2014 TOYOTA TUNDRA turn signal

4537-3. Do-it-yourself maintenance
7
Maintenance and care
■When installing the rubber cover of the headlight
Ensure the rubber cover is securely attached.
■ When replacing the light bulbs
Confirm that they are properly engaged with the bulb base and that there is
no light leakage.
■ LED Lights
The parking lights (LED type), daytime running light (LED type) and side turn
signal lights consist of a number of LEDs. If any of the LEDs burn out, take
your vehicle to your Toyota dealer to have the light replaced.
■ Condensation build-up on the inside of the lens
Temporary condensation build-up on the inside of the headlight lens does not
indicate a malfunction. Contact your Toyota dealer for more information in the
following situations:
●Large drops of water have built up on the inside of the lens.
● Water has built up inside the headlight.Fit the rubber cover outer circumfer-
ence in firmly.
Fit the rubber cover around the light
bulb in until the light bulb plug can be
seen.
1
2

4568-1. Essential information
Emergency flashers
Press the switch.
All the turn signal lights will flash.
To turn them off, press the switch
once again.
■Emergency flashers
If the emergency flashers are used for a long time while the engine is not
operating, the battery may discharge.
The emergency flashers are used to warn other drivers when the
vehicle has to be stopped in th e road due to a breakdown, etc.

5159-1. Specifications
9
Vehicle specifications
*1: If equipped
*2: Bulb type only
A: HB2 halogen bulbs
B: H16 halogen bulbs
C: Wedge base bulbs (amber)
D: Wedge base bulbs (clear)
E: Double end bulbs
Light bulbs
Light BulbsBulb No.WTy p e
Exterior Headlights HB2 60/55 A
Front fog lights
*1H16 19 B
Front side marker lights W5W 5 D
Front turn signal lights/
parking lights
*2/
daytime running lights
*1, 24157NAK 28/8 C
Rear turn signal lights 921 16 D
Stop/tail and rear side
marker lights 3157KX 27/8 D
Back-up lights 7440 21 D
License plate lights W5W 5 D
High mounted stoplight and
cargo lamp 921 16 D
Outer foot light — 5 D
InteriorVanity lights 7065 5 E
Personal/interior lights
Front
Rear W5W
W5W5
5D
D
Foot well lighting — 1.4 D

565Alphabetical index
FFV .................................... 196, 516
Flat tire...................................... 475
Flex-fuel ............................ 196, 516
Flexible fuel vehicle......... 196, 516
Floor mats .................................. 28
FluidAutomatic transmission......... 512
Brake .................................... 513
Washer ................................. 416
Fog lights ................................. 192
Replacing light bulbs............. 447
Switch ................................... 192
Wattage ................................ 515
Foot well light .......................... 353
Four-wheel drive system ........ 226
Front passenger occupant classification system .............. 50
Front personal lights ............... 354
Front seats ............................... 113 Adjustment ............................ 113
Cleaning................................ 394
Correct driving posture ........... 30
Driving position memory ....... 118
Head restraints ..................... 122
Power easy access system ......... ....................... 118
Seat heaters ......................... 350
Seat position memory ........... 118
Seat ventilators ..................... 350
Front side marker lights Light switch ........................... 189
Replacing light bulbs............. 445
Wattage ................................ 515 Front turn signal lights
Replacing light bulbs ............ 444
Turn signal lever ................... 186
Wattage ................................ 515
Fuel ........................................... 508 Capacity................................ 508
Fuel gauge.............................. 88
Fuel pump shut off system ... 463
Gas station information......... 576
Information............................ 516
Refueling .............................. 196
Type.............................. 196, 508
Warning light......................... 466
Warning message................. 474
Fuel consumption Average fuel
consumption ................... 92, 94
Current fuel consumption ....... 94
Fuel filler door ......................... 198
Fuel pump shut off system..... 463
Fuses ........................................ 436
Garage door opener ................ 381
Gas station information .......... 576
Gauges ....................................... 88
Glove box ................................. 358
F
G

567Alphabetical index
JackPositioning the jack ............... 483
Vehicle-equipped jack........... 476
Jack handle .............................. 481
Jam protection function
Moon roof.............................. 142
Power windows ..................... 137
Keyless entry ........................... 103 Wireless remote control ........ 103
Keys .......................................... 100 Engine switch........................ 179
If you lose your keys ............. 100
Ignition switch ....................... 179
Key number plate.................. 100
Keyless entry ........................ 103
Replacing the battery ............ 434
Wireless remote control ........ 103
Knee airbags .............................. 39
Language (multi-information display) ..... 95
LATCH anchors ................... 63, 64
Lever
Auxiliary catch lever .............. 405
Hood lock release lever ........ 405
Shift lever .............................. 181
Turn signal lever ................... 186
Wiper lever............................ 193 License plate lights
Light switch ........................... 189
Replacing light bulbs ............ 451
Wattage ................................ 515
Light bulbs Replacing.............................. 441
Wattage ................................ 515
Lights Cargo lamp switch ................ 355
Engine switch light (ignition switch light) ........... 353
Fog light switch ..................... 192
Headlight switch ................... 189
Illuminated entry system ....... 355
Interior lights ......................... 354
Interior lights list.................... 353
Outer foot light ...................... 353
Personal lights ...................... 354
Replacing light bulbs ............ 439
Turn signal lever ................... 186
Vanity lights .......................... 374
Wattage ................................ 515
Load capacity .......................... 156
Luggage compartment features .................................. 373
Luggage storage box .............. 371
J
K
L

569Alphabetical index
Parking assist sensors (intuitive parking assist) ....... 203
Parking brake ........................... 187 Operation .............................. 187
Parking brake engaged
warning buzzer ................... 464
Parking brake engaged
warning message ............... 473
Parking lights ........................... 189 Light switch ........................... 189
Replacing light bulbs..... 444, 452
Wattage ................................ 515
Pen holder ................................ 363
Personal lights ......................... 354
Light switch ........................... 354
Wattage ................................ 515
Power back window ................ 140
Power easy access system .... 118
Power outlets ........................... 377
Power steering fluid ................ 413
Power windows........................ 136 Jam protection function......... 137
Operation .............................. 136
Window lock switch............... 136 Radiator .................................... 412
Radio ........................................ 267
Rear personal lights ................ 354
Rear seat
Adjustment precautions ........ 117
Child seats/child restraint system installation ................ 60
Cleaning ............................... 394
Head restraints ..................... 122
Raising the bottom cushion ............................... 116
Rear side marker lights........... 189 Light switch ........................... 189
Replacing light bulbs ............ 450
Wattage ................................ 515
Rear step bumper .................... 112
Rear turn signal lights ............ 186
Replacing light bulbs ............ 450
Turn signal lever ................... 186
Wattage ................................ 515
Rear view mirror Inside rear view mirror .......... 129
Outside rear view mirrors ..... 132
Rear view monitor system ...... 209
Refueling .................................. 196 Capacity................................ 508
Fuel types ............................. 508
Opening the fuel tank cap..... 198
Replacing Fuses .................................... 436
Light bulbs ............................ 439
Tires...................................... 475
Wireless remote control battery ................................ 434
Reporting safety defects for U.S. owners...................... 538
Reset the maintenance data ... 398
PR

570Alphabetical index
Seat belts.................................... 32Adjusting the seat belt ............ 33
Automatic Locking Retractor............................... 34
Child restra int system
installation ............................ 60
Cleaning and maintaining
the seat belt ........................ 395
Emergency Locking Retractor............................... 34
How to wear your seat belt ..... 32
How your child should wear the seat belt .......................... 34
Pregnant women, proper seat belt use ......................... 35
Reminder light and buzzer .... 466
Seat belt extender................... 34
Seat belt pretensioners ........... 33
SRS warning light ................. 465
Seat heaters ............................. 350
Seat position memory ............. 118
Seat ventilators ........................ 350
Seating capacity ...................... 156
Seats, Front .............................. 113 Adjustment ............................ 113
Adjustment precautions ........ 115
Child seats/child restraint system installation ................ 60
Cleaning................................ 394
Driving position memory ....... 118
Head restraints ..................... 122
Power easy access system ......... ....................... 118
Properly sitting in the seat ...... 30
Seat heaters ......................... 350
Seat position memory ........... 118
Seat ventilators ..................... 350 Seats, Rear ............................... 116
Adjustment precautions ........ 117
Child seats/child restraint system installation ................ 60
Cleaning ............................... 394
Head restraints ..................... 122
Raising the bottom cushion ............................... 116
Sensor Automatic headlight
system .......... ...................... 191
Inside rear view mirror .......... 130
Intuitive parking assist .......... 203
Service reminder indicators ..... 84
Shift lever ................................. 181 Automatic transmission ........ 181
If the shift lever
cannot be shifted from P .... 491
Shift lock system ..................... 491
Side airbags ............................... 39
Side doors ................................ 102
Side marker lights ................... 189
Light switch ........................... 189
Replacing light bulbs .... 445, 450
Wattage ................................ 515
Side mirrors ............................. 132 Adjusting and folding ............ 132
BSM (Blind spot monitor)...... 218
Mirror position memory ......... 118
Side turn signal lights ............. 186 Replacing light bulbs .... 445, 450
Turn signal lever ................... 186
Wattage ................................ 515
Snow tires ................................ 242
Spare tire .................................. 475
Inflation pressure .................. 513
Replacing.............................. 475
Storage location.................... 476
S

571Alphabetical index
Spark plug ................................ 510
Specifications .......................... 500
Speedometer .............................. 88
SteeringColumn lock release ............. 180
Steering wheel Adjustment .................... 126, 127
Steering wheel
position memory ................. 118
Steering wheel audio switches
*
Stop lights
Replacing light bulbs............. 450
Wattage ................................ 515
Storage box .............................. 371
Storage feature ........................ 356
Stuck If the vehicle becomes stuck ................................... 498
Sun visors ................................ 374
Switches
Back window defogger switch ......................... 338, 345
BSM (Blind spot monitor) main switch......................... 218
Cargo lamp main switch ....... 355
Cruise control switch............. 200
“DISP” button .......................... 94
Door lock switch.................... 105
Driving position memory
switches.............................. 118
Emergency flashers switch ... 456
Engine switch........................ 179
Fog light switch ..................... 192 Front-wheel drive control
switch ................................. 226
Garage door opener
switches ............................. 381
Ignition switch ....................... 179
Intuitive parking assist .......... 203
Light switches ....................... 189
Moon roof switches............... 142
Outside rear view mirror defoggers switch ........ 338, 345
Outside rear view mirror switches ............................. 132
Personal/interior lights
main switch ........................ 354
Power back window switch ................................. 140
Power door lock switch ......... 105
Power window switches........ 136
Seat heater switches ............ 350
Seat ventilator switches ........ 350
Tilt and telescopic steering control switch........ 127
Tire pressure warning reset switch ................................. 419
TOW/HAUL switch................ 184
Turn signal lights .................. 186
VSC off switch ......... 229, 232, 234, 236
Window lock switch .............. 136
Windshield wiper de-icer switch ............. 339, 346
Windshield wipers and washer switch.............. 193
*: Refer to “NAVIGATION SYSTEM OWNER’S MANUAL”.
