519 5-2. Steps to take in an emergency
When trouble arises
*1: Driver’s and front passenger’s seat belt reminder:
The driver’s and front passenger’s seat belts reminder sounds to alert the
driver and front passenger that their seat belts are not fastened. The buzzer
sounds for 30 seconds after the vehicle has reached a speed of at least
20 km/h (12 mph). Then, if the seat belts are still unfastened, the buzzer will
sound in a different tone for 90 more seconds.
*2: Rear passenger’s seat belt reminders:
The rear passenger’s seat belt reminder sounds to alert the rear passenger
that his or her seat belt is not fastened. The buzzer sounds for 30 seconds
after the vehicle has reached a speed of at least 20 km/h (12 mph). Then, if
the seat belt is still unfastened, the buzzer will sound in a different tone for
90 more seconds.
*3: 5-passenger models
*4: 7-passenger models
Front passenger detection sensor and passenger seat belt reminder
If luggage is placed on the front passenger seat, the front passenger
detection sensor may cause the warning light to flash, even if a passen-
ger is not sitting in the seat.
If a cushion is placed on the seat, the sensor may not detect a passen-
ger, and the warning light may not operate properly.
When the tire pressure warning light comes on (vehicles with a tire
pressure warning light system)
Inspect the appearance of the tire to check that the tire is not punctured.
If the tire is punctured: P. 536, 552
If the tire is not punctured:
Carry out the following procedure after the tire temperature has lowered suffi-
ciently.
Check the tire inflation pressure and adjust to the appropriate level.
If the warning light does not go out even after several minutes, check that
the tire inflation pressure is at the specified level and carry out initialization.
The warning light may come on again if the above operations are conducted
without first allowing the tire temperature to lower sufficiently.
VERSO_WE.book Page 519 Thursday, June 19, 2014 11:31 AM

630 6-2. Customization
Smart entry
& start
system
(P. 42)/
Wireless
remote
control
(P. 64)Wireless remote
controlON OFF—O
Operation signal
(Emergency flashers)ON OFF—O
Time elapsed before
automatic door lock
function is activated
if door is not opened
after being unlocked30 seconds60 seconds
—O
120 seconds
Door lock
(P. 73)Shifting the shift
lever to position
other than “P” locks
all doors
*1
OFF ONOO
Shifting the shift
lever to “P” unlocks
all doors
*1OFF ONOO
Speed-detecting
automatic door lock
functionON OFFOO
Opening driver’s
door unlocks all
doors
*2ON OFF—O
Opening driver’s
door unlocks all
doors
*3OFF ON—O
Automatic
light control
system
(P. 251)Light sensor
sensitivityLevel 3 Level 1 to 5OO
ItemFunctionDefault
settingCustomized
setting
VERSO_WE.book Page 630 Thursday, June 19, 2014 11:31 AM

631 6-2. Customization
6
Vehicle specifications
Illumination
(P. 365)Time elapsed before
lights turn off15 seconds7.5 seconds
—O
30 seconds
Operation after the
engine switch
(vehicles without
smart entry & start
system) or “ENGINE
START STOP”
switch (vehicles with
smart entry & start
system) turned offON OFF—O
Operation when the
doors are unlockedON OFF—O
Operation when you
approach the
vehicle with the
electronic key on
your person
*4
(When the interior
light switch is in the
door position)ON OFF—O
Foot lights ON OFF—O
Lounge illumination ON OFF—O
Lights
(P. 251)Time that the low
beam headlights are
on when the vehicle
is parked30 seconds60 seconds
—O 90 seconds
120 seconds
Toyota
parking
assist-sensor
(P. 272)Buzzer volume 3 1 to 5—O
ItemFunctionDefault
settingCustomized
setting
VERSO_WE.book Page 631 Thursday, June 19, 2014 11:31 AM

641 Alphabetical index
Hooks
Cargo hooks.......................... 392
Horn .......................................... 227
Identification
Engine ................................... 602
Vehicle .................................. 601
Ignition
Engine switch ................ 196, 200
Ignition switch ............... 196, 200
Keys ........................................ 38
Ignition switch.................. 196, 200
Illuminated entry system......... 368
Immobilizer system ................. 124
Indicator lights ......................... 233
Initialization
Items to initialize ................... 633
Tire pressure warning
system ................................ 444
Inside rear view mirror ............ 105
Instrument panel light
control .................................... 232
Intercooler ................................ 433
Intrusion sensor....................... 138
Interior lights
Interior lights ................. 366, 367
Switch ........................... 366, 367
Wattage................................. 624
Jack
Positioning a floor jack .......... 418
Replacing the wheel.............. 536
Vehicle-equipped
jack ............................. 536, 552
Jack handle ...................... 536, 552Keyless entry ....................... 42, 64
Keys
Electronic key ......................... 38
Engine switch................ 196, 200
If the electronic key does not
operate properly ................. 582
If you lose your keys ............. 580
Ignition switch ............... 196, 200
Key number plate.................... 38
Keyless entry .................... 42, 64
Keys ........................................ 38
Mechanical key ....................... 38
Wireless remote control key ... 64
Knee airbag .............................. 147
License plate lights
Replacing light bulbs............. 484
Switch ................................... 251
Wattage ................................ 624
Light bulbs
Replacing .............................. 484
Wattage ................................ 624
Lights
Door courtesy lights .............. 365
Emergency flasher switch ..... 502
Fog light switch ..................... 258
Foot lights ............................. 365
Front door courtesy lights ..... 365
Hazard light switch................ 502
Headlight switch.................... 251
Luggage compartment light .... 80
Personal/interior light
switch ......................... 366, 367
Replacing light bulbs............. 484
Turn signal lever ................... 224
Vanity lights .......................... 379
Wattage ................................ 624
I
J
K
L
VERSO_WE.book Page 641 Thursday, June 19, 2014 11:31 AM

644 Alphabetical index
Switch
Airbag manual on/off ............. 177
Emergency flasher switch ..... 502
Engine switch ................ 196, 200
Fog light switch ..................... 258
Hazard light switch ................ 502
Ignition switch ............... 196, 200
Light switches ....................... 251
Power door lock switch ........... 73
Power window switches ........ 112
Rear window wiper and
washer switch ..................... 264
“SPORT” mode
switch.......................... 207, 213
Stop & Start cancel switch .... 281
Tire pressure warning
reset switch......................... 445
Window lock switch ............... 112
Wipers and washer
switch.......................... 259, 264
Tachometer .............................. 228
Tail lights
Replacing light bulbs ............. 484
Switch ................................... 251
Wattage................................. 624
Theft deterrent system
Alarm..................................... 136
Double locking system .......... 134
Engine immobilizer system ... 124
Intrusion sensor .................... 138
Tire inflation pressure ............. 457
Tire pressure warning
system .................................... 444
Function ................................ 444
Initializing .............................. 445
Installing tire pressure
warning valves and
transmitters ......................... 444
Registering ID codes............. 447Tire pressure warning
reset switch ........................ 445
Warning light ......................... 517
Tires
Chains................................... 299
Checking ............................... 443
Emergency tire puncture
repair kit.............................. 552
If you have a flat
tire .............................. 536, 552
Inflation pressure .................. 457
Replacing .............................. 536
Rotating tires......................... 443
Size ....................................... 621
Snow tires ............................. 298
Spare tire .............................. 536
Tire pressure warning
system ................................ 444
Tools................................. 536, 552
Towing
Emergency towing ................ 504
Trailer towing ........................ 302
Toyota parking
assist-sensor ......................... 272
Traction control ....................... 287
Trailer towing ........................... 302
Transmission shift
switches ......................... 206, 212
TRC ........................................... 287
Trip information display.......... 240
Trip meter ................................. 228
Turn signal lights
Replacing light bulbs............. 484
Switch ................................... 224
Wattage ................................ 624
T
