2014 TOYOTA PRIUS C charging

438 5-2. Steps to take in an emergency
Stop the vehicle immediately.The following warning indicates the possibility of damage to the vehi-
cle that may lead to an accident. Immediately stop the vehicle in a
safe place and contact your Toyota dealer.
Have the vehicle inspected by your Toyota dealer immediately.Failure to investigate the cause of the following warnings may lead to
the system operating abnormally and possibly cause an accident.
Have the vehicle inspected by your Toyota dealer immediately.
Warning lightWarning light/Details
Charging system warning light Indicates a malfunction in the vehicle's charging sys-
tem
Warning lightWarning light/Details
(U.S.A.)

(Canada)
Malfunction indicator lamp Indicates a malfunction in:
• The hybrid system;
• The electronic engine control system; or
• The electronic throttle control system
SRS warning light Indicates a malfunction in:
• The SRS airbag system;
• The front passenger occupant classification system; or
• The seat belt pretensioner system
(U.S.A.)

(Canada)
ABS warning light Indicates a malfunction in:
• The ABS; or
• The brake assist system

484 5-2. Steps to take in an emergency
■Starting the hybrid system when the 12-volt battery is discharged
The hybrid system cannot be started by push-starting.
■ To prevent 12-volt battery discharge
●Turn off the headlights and the audio system while the hybrid system is
off.
● Turn off any unnecessary electrical components when the vehicle is run-
ning at a low speed for an extended period, such as in heavy traffic.
■ Precautions when the 12-volt batter y is discharged (vehicles with a
smart key system)
● In some cases, it may not be possible to unlock the doors using the smart
key system immediately after the 12-volt battery has been disconnected
and reconnected. Use the wireless remote control or the mechanical key
to lock or unlock the doors.
● The hybrid system may not start on the first attempt after the 12-volt bat-
tery has recharged but will start normally after the second attempt. This is
not a malfunction.
● The “POWER” switch mode is memorized by the vehicle. When the 12-
volt battery is reconnected, the system will return to the mode it was in
before the 12-volt battery was discharged. Before disconnecting the 12-
volt battery, turn the “POWER” switch off.
If the “POWER” switch was in ACCESSORY or ON mode before the 12-
volt battery was discharged, the audio system and/or air conditioning
system may operate when the 12-volt battery is reconnected.
■ Charging the 12-volt battery
The electricity stored in the 12-volt battery will discharge gradually even
when the vehicle is not in use, due to natural discharge and the draining
effects of certain electrical appliances. If the vehicle is left for a long time, the
12-volt battery may discharge, and the hybrid system may be unable to start.
(The 12-volt battery recharges automatically while the hybrid system is oper-
ating.)

5
When trouble arises
485
5-2. Steps to take in an emergency
CAUTION
■
Avoiding 12-volt battery fires or explosions
Observe the following precautions to prevent accidentally igniting the flam-
mable gas that may be emitted from the 12-volt battery:
●Make sure each jumper cable is connected to the correct terminal and that
it is not unintentionally in contact with anything other than the intended ter-
minal.
● Do not allow the other end of the jumper cable connected to the “+” termi-
nal to come into contact with any other parts or metal surfaces in the area,
such as brackets or unpainted metal.
● Do not allow the + and - clamps of the jumper cables to come into contact
with each other.
● Do not smoke, use matches, cigarette lighters or allow open flame near
the 12-volt battery.
■ After recharging the 12-volt battery
Have the 12-volt battery inspected at your Toyota dealer as soon as possi-
ble.
If the 12-volt battery is deteriorating, continued use may cause the 12-volt
battery to emit a malodorous gas, which may be detrimental to the health of
passengers.
■ When replacing the 12-volt battery
P. 383

486 5-2. Steps to take in an emergency
CAUTION
■12-volt battery precautions
The 12-volt battery contains poisonous and corrosive acidic electrolyte,
while related parts contain lead and lead compounds. Observe the following
precautions when handling the 12-volt battery:
●When working with the 12-volt battery, always wear safety glasses and
take care not to allow any battery fluids (acid) to come into contact with
skin, clothing or the vehicle body.
● Do not lean over the 12-volt battery.
● In the event that battery fluid comes into contact with the skin or eyes,
immediately wash the affected area with water and seek medical attention.
Place a wet sponge or cloth over the affected area until medical attention
can be received.
● Always wash your hands after handling the battery support, terminals, and
other battery-related parts.
● Do not allow children near the 12-volt battery.
NOTICE
■When handling jumper cables
When connecting the jumper cables, ensure that they do not become entan-
gled in the cooling fan or belt.
■ Exclusive jump starting terminal
The exclusive jump starting terminal is to be used when charging the 12-volt
battery from another vehicle in an emergency. It cannot be used to jump start
another vehicle.

501
6-1. Specifications
6
Vehicle specifications
Ignition system
Electrical system
Spark plug
Make
Gap
DENSO FK16R-A8
0.03 in. (0.8 mm)
NOTICE
■
Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust the spark plug gap.
12-volt battery
Open voltage* at
68 F (20 C):
Fully charged
Half charged
Discharged 12.5 V or over
11 . 0

12.5 V
Under
11.0 V
(*: Voltage checked 20 minutes after the hybrid
system and all the lights are turned off)
Charging rates 3.5 A or less
(Recharge within 10 hours)

556 Alphabetical index
Vanity mirrors........................... 333
Vehicle data recordings ............18
Vehicle identification number ................................... 497
Vehicle Proximity Notification
System ....................................25
Vehicle stability control........... 221
VSC............................................ 221
Warning buzzers Brake system ........................ 437
Electric power steering system ................................ 438
Key reminder ......................... 455
Master warning...................... 439
Seat belt reminder ................. 439
Warning lights Anti-lock brake system .......... 438
Brake assist system .............. 438
Brake system ........................ 437
Charging system .... ............... 438
Electric power steering
system ................................ 438
Front passenger occupant classification system ........... 438
Low brake fluid ...................... 437
Low fuel level ........................ 439
Low tire inflation pressure ..... 439
Malfunction indicator lamp .... 438
Master warning light .............. 439 Pretensioners ........................ 438
Seat belt reminder light ......... 439
Slip indicator light .................. 438
SRS airbag system ............... 438
Tire pressure ......................... 439
Tire pressure warning
system ................................ 439
Warning messages
Back door .............................. 450
Cruise control ........................ 449
EV drive mode ...................... 450
Hybrid system ....................... 448
Hybrid system overheat ........ 450
Maintenance ......................... 450
Moon roof .............................. 450
N position .............................. 450
Open door ............................. 450
P position .............................. 450
Parking brake ........................ 450
Smart key system ......... 449, 455
Traction battery ..................... 450
Washer Checking ............................... 378
Preparing and checking
before winter ....................... 231
Switch ........................... 210, 214
Washing and waxing ............... 346
Weight Cargo capacity ...................... 226
Load limits ............................. 230
Weight ................................... 496
Wheels ...................................... 396
Window lock switch................... 98V
W

559
What to do if...
■
Warning lights
P. 438
or
P. 4 3 7P. 438
P. 4 3 8P. 438
orP. 439
P. 4 3 8
P. 439
P. 4 3 8
P. 439
orP. 439
P. 4 3 8
*: Slip indicator comes on.
Brake system warning
light
(red indicator)Electric power steering system
warning light
Slip indicator light*
Charging system warning
lightBrake system warning light
(yellow indicator)
Malfunction indicator
lampLow fuel level warning
light
Driver’s and front pas-
senger’s seat belt
reminder light
SRS warning light
Master warning light
ABS warning light
Tire pressure warning
light
