2014 VOLKSWAGEN BEETLE light

Color Current strength in amps(ATO/MINI) Current strength in amps(JCASE)
Red 10 50
Blue 15 20
Yellow 20 60
White or clear 25 —
Green 30 40
Orange 40 —
Pink 30 30
Opening the fuse box in the instrument panel
x Open the storage compartment ⇒ fig. 164, Storage areas.
x On the back of the cover there are plastic tweezers for removing and inserting fuses.
x Press the sides of the storage compartment in slightly ((A) arrows) while pulling back firmly ((B) arrow).
x To install, guide the cover from the bottom into the instrument panel and push in the direction opposite to the arrows (A), then push forward until you can hear it latch into place.
Opening the fuse box in the engine compartment
x Open the engine hood

Replacing light bulbs

WARNING
Improper replacement of burned out headlights and other light bulbs can cause serious personal injury.
x Stop! Always read and heed the WARNINGS before doing any work in the engine
compartment ,Working in the engine compartment. The engine compartment of any motor vehicle is a potentially dangerous area, and work in this area can lead to serious personal injury.
x HID – High Intensity Discharge (Xenon) headlights get power from a high voltage source that can cause severe personal injury and even death if handled improperly.
x HB2 (H4) bulbs and HID – High Intensity Discharge (Xenon) headlights are under high pressure and can explode if handled improperly.
x Always let a burned out light bulb cool down before replacing it.
x Never replace a light bulb unless you are familiar with all of the necessary procedures. In particular, never remove a headlight unless you know exactly how to carry out the job and have the correct tools and light bulbs.
x If you are uncertain about what to do, have the work performed by an authorized Volkswagen dealer, an authorized Volkswagen Service Facility, or another qualified workshop. Serious personal injury may result from improperly performed work.
x We strongly recommend that you always have HID – High Intensity Discharge (Xenon) headlights and HB2 (H4) bulbs replaced by a qualified technician.
x Do not touch the glass of light bulbs with your bare hands. Fingerprints left on the bulb evaporate due to the heat when the bulb is switched on and cause the reflector to “cloud.”
x There are sharp edges on and around the headlight housing in the engine compartment and the rear light housing. Wear hand protection if you replace bulbs.
NOTICE
After replacing a headlight bulb or other light bulb, always make sure that the rubber covers or plastic caps have been properly and securely reinstalled to help prevent water from getting into the electrical connections and headlight housing and damaging the electrical system.
You cannot replace the LEDs in LED daytime running lights. Contact your authorized Volkswagen dealer or an authorized Volkswagen Service Facility for assistance.
Indicator light

WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
Failure of a single LED within a taillight is not indicated. However, the = indicator light will come on if all LEDs fail.
Information on light bulb replacement

WARNING
Disregarding the safety-related checklist may lead to accidents and serious personal injuries.
x Always review and follow the checklist. Follow accepted safety practices and use common sense.
NOTICE
Always insert and remove lamps carefully to help prevent damage to the vehicle paint or to other parts of the vehicle.
Replacing headlight bulbs - removing the headlight assembly

Fig. 168 In the engine compartment: Release lever for the left headlight.

Different models may have different lights, and the location and design of covers, bulb holders, and bulbs may be in a different location than shown in the illustrations.
You cannot replace the LEDs in LED daytime running lights. Contact your authorized Volkswagen dealer or an authorized Volkswagen Service Facility for assistance.
Replacing headlight bulbs - after removing the headlight assembly

Fig. 169 Left headlight assembly: 1 Cover in the headlight assembly, 2 low beam and high beam headlights, 3 parking light, and daytime running light.

Fig. 170 In the headlight: Reinstalling the bulb holder for the parking light/daytime running light.

Please carry out each step only in the order specified:
⇒ fig. 169 (2)(3)
Low beam headlights / high beam headlights Parking lights / daytime running lights
1. Please review and follow the checklist
2. Open the engine hood

Reinstalling the headlight assembly

Fig. 171 Anchors 1 and connector plug 2 of the left headlight assembly.

Fig. 172 In the engine compartment: Release lever for the left headlight.
