2014 TOYOTA PRIUS C reset

5
When trouble arises
451
5-2. Steps to take in an emergency
(Flashes)
(If equipped) Indicates that the
moon roof is not fully
closed (with the
“POWER” switch off
and the driver's door
is open)
A buzzer also sounds. Close the moon roof.
(U.S.A.)
(Canada) (red) Indicates that the
parking brake is still
engaged
If the vehicle reaches
a speed of 3 mph (5
km/h), flashes
and a buzzer sounds
to indicate that the
parking brake is still
engaged. Release the parking
brake.
(U.S.A. only) Indicates that all
maintenance accord-
ing to the driven dis-
tance on the
maintenance sched-
ule
*1 should be per-
formed soon If necessary, perform
maintenance.
Comes on approxi-
mately 4500 miles
(7200 km) after the
maintenance data has
been reset
Warning messageDetailsCorrection procedure

452 5-2. Steps to take in an emergency
(U.S.A. only)Indicates that all
maintenance is
required to corre-
spond to the driven
distance on the main-
tenance schedule
*1Perform the necessary
maintenance.
Please reset the main-
tenance data after the
maintenance is per-
formed.(
P. 353)
Comes on approxi-
mately 5000 miles
(8000 km) after the
maintenance data has
been reset
(The indicator will not
work properly unless
the maintenance data
has been reset)
Indicates that the
hybrid system has
overheated
A buzzer also sounds.
This message may be
displayed when driv-
ing under severe oper-
ating conditions. (For
example, when driv-
ing up a long steep
hill.) Stop and check.
(
P. 487)
(Flashes) Indicates that the
hybrid battery (trac-
tion battery) is low
A buzzer also sounds. When stopping the
vehicle for a long period
of time, shift the shift
lever to P. The hybrid
battery (traction battery)
cannot be charged with
the shift position in N.
Warning messageDetailsCorrection procedure

470 5-2. Steps to take in an emergency
■The compact spare tire
●The compact spare tire is identified by the label “TEMPORARY USE
ONLY” on the tire sidewall.
Use the compact spare tire temporarily, and only in an emergency.
●Make sure to check the tire inflation pressu re of the compact spare
tire. ( P. 504)
■After completing the tire change
The tire pressure warnin g system must be reset. ( P. 385)
■When using the compact spare tire
As the compact spare tire is not equipped with a tire pressure warning
valve and transmitter, low inflation pressure of the spare tire will not be
indicated by the tire pressure warn ing system. Also, if you replace the
compact spare tire after the tire pressure warning light comes on, the
light remains on.
■If you have a flat front tire on a road covered with snow or ice
Install the compact spare tire on one of the rear wheels of the vehicle.
Perform the following steps and fit tire chains to the front tires:
Replace a rear tire with the compact spare tire.
Replace the flat front tire with the tire removed from the rear of
the vehicle.
Fit tire chains to the front tires.
STEP1
STEP2
STEP3

553
Alphabetical index
Radiator.................................... 375
Radio ........................................ 254
Rear seat
Folding down .......................... 77
Rear turn signal lights
Replacing light bulbs ............ 415
Wattage ................................ 505
Rear window defogger............ 247
Rear window wiper.................. 214
Reset the maintenance data... 353
Replacing
Fuses.................................... 404
Key battery ........................... 401
Light bulbs ............................ 415
Tires ..................................... 463
Reporting safety defects for U.S. owners ..................... 530 Seat belts
Adjusting the seat belt .............84
Automatic Locking
Retractor (ALR).....................88
Child restraint system
installation ...........................140
Cleaning and maintaining the seat belts ......................349
Emergency Locking Retractor (ELR).................... 88
How to wear your seat belt......84
How your child should
wear the seat belt .................88
Pregnant women,
proper seat belt use ..............90
Reminder light .......................439
Seat belt extenders .................89
Seat belt pretensioners ...........88
Seat cushion airbag .................116
Seat heaters..............................337
Seating capacity.......................230RS
