2014 TOYOTA PRIUS PLUG-IN stop start

568
5-2. Steps to take in an emergency
PRIUS PHV_OM_OM47856U_(U)
MessageDetailsCorrection
procedure
Charging has been
stopped because of a
problem with the charg-
ing cable.
If the charging cable is
not a genuine Toyota
product, or if you are
charging using a charg-
ing station (other than a
To y o t a d e a l e r ) , t r y c h a r g -
ing with a genuine Toyota
charging cable.
If the message is still
displayed, contact your
To y o t a d e a l e r .
Charging has stopped
because of the continued
high temperature of the
hybrid battery (traction
battery) (in order to pro-
tect the battery).
If the desired charge
level has not been
achieved, restart charg-
ing by following the pro-
cedure on P. 84 after the
hybrid battery (traction
battery) has cooled
down.

596
5-2. Steps to take in an emergency
PRIUS PHV_OM_OM47856U_(U)
■Stopping the hybrid system
Set the parking brake, shift the shift position to P and press the “POWER”
switch as you normally do when stopping the hybrid system.
■Replacing the key battery
As the above procedure is a temporary measure, it is recommended that the
electronic key battery be replaced immediately when the battery is depleted.
(→P. 4 9 6 )
■Changing “POWER” switch modes
Within 10 seconds of the buzzer sounding, release the brake pedal and
press the “POWER” switch.
The hybrid system does not start and modes will be changed each time the
switch is pressed. (→P. 2 4 2 )

5
When trouble arises
607
5-2. Steps to take in an emergency
PRIUS PHV_OM_OM47856U_(U)
CAUTION
■To p r e v e n t a n a c c i d e n t o r i n j u r y w hen inspecting under the hood of
your vehicle
●If steam is seen coming from under the hood, do not open the hood until
the steam has subsided. The engine compartment may be very hot, caus-
ing serious injuries such as burns.
●After the hybrid system has been turned off, check that the indicator on the
“POWER” switch and the “READY” indicator are off.
When the hybrid system is operating, the gasoline engine may automati-
cally start, or the cooling fans may suddenly operate even if the gasoline
engine stops. Do not touch or approach rotating parts such as the fans,
which may lead to fingers or clothing (especially a tie, a scarf or a muffler)
getting caught, resulting in serious injury.
●Do not loosen the coolant reservoir cap while the hybrid system and radia-
tor are hot.
Serious injury, such as burns, may result from hot coolant and steam
released under pressure.
NOTICE
■When adding engine/power control unit coolant
Wait until the hybrid system has cooled down before adding engine/power
control unit coolant.
When adding coolant, do so slowly. Adding cool coolant to a hot hybrid sys-
tem too quickly can cause damage to the hybrid system.
■To p r e v e n t d a m a g e t o t h e c o o l i n g s y s t e m
Observe the following precautions:
●Avoid contaminating the coolant with foreign matter (such as sand or dust
etc.).
●Do not use any coolant additives.

608
5-2. Steps to take in an emergency
PRIUS PHV_OM_OM47856U_(U)
If the vehicle becomes stuck
CAUTION
■When attempting to free a stuck vehicle
If you choose to push the vehicle back and forth to free it, make sure the sur-
rounding area is clear to avoid striking other vehicles, objects or people. The
vehicle may also lunge forward or lunge back suddenly as it becomes free.
Use extreme caution.
■When changing the shift position
Be careful not to change the shift position with the accelerator pedal
depressed.
Changing the shift position to any positions other than P or N may cause the
vehicle to accelerate abruptly, causing an accident and resulting in death or
serious injury.
Carry out the following procedures if the tires spin or the vehicle
becomes stuck in mud, dirt or snow:
Set the parking brake and shift the shift position to P. Stop
the hybrid system.
Remove the mud, snow or sand from around the stuck tire.
Place wood, stones or some other material under the tires
to help provide traction.
Restart the hybrid system.
Shift the shift position to D or R, release the parking brake
and carefully apply the accelerator to free the vehicle.
STEP 1
STEP 2
STEP 3
STEP 4
STEP 5

675
Alphabetical index
PRIUS PHV_OM_OM47856U_(U)
Daytime running light
system ................................... 297
Deck board............................... 405
Defogger
Rear window......................... 377
Side mirrors .......................... 377
Dimensions .............................. 614
Dinghy towing ......................... 357
Display
Dynamic radar cruise
control ................................ 314
Multi-information ................... 268
Warning messages............... 548
Do-it-yourself maintenance .... 442
Door lock
Back door ............................. 144
Side doors ............................ 138
Smart key system ................. 112
Wireless remote control........ 136
Doors
Back door ............................. 144
Door glasses ........................ 175
Door lock .............. 112, 136, 138
Rear door child-protector...... 139
Side doors ............................ 138
Driver’s seat belt reminder
light ........................................ 539
Driving
Break-in tips ......................... 228
Correct posture..................... 185
Procedures ........................... 226
Winter driving tips ................. 351
Eco drive mode switch ............249
Electric power steering ...........330
Electronic key
If the electronic key does not
operate properly..................594
Replacing battery ..................496
Emergency, in case of
If a warning buzzer
sounds ................................535
If a warning light turns on ......535
If the electronic key does not
operate properly..................594
If the hybrid system will not
start .....................................591
If the 12-volt battery is
discharged ..........................597
If you have a flat tire .............569
If you lose your keys .............593
If you think something is
wrong ..................................534
If your vehicle becomes
stuck ...................................608
If your vehicle has to be
stopped in an
emergency ..........................610
If your vehicle needs to be
towed ..................................527
If your vehicle overheats .......603
Emergency flashers
Switch....................................526
DE
