2014 VAUXHALL COMBO Owner's Manual

In brief7Seat adjustmentSeat positioning
Pull handle, slide seat, release
handle.
Seat position 3 33, Seat adjustment
3 33.
9 Danger
Do not sit nearer than 25 cm from
the steering wheel, to permit safe
airbag deployment.
Seat backrests
Turn handwheel. Do not lean on
backrest when adjusting.
Seat position 3 33, Seat adjustment
3 33.
Seat height
Lever pumping motion
up=higherdown=lower
Operate lever and adjust body weight
on seat to raise or lower it.
Seat position 3 33, Seat adjustment
3 33.

8In briefHead restraint adjustment
Press release catch, adjust height,
engage.
Head restraints 3 32.
Seat belt
Pull out the seat belt and engage in
belt buckle. The seat belt must not be twisted and must fit close against the
body. The backrest must not be tilted
back too far (maximum approx. 25 ° ).
To release belt, press red button on belt buckle.
Seat position 3 33, Seat belts
3 38, Airbag system 3 41.
Mirror adjustment
Interior mirror
Adjust the lever on the underside to
reduce dazzle.
Interior mirror 3 28.

In brief9
Exterior mirrors
Swivel lever in required direction.
Select the relevant exterior mirror by
turning the control to left _ or right 6.
Then swivel the control to adjust the
mirror.
In position o no mirror is selected.
Convex exterior mirrors 3 27,
Electric adjustment 3 27, Folding
exterior mirrors 3 28, Heated
exterior mirrors 3 28.
Steering wheel adjustment
Unlock the lever, adjust the steering
wheel, then engage lever and ensure it is fully locked.
Do not adjust steering wheel unless
vehicle is stationary and the steering
wheel lock has been released.
Airbag system 3 41, Ignition
positions 3 102.

10In briefInstrument panel overview

In brief11
1Fixed air vents ..................... 100
2 Side air vents ........................ 99
3 Light switch .......................... 88
Turn and lane-change
signals, headlight flash,
low beam and high beam .....90
4 Instruments .......................... 67
Driver Information Centre ...... 79
5 Windscreen wiper,
windscreen washer
system, rear window
wiper/washer ........................ 62
Trip odometer reset ............... 67
6 Centre air vents .................... 99
7 Headlight range
adjustment ........................... 89
Driver Information Centre
controls ................................ 79
Trip computer ........................ 86
Instrument illumination ..........91
Hazard warning flashers .......90
Front fog lights .....................90Rear fog light ........................ 91
Heated rear window ..............31
Heated exterior mirrors .........28
8 Front passenger airbag ........44
9 Glovebox .............................. 54
10 Climate control system .......... 95
Electronic climate control
system ................................... 97
11 Selector lever, manual
transmission ....................... 107
Manual transmission
automated ........................... 108
12 Ignition switch with
steering wheel lock ............102
13 Steering wheel controls .......61
14 Horn ..................................... 62
Driver airbag ........................ 44
15 Steering wheel adjustment ..61
16 Cruise control .....................115
17 Fuse box ............................. 140
18 Bonnet release lever ..........127Exterior lighting
Turn light switch:
§=off / daytime running lights9=sidelights / headlights
Lighting 3 88, Daytime running
lights 3 89.

12In brief
Fog lights
Press light switch:
>=front fog lightsr=rear fog lightHeadlight flash, high beam and
low beamheadlight flash=pull leverhigh beam=push leverlow beam=pull lever
High beam 3 88, Headlight flash
3 88.
Turn and lane-change signalslever up=right turn signallever down=left turn signal
Turn and lane-change signals
3 90.

In brief13
Hazard warning flashers
Operated with the ¨ button.
Hazard warning flashers 3 90.
Horn
Press j.
Washer and wiper systems
Windscreen wiper
Twist lever:
§=offÇ=intermittent wipingÈ=slowÉ=fast
For a single wipe when the
windscreen wiper is off, move the
lever up.
Windscreen wiper 3 62, Wiper
blade replacement 3 131.

14In brief
Windscreen and headlight
washer systems
Pull lever.
Windscreen and headlight washer
system 3 62, Washer fluid 3 129.
Rear window wiper and washer
systems
Twist band to activate the rear
window wiper.
The rear window wiper comes on
automatically when the windscreen
wiper is switched on and reverse gear
is engaged.
Push lever: Washer fluid is sprayed
on the rear window and the wiper
wipes a few times.
Rear window wiper/washer 3 63.
Climate control
Heated rear window, heatedexterior mirrors
The heating is operated by pressing
the Ü button.
Heated rear window 3 31.
