148Vehicle careElectrical systemFuses
Data on the replacement fuse must
match the data on the defective fuse.
There are two fuse boxes in the
vehicle:
■ on the left-hand side of the instrument panel, behind the trim
panel.
■ in the engine compartment located below the coolant expansion tank.
Before replacing a fuse, turn off the
respective switch and the ignition.
A blown fuse can be recognised by its melted wire. Do not replace the fuse
until the cause of the fault has been
remedied.
It is advisable to carry a full set of
fuses. Consult a workshop.
Some functions are protected by
several fuses.
Fuses may also be inserted without
existence of a function.
Fuse extractor

Vehicle care149
To help in replacing fuses, a fuse
extractor is located in the instrument
panel fuse box.
Place the fuse extractor on the
various types of fuse from the top or
side, and withdraw fuse.
Engine compartment fusebox
Located below the coolant expansion tank.
Some circuits may be protected by
several fuses.
Due to restricted accessibility, have
fuses replaced by a workshop.SymbolCircuitSRight side lightsTLeft side lightsWRight low beamaLeft low beam>Front fog lightLLeft high beamNRight high beamuABSKWindscreen wipernAir conditioningVHeated windscreenInstrument panel fuse box
Located behind the trim panel on the
left-hand side of the instrument panel. Pull upper part of trim panel to
remove.
Do not store any objects behind this
panel.
Some circuits may be protected by
several fuses.

168Service and maintenanceRecommended fluids,lubricants and parts
Recommended fluids and
lubricants
Only use products that meet the
recommended specifications.
Damage resulting from the use of
products not in line with these
specifications will not be covered by
the warranty.9 Warning
Operating materials are
hazardous and could be
poisonous. Handle with care. Pay
attention to information given on
the containers.
Engine oil
Engine oil is identified by its quality
and its viscosity. Quality is more
important than viscosity when
selecting which engine oil to use. The oil quality ensures e.g. engine
cleanliness, wear protection and oil
aging control, whereas viscosity
grade gives information on the oil's
thickness over a temperature range.
Dexos is the newest engine oil quality
that provides optimum protection for
diesel engines. If it is unavailable,
engine oils of other listed qualities
have to be used.
Select the appropriate engine oil based on its quality and on the
minimum ambient temperature
3 173.
Topping up engine oil
Engine oils of different manufacturers and brands can be mixed as long as
they comply with the required engine
oil quality and viscosity.
Use of engine oil with only
ACEA A1/B1 or only A5/B5 quality is
prohibited, since it can cause long-
term engine damage under certain
operating conditions.
Select the appropriate engine oil
based on its quality and on the
minimum ambient temperature
3 173.Additional engine oil additives
The use of additional engine oil
additives could cause damage and
invalidate the warranty.
Engine oil viscosity grades
The SAE viscosity grade gives
information of the thickness of the oil.
Multigrade oil is indicated by two
figures, e.g. SAE 5W-30. The first
figure, followed by a W, indicates the
low temperature viscosity and the
second figure the high temperature
viscosity.
Select the appropriate viscosity grade depending on the minimum ambient
temperature 3 173.
All of the recommended viscosity grades are suitable for high ambient
temperatures.
Coolant and antifreeze
Use only silicate-free long life coolant
(LLC) antifreeze approved for the
vehicle, consult a workshop.
The system is factory filled with
coolant designed for excellent
corrosion protection and frost

195
Climate control systems...............94
Clock ............................................ 71
Control indicators.......................... 76
Control of the vehicle .................106
Controls ........................................ 68
Convex shape .............................. 30
Coolant ....................................... 135
Coolant and antifreeze ...............168
Coolant heater ............................ 100
Cornering light ......................89, 142
Coupling ball bar ........................130
Cruise control ...................... 82, 121
Cupholders .................................. 61
D Danger, Warnings and Cautions ...3
Dashboard .................................... 10
Daytime running lights .................88
Declaration of conformity ............191
Diesel fuel filter .......................... 138
Diesel fuel system bleeding .......139
Diesel particle filter ...............81, 112
Door open .................................... 82
Doors ............................................ 24
Drain fuel filter ............................. 81
Driver assistance systems ..........121
Driver Information Centre .............83
Driving characteristics and towing tips .............................. 129
Driving hints ................................ 106E
Electric adjustment ......................30
Electrical system......................... 148
Electronic climate control system 96
Electronic driving programmes ..116
Electronic Stability Program 80, 120
Emergency exit ............................. 34
End-of-life vehicle recovery .......133
Engine compartment fuse box ...149
Engine coolant ........................... 135
Engine coolant temperature ........80
Engine coolant temperature gauge ....................................... 74
Engine data ............................... 174
Engine exhaust .......................... 112
Engine identification ...........171, 172
Engine oil ................... 134, 168, 173
Engine oil level monitor ................74
Engine oil pressure ......................81
Event data recorders ..................191
Exhaust gases ............................ 112
Exit lighting .................................. 92
Exterior care .............................. 164
Exterior light ................................. 82
Exterior lighting ......................12, 87
Exterior mirrors ............................. 30F
Fault ........................................... 117
Fire extinguisher ..........................65
First aid ......................................... 65
First aid kit ................................... 65
Fixed air vents ........................... 104
Fog light ....................................... 82
Fog lights .............................. 89, 143
Folding mirrors ............................. 30
Front airbag system .....................49
Front fog lights ............................. 89
Front seats.................................... 36
Front storage ............................... 61
Front turn signal lights ...............143
Fuel consumption - CO 2-
Emissions ............................... 128
Fuel for diesel engines ..............127
Fuel gauge ................................... 74
Fuse box ..................................... 149
Fuses ......................................... 148
G Gauges ......................................... 73
General information ...................129
Glass panel .................................. 34 Glovebox ..................................... 61
Glovebox cooler ......................... 104
