2014 TOYOTA PRIUS PLUG-IN Owners Manual

570
5-2. Steps to take in an emergency
PRIUS PHV_OM_OM47856U_(U)
■Emergency tire puncture repair kit components
Bottle
Air release cap
Hose
Stickers

5
When trouble arises
571
5-2. Steps to take in an emergency
PRIUS PHV_OM_OM47856U_(U)
Compressor
Power plug
Air pressure gauge Compressor switch

572
5-2. Steps to take in an emergency
PRIUS PHV_OM_OM47856U_(U)
Before performing emergency repair
Check the degree of the tire damage.
A tire should only be repaired
with the emergency tire puncture
repair kit if the damage is caused
by a nail or screw passing
through the tire tread.
•Do not remove the nail or
screw from the tire. Removing
the object may widen the
opening and prevent emer-
gency repair with the repair kit.
•To avoid sealant leakage,
move the vehicle until the area
of the puncture, if known, is
positioned at the top of the
tire.

5
When trouble arises
573
5-2. Steps to take in an emergency
PRIUS PHV_OM_OM47856U_(U)
■In the following cases, the tire cannot be repaired with the emer-
gency tire puncture repair kit. Contact your Toyota dealer.
●When the tire is damaged due to driving without sufficient air pres-
sure
●When there are any cracks or damage at any location on the tire,
such as on the side wall, except the tread
●When the tire is visibly separated from the wheel
●When the cut or damage to the tread is 0.16 in. (4 mm) long or more
●When the wheel is damaged
●When two or more tires have been punctured
●When more than 2 sharp objects such as nails or screws have
passed through the tread on a single tire
●When the sealant has expired

574
5-2. Steps to take in an emergency
PRIUS PHV_OM_OM47856U_(U)
Ta k i n g o u t t h e e m e r g e n c y t i r e p u n c t u r e r e pa i r k i t
Lift the side deck board.
Unhook the tightening strap.
Ta k e o u t t h e e m e r g e n c y t i r e
puncture repair kit.
STEP 1
STEP 2

5
When trouble arises
575
5-2. Steps to take in an emergency
PRIUS PHV_OM_OM47856U_(U)
Emergency repair method
Ta k e o u t t h e r e p a i r k i t f r o m t h e p l a s t i c b a g .
Remove the valve cap from the
valve of the punctured tire.
Remove the air release cap from
the hose.
Yo u w i l l u s e t h e a i r r e l e a s e c a p
again. Therefore keep it in a
safe place.
STEP 1
STEP 2
STEP 3

576
5-2. Steps to take in an emergency
PRIUS PHV_OM_OM47856U_(U)
Connect the hose to the valve.
Screw the end of the hose
clockwise as far as possible.
Make sure that the compressor
switch is off.
Remove the rubber stopper from
the compressor.
STEP 4
STEP 5
STEP 6

5
When trouble arises
577
5-2. Steps to take in an emergency
PRIUS PHV_OM_OM47856U_(U)
Connect the power plug to the power outlet socket. (→P. 3 9 7 )
Instrument panel
Rear console box
STEP7
