2014 TOYOTA PRIUS C ECO mode

5
When trouble arises
483
5-2. Steps to take in an emergency
Start the engine of the second vehicle. Increase the engine
speed slightly and maintain that level for approximately 5
minutes to recharge the 12-v
olt battery of your vehicle.
Vehicles with a smart key system only: Open and close any
of the doors of your vehicle with the “POWER” switch off.
Vehicles without a smart key system
Maintain the engine speed of the second vehicle and start
the hybrid system of your vehicle by turning the engine
switch to the “ON” position.
Vehicles with a smart key system
Maintain the engine speed of the second vehicle and start
the hybrid system of your ve hicle by turning the “POWER”
switch to ON mode.
Make sure the “READY” indicator comes on. If the indicator
does not come on, contact your Toyota dealer.
Once the hybrid system has started, remove the jumper
cables in the exact reverse or der from which they were con-
nected.
Close the exclusive jump starting terminal cover, and rein-
stall the fuse box cover to its original position.
When installing, first hook the fuse box cover onto the two rear
tabs.
Once the hybrid system starts, ha ve the vehicle inspected at your
Toyota dealer as soon as possible.
STEP4
STEP5
STEP6
STEP7
STEP8
STEP9

484 5-2. Steps to take in an emergency
■Starting the hybrid system when the 12-volt battery is discharged
The hybrid system cannot be started by push-starting.
■ To prevent 12-volt battery discharge
●Turn off the headlights and the audio system while the hybrid system is
off.
● Turn off any unnecessary electrical components when the vehicle is run-
ning at a low speed for an extended period, such as in heavy traffic.
■ Precautions when the 12-volt batter y is discharged (vehicles with a
smart key system)
● In some cases, it may not be possible to unlock the doors using the smart
key system immediately after the 12-volt battery has been disconnected
and reconnected. Use the wireless remote control or the mechanical key
to lock or unlock the doors.
● The hybrid system may not start on the first attempt after the 12-volt bat-
tery has recharged but will start normally after the second attempt. This is
not a malfunction.
● The “POWER” switch mode is memorized by the vehicle. When the 12-
volt battery is reconnected, the system will return to the mode it was in
before the 12-volt battery was discharged. Before disconnecting the 12-
volt battery, turn the “POWER” switch off.
If the “POWER” switch was in ACCESSORY or ON mode before the 12-
volt battery was discharged, the audio system and/or air conditioning
system may operate when the 12-volt battery is reconnected.
■ Charging the 12-volt battery
The electricity stored in the 12-volt battery will discharge gradually even
when the vehicle is not in use, due to natural discharge and the draining
effects of certain electrical appliances. If the vehicle is left for a long time, the
12-volt battery may discharge, and the hybrid system may be unable to start.
(The 12-volt battery recharges automatically while the hybrid system is oper-
ating.)

519
6-1. Specifications
6
Vehicle specifications
Intended outboard
sidewall
(a) The sidewall that contains a whitewall,
bears white lettering, or bears manufac-
turer, brand, and/or model name molding
that is higher or deeper than the same
molding on the other sidewall of the tire, or
(b) The outward facing sidewall of an asymmet- rical tire that has a particular side that must
always face outward when mounted on a
vehicle
Light truck (LT) tire A tire designated by its manufacturer as prima-
rily intended for use on lightweight trucks or
multipurpose passenger vehicles
Load rating The maximum load that a tire is rated to carry
for a given inflation pressure
Maximum load rating The load rating for a tire at the maximum per-
missible inflation pressure for that tire
Maximum permissible
inflation pressure The maximum cold inflation pressure to which
a tire may be inflated
Measuring rim The rim on which a tire is fitted for physical
dimension requirements
Open splice Any parting at any junction of tread, sidewall, or
innerliner that extends to cord material
Outer diameter The overall diameter of an inflated new tire
Overall width The linear distance between the exteriors of
the sidewalls of an inflated tire, including eleva-
tions due to labeling, decorations, or protective
bands or ribs
Passenger car tire A tire intended for use on passenger cars, mul-
tipurpose passenger vehicles, and trucks, that
have a gross vehicle weight rating (GVWR) of
10,000 lb. or less.
Ply A layer of rubber-coated parallel cords
Tire related termMeaning

527
6-2. Customization
6
Vehicle specifications
*1: If equipped
*2: Vehicles with a smart key system
*3: Vehicles without a smart key system
Automatic
air condi-
tioning sys-
tem
(
P. 238)
Air condition-
ing control of
Eco drive mode
On Off — O
ItemFunctionDefault set-
tingCustomizedsetting

549
Alphabetical index
Doors
Back door ............................... 71
Door lock .................... 47, 61, 65
Door windows ......................... 98
Rear door child protector ........ 67
Side doors .............................. 65
Side mirrors ............................ 96
Driver’s seat belt reminder
light ........................................ 439
Driving Break-in tips ......................... 151
Correct posture..................... 114
Procedures ........................... 150
Winter driving tips ................. 231
Eco drive mode ....................... 176
Electric power steering........... 221
Electronic key If the electronic key does
not operate properly ........... 479
Emergency flashers Switch ................................... 428
Emergency, in case of If a warning buzzer sounds ............................... 437
If a warning light turns on .............................. 437
If a warning message is
displayed ............................ 447
If the electronic key does not operate properly ........... 479
If the hybrid system will not start .............................. 475
If the shift lever cannot
be shifted from P ................ 477
If the vehicle becomes stuck................................... 492
If the vehicle 12-volt battery is discharged .......... 481 If you have a flat tire .............463
If you lose your keys .............478
If you think something is
wrong ..................................436
If your vehicle has to
be stopped in an
emergency ..........................493
If your vehicle needs to
be towed .............................429
If your vehicle overheats .......487
Engine
Compartment ........................368
Engine switch ................160, 164
Hood......................................364
How to start the hybrid system ........................160, 164
Identification number .............497
If the hybrid system will
not start ...............................475
Ignition switch................160, 164
Overheating...........................487
“POWER” switch ...................164
Engine coolant
Capacity ................................500
Checking ...............................373
Preparing and checking before winter .......................231
E

550 Alphabetical index
Engine oilCapacity ................................ 499
Checking ............................... 369
Preparing and checking before winter ....................... 231
Engine/power control unit coolantCapacity ................................ 500
Checking ............................... 373
Preparing and checking before winter ....................... 231
Engine switch ................... 160, 164
EPS ............................................ 221
EV drive mode .......................... 172
Event data recorder ...................18
Exclusive jump starting terminal .................... 481
Floor mat................................... 341
Fluid Brake ..................................... 503
Washer .................................. 378
Fog lights Replacing light bulbs ............. 415
Switch.................................... 208
Wattage ................................. 505
Front fog lights Replacing light bulbs ............. 415
Switch.................................... 208
Wattage ................................. 505
Front passenger occupant
classification system ............ 130 Front passenger’s seat
belt reminder light ................. 439
Front seats Adjustment .............................. 76
Front side marker lights
Replacing light bulbs ............. 415
Switch ................................... 204
Wattage................................. 505
Front turn signal lights Replacing light bulbs ............. 415
Switch ................................... 178
Wattage................................. 505
Fuel Capacity ................................ 498
Fuel gauge ............................ 181
Gas station information ......... 560
Information ............................ 506
Refueling ............................... 105
Type ...................................... 498
Fuel door .................................. 105
Fuel filler door .......................... 105
Fuses ........................................ 404
Gas station information .......... 560
Gauges...................................... 181
Glove box ................................. 325
Hazard lights
Switch ................................... 428
Head restraints
Adjusting ................................ 81
Headlights Replacing light bulbs ............. 415
Switch ................................... 204
Wattage................................. 505
F
G
H

555
Alphabetical index
Switch
Cruise control ....................... 217
“ECO MODE” switch ............ 176
Emergency flasher switch .... 428
EV drive mode switch ........... 172
Engine switch ............... 160, 164
Fog light switch..................... 208
Hazard light switch ............... 428
Headlight switch ................... 204
Ignition switch ............... 160, 164
Light switches ....................... 204
Power door lock switch........... 65
“POWER” switch .................. 164
Power window switch ............. 98
Rear window wiper and
washer switch .................... 214
Steering wheel audio
switches ............................. 288
Window lock switch ................ 98
Wiper and washer ........ 210, 214
Tail lights Replacing light bulbs ............ 415
Switch ................................... 204
Wattage ................................ 505
Theft deterrent system Immobilizer system............... 110
Theft prevention labels ......... 113
Theft prevention labels ........... 113
Tire inflation pressure ............ 392
Tire information Glossary ............................... 516
Size ...................................... 512
Tire identification number ..... 511
Uniform tire quality grading ............................... 513 Tires
Chains ...................................231
Checking ...............................384
If you have a flat tire ..............463
Inflation pressure...................392
Inflation pressure sensor .......385
Information ............................509
Replacing ..............................463
Rotating tires .........................384
Size .......................................504
Snow tires .............................231
Spare tire...............................463
Tire pressure warning system ........................384, 439
Tools .........................................463
Total load capacity...................230
Towing Dinghy towing........................236
Emergency towing.................431
Trailer towing.........................235
TRAC .........................................221
Traction control........................221
Transmission Hybrid transmission...............175
If the shift lever cannot be shifted from P................. 477
Trip information .......................187
Trip meter .................................181
Turn signal lights Replacing light bulbs .............415
Switch....................................178
Wattage .................................505
USB memory ....................268, 276
T
U

556 Alphabetical index
Vanity mirrors........................... 333
Vehicle data recordings ............18
Vehicle identification number ................................... 497
Vehicle Proximity Notification
System ....................................25
Vehicle stability control........... 221
VSC............................................ 221
Warning buzzers Brake system ........................ 437
Electric power steering system ................................ 438
Key reminder ......................... 455
Master warning...................... 439
Seat belt reminder ................. 439
Warning lights Anti-lock brake system .......... 438
Brake assist system .............. 438
Brake system ........................ 437
Charging system .... ............... 438
Electric power steering
system ................................ 438
Front passenger occupant classification system ........... 438
Low brake fluid ...................... 437
Low fuel level ........................ 439
Low tire inflation pressure ..... 439
Malfunction indicator lamp .... 438
Master warning light .............. 439 Pretensioners ........................ 438
Seat belt reminder light ......... 439
Slip indicator light .................. 438
SRS airbag system ............... 438
Tire pressure ......................... 439
Tire pressure warning
system ................................ 439
Warning messages
Back door .............................. 450
Cruise control ........................ 449
EV drive mode ...................... 450
Hybrid system ....................... 448
Hybrid system overheat ........ 450
Maintenance ......................... 450
Moon roof .............................. 450
N position .............................. 450
Open door ............................. 450
P position .............................. 450
Parking brake ........................ 450
Smart key system ......... 449, 455
Traction battery ..................... 450
Washer Checking ............................... 378
Preparing and checking
before winter ....................... 231
Switch ........................... 210, 214
Washing and waxing ............... 346
Weight Cargo capacity ...................... 226
Load limits ............................. 230
Weight ................................... 496
Wheels ...................................... 396
Window lock switch................... 98V
W
