (vehicle with the good battery).
3. Disconnect the red (+) cable from the other vehicle (vehicle with the good battery).
4. Disconnect the red (+) cable from the vehicle with the dead battery.
5. Close the battery cover.
6. If necessary, unscrew the towing eye on the front of the vehicle, Installing the front towing eye.
WARNING
Improper use of jumper cables when jump-starting a vehicle with a dead battery can cause the battery to explode, leading to serious personal injury. To help reduce the risk of battery explosion:
x All work on the batteries or the electrical system in your vehicle can cause serious acid burns, fires, or electrical shocks. Always read and heed the following WARNINGS and safety precautions before working on the batteries or the electrical system, Vehicle battery.
x Always wear proper eye protection. Never lean over the vehicle battery.
x Attach the jumper cables in the correct order: first the positive cable, then the negative cable.
x Never connect the negative cable from the vehicle providing starting assistance to parts of the fuel system or to the brake hoses or brake lines.
x Never allow the non-insulated parts of the battery clamps to touch.
x Never allow the jumper cable attached to the positive battery terminal to contact metal parts of the vehicle.
x Check the battery acid level indicator window on the vehicle battery. Use a flashlight, never a match, cigarette lighter, or other open flame. If you cannot see the color of the window clearly, or if it is light yellow or colorless, do not jump-start the vehicle. Get expert assistance.
x Avoid electrostatic discharge in the vicinity of the vehicle battery. Sparks may cause the hydrogen gas escaping from the vehicle battery to ignite.
x Never jump-start a vehicle with a battery that is damaged or frozen or that was frozen and has thawed. The battery can explode. Replace the battery instead.
x Always follow the instructions of the jumper cable manufacturer.
x Always make sure that the battery providing starting assistance has the same voltage as the dead battery (12 V) and about the same capacity (see battery label).
x Batteries give off explosive hydrogen gas. Always keep fire, sparks, open flame and smoking materials away from batteries.
x Never connect the negative cable from the other vehicle directly to the negative terminal of the dead battery. The hydrogen gas from the battery is explosive.
x Never short out the battery terminals by connecting the positive (+) and negative (-) terminals with each other.

Abbreviations
Abbreviation Meaning
5S man 5-speed manual transmission
6S auto 6-speed automatic transmission
6S man 6-speed manual transmission
ABS Anti-lock Brake System
AKI Anti-Knock Index
ANSI American National Standards Institute
ASR Anti-Slip Regulation
ATA Anti-Theft Alarm system
BAS Brake Assist System
ccm Cubic centimeter – metric unit of measure for engine displacement
CCS Cruise Control System
CID Cubic inch displacement – unit of measure for engine displacement
cm Centimeter – metric unit of measure for length
CO2 Carbon dioxide
DIN Deutsches Institut für Normung (German Institute for Standardization)
DPF Diesel Particulate Filter
DRL Daytime Running Lights
DSG® Direct Shift Gearbox automatic transmission
EDL Electronic Differential Lock
EN European Norm
EPC Engine control (Electronic Power Control)
ESC Electronic Stability Control
g/km Generated carbon monoxide amount in grams per kilometer driven
GAWR Gross Axle Weight Rating
