2014 TOYOTA HIGHLANDER display

3144-5. Using the driving support systems
HIGHLANDER_U (OM48A12U)
■The outside rear view mirror indicators visibility
When under strong sunlight, the outside r ear view mirror indicator may be dif-
ficult to see.
■ Rear Cross Traffic Alert buzzer hearing
Rear Cross Traffic Alert function may be difficult to hear over loud noises
such as high audio volume.
■ When there is a malfunction in the Blind Spot Monitor
If a system malfunction is detected due to any of the following reasons, warn-
ing message will be displayed: ( P. 578, 579)
● There is a malfunction with the sensors
● The sensors have become dirty
● The outside temperature is extremely high or low
● The sensor voltage has become abnormal
Outside rear view mirror indicators
Blind Spot Monitor function:
When a vehicle is detected in the blind spot, the outside rear view mirror
indicator comes on while the turn signal lever is not operated and the out-
side rear view mirror indicator flashes while the turn signal lever is oper-
ated.
Rear Cross Traffic Alert function:
When a vehicle approaching from the right or left rear of the vehicle is
detected, the outside rear view mirror indicators flash.
Rear Cross Traffic Alert buzzer (Rear Cross Traffic Alert function
only)
When a vehicle approaching from the right or left rear of the vehicle is
detected, a buzzer sounds from behind the left-hand third seat.
2
3

332
HIGHLANDER_U (OM48A12U)5-1. Basic Operations
Audio system types ........... 334
Audio system .................... 338
Steering wheel audio switches .......................... 341
USB Port/AUX Port ........... 342
Basic audio operations...... 343
5-2. Setup Setup menu....................... 345
General settings ................ 346
Audio settings ................... 347
Display settings ................. 348
Voice settings.................... 349
5-3. Using the Multimedia system
Selecting the audio source ............................. 350
List screen operation......... 351
Optimal use of the audio system ................... 353
5-4. Using the radio Radio operation................. 354
5Audio system

333
5Audio system
HIGHLANDER_U (OM48A12U)5-5. Playing an audio CD and
MP3/WMA/AAC discs
CD player operation .......... 356
5-6. Using an external device Listening to an iPod .......... 362
Listening to a USB memory device................ 366
Using the AUX port ........... 370
5-7. Connecting Bluetooth
®
Preparations to use wireless
communication ................ 371
Registering a Bluetooth
®
audio player for the
first time .......................... 375
Registering a Bluetooth
®
phone for the first time .... 376
Registering a Bluetooth
®
device.............................. 377
Connecting a Bluetooth
®
device.............................. 379
Displaying a Bluetooth
®
device details .................. 381
Detailed Bluetooth
®
system settings ............... 382 5-8. Bluetooth
® Audio
Listening to Bluetooth®
Audio ............................... 383
5-9. Bluetooth
® phone
Using a Bluetooth®
Phone ............................. 384
Making a call ..................... 386
Receiving a call ................. 389
Speaking on the phone ..... 390
Bluetooth
® phone
message function ............ 393
Using the steering wheel switches .......................... 397
Bluetooth
® phone
settings ........................... 398
Contact/Call History Settings ........................... 399
What to do if... (Troubleshooting) ............ 408
5-10. Bluetooth
®
Bluetooth®......................... 412
5-11. Using the voice command system
Voice command system .... 417

3385-1. Basic Operations
HIGHLANDER_U (OM48A12U)
Audio system
: If equipped
Operations such as listening to audio, using the hands-free
phone, confirming vehicle information and changing audio sys-
tem settings are started by using the following buttons.
Audio system operation buttons
“AUDIO” button
Display the “Select Audio Source” screen
or audio top screen. (P. 350) button
Press this button to access the
Bluetooth
® hands-free system. ( P. 384)
“CAR” button
Press this button to access the vehicle information.
(P. 110)
“SETUP” button
Press this button to customize
the function settings. (
P. 345)

3405-1. Basic Operations
HIGHLANDER_U (OM48A12U)■
When using the touch screen
●If the screen is cold, the display may be dark, or the system may seem to be
operating slightly slower than normal.
● The screen may seem dark and hard to see when viewed through sun-
glasses. Change your angle of viewing, adjust the display on the “Display
Settings” screen (P. 348) or remove your sunglasses.
● Flick operations may not be performed smoothly in high altitudes.
NOTICE
■To avoid damaging the touch screen
●To prevent damaging the screen, lightly touch the screen buttons with your
finger.
● Do not use objects other than your finger to touch the screen.
● Wipe off fingerprints using a glass cleaning cloth. Do not use chemical
cleaners to clean the screen, as they may damage the touch screen.

3415-1. Basic Operations
5
Audio system
HIGHLANDER_U (OM48A12U)
Vol um e s wit ch• Increases/decreases volume
• Press and hold: Continuously increases/decreases volume
Cursor switch (“ ” and “ ”)
• Selects (radio stations/radio presets/tracks/files/songs)
• Press and hold: Fast up/ down (radio stations)
• Fast up/down (tracks/files)
Cursor switch (“ ” and “ ”)
• Seek up/down (radio station)
• Press and hold: Continuously seek up/down (radio station)
• Press and hold: Fast forward/rewind (tracks/files/songs)
“MODE/HOLD” switch • Changes audio source
• Press and hold this switch to mute or pause the current operation To cancel the mute or pause, press and hold.
Back switch • Returns to the previous screen
Enter switch • Displays the preset/list screen
• Selects items
Steering wheel audio switches
Some audio features can be controlled using the switches on
the steering wheel.
Operation may differ depending on the type of audio system or
navigation system. For details, refer to the manual provided with
the audio system or navigation system.
Operating the audio system using the steering wheel switches
1
12
3
4
5
WARNING
■ To reduce the risk of an accident
Exercise care when operating the audio switches on the steering wheel.

3435-1. Basic Operations
5
Audio system
HIGHLANDER_U (OM48A12U)
Basic audio operations
Basic audio operations and functions common to each mode are
explained in this section.
Operating the audio system
Press the “” or “ ” button to
seek up or down for a radio
station, or to access a
desired track or file.
Press this knob to turn the
audio system on and off, and
turn it to adjust the volume.
Press this button
to eject a disc
Press to pause or resume
playing music.
Insert a disc into
the disc slot
Turn this knob to select radio
station bands, tracks and files.
Also the knob can be used to
select items in the list display.

345
5
Audio system
HIGHLANDER_U (OM48A12U)
5-2.Setup
Press the “SETUP” button to display the “Setup” screen.Select to adjust the settings for
operation sounds, screen ani-
mation, etc. ( P. 346)
Select to set the voice settings.
( P. 349)
Select to adjust the settings for
contrast and brightness of the
screen. ( P. 348)
Select to adjust the settings for registering, removing, connecting
and disconnecting Bluetooth
® devices. ( P. 382)
Select to adjust the settings for phone sound, contact, message,
etc. ( P. 399)
Select to set audio settings. ( P. 347)
Select to turn the screen off.
Select to set the vehicle custmization. ( P. 662)
Setup menu
You can adjust the audio system to your desired settings.
Display “Setup” screen
1
2
3
4
5
6
7
8
