2014 TOYOTA HIGHLANDER display

5898-2. Steps to take in an emergency
8
When trouble arises
HIGHLANDER_U (OM48A12U)
*: The engine may not be restarted depending on the vehicle condition.
■Messages displays
The message illustrations used are intended as examples, and may differ
from the image that is actually displayed on the multi-information display.
■ Warning buzzer
P. 568
Once
The engine switch has been
turned off with the shift lever in
a position other than P.
 Shift the shift lever to P.
Once
After the engine switch has
been turned off with the shift
lever in a position other than P,
the shift lever has been shifted
to P.
Turn the engine switch off.
Con-
tinu-
ous

Indicates that the engine was
stopped in an emergency while
driving
To restart the engine, shift
the shift lever to N and turn
the engine switch to ON
mode.
*
Once
Indicates that the engine switch
has been pressed while driving
Except when emergency
stopping of the vehicle is
needed, immediately
release the engine switch.
Interior
buzzerExterior buzzerWarning messageDetails/Actions
(Flashes)
(Flashes)
(Flashes)
(Flashes)

6198-2. Steps to take in an emergency
8
When trouble arises
HIGHLANDER_U (OM48A12U)
Ensure that the shift lever is in P and depress the brake pedal.
Touch the Toyota emblem side
of the electronic key to the
engine switch.
When the electronic key is
detected, a buzzer sounds and the
engine switch will turn to IGNITION
ON mode.
When the smart key system is
deactivated in customization set-
ting, the engine switch will turn to
ACCESSORY mode.
Firmly depress the brake pedal.
Vehicles with monochrome display:
Check that is shown on the multi-information display.
Vehicles with color display:
Check that and a message are shown on the multi-information dis-
play.
Press the engine switch.
In the event that the engine still cannot be started, contact your Toyota
dealer.
Starting the engine
1
2
3
4

6639-2. Customization
9
Vehicle specifications
HIGHLANDER_U (OM48A12U)
Some function settings are changed simultaneously with other func-
tions being customized. Contact your Toyota dealer for further details.Settings that can be changed on the audio system screen
Settings that can be changed by the meter control switches
Settings that can be changed by your Toyota dealer
Definition of symbols: O = Available, — = Not available
■Gauges, meters and multi-information display ( P. 94, 97, 101)
Vehicles with monochrome display
Vehicles with color display
Customizable features
1
2
3
Function*1Default settingCustomized set-
ting
Language*2EnglishFrenchOO—Spanish
Units*2miles (MPG US)
km (km/L)
OO—km (L/100 km)
miles (MPG Imperial)
Eco Driving Indicator
LightOn
(Self-lighting)Off—O—
123
Function*1Default settingCustomized set- ting
Language*2EnglishFrenchOO—Spanish
Units*2miles (MPG US)
km (km/L)
OO—km (L/100 km)
miles (MPG Imperial)
Maintenance system ini-
tialization
*3OffOn—O—
Eco Driving Indicator
LightOn
(Self-lighting)Off—O—
123

6649-2. Customization
HIGHLANDER_U (OM48A12U)
*1: For details about each function: P. 99, 104
*2: The default setting varies according to country.
*3: U.S.A. only
*4: Some status screens cannot be registered (indicated on multi-information
display).
*5: 6 of the following items: current fuel consumption, average fuel economy
(after reset), average fuel economy (after refuel), average fuel economy
(after start), average vehicle speed (after reset), average vehicle speed
(after start), distance (driving range), elapsed time (after reset), elapsed
time (after start), distance (after star t), driving distance (after reset), blank.
*6: Speed limit display may not be available for some regions.
switch settingsDrive informa-
tion 1Desired status screen
*4—O—
Drive information 1
Current fuel con-
sumption
*5
—O—
Average fuel
economy (after
reset)
—O—
Drive information 2
Distance (driving range)
*5
—O—
Average fuel
economy (after refueling)
—O—
Drive information 3
Driving distance (after reset)
*5
—O—
Average vehicle
speed (after reset)
—O—
Pop-up displayOnOff—O—
Accent colorLight blue
Blue
OO—Orange
Ye l l o w
Speed limit display*6
On with the
speed limit cau- tion indicator
(yellow) enabled
On with the
speed limit cau-
tion indicator (yellow) not enabled
—OO
Off
Function*1Default settingCustomized set-
ting123

6699-2. Customization
9
Vehicle specifications
HIGHLANDER_U (OM48A12U)■
Automatic light control system (
P. 241)
■Lights ( P. 241)
*: U.S.A. only
■
Intuitive parking assist*1 (Refer to “Navigation and Multimedia
System Owner’s Manual”)
*1: If equipped
*2: When intuitive parking assist is operating.
■
Automatic air conditioning system* (  P. 428)
*: If equipped
FunctionDefault settingCustomized set-
ting
Light sensor sensitivityStandard-2 to 2O—O
Time elapsed before
headlights automatically
turn off after doors are
closed
30 seconds
Off
O—O60 seconds
90 seconds
123
FunctionDefault settingCustomized set-ting
Daytime running light
system
*OnOffO—O
123
FunctionDefault settingCustomized set-ting
Detection distance of the
rear center sensorFarNearO—O
Buzzer volumeLevel 3Level 1 to 5O—O
Display setting*2All sensors dis-playedDisplay offO—O
123
FunctionDefault settingCustomized set- ting
A/C auto switch opera-
tionOnOffO—O
123

692What to do if... (Troubleshooting)
HIGHLANDER_U (OM48A12U)
●Is the electronic key left inside the vehicle or the moon roof or panoramic
moon roof open?
Check the message on the multi-information display. (P. 572)
●When a warning light turns on or a warning message or indicator is dis-
played, refer to P. 563, 572.
A warning buzzer sounds when leaving the vehicle
(vehicles with a smart key system)
A warning light turns on or a warning message or indicator
is displayed

697Alphabetical index
HIGHLANDER_U (OM48A12U)
Child-protectors....................... 126
Cleaning ........................... 484, 487Aluminum wheels.................. 485
Exterior ................................. 484
Interior................................... 487
Seat belts .............................. 488
Clock ......................................... 457
Coat hooks ............................... 464
Compass .................................. 479
Condenser................................ 509
Console box ............................. 447
Conversation mirror ................ 456
Cooling system ........................ 508 Engine overheating ............... 626
Cruise control Cruise control........................ 261
Dynamic radar cruise control................................. 266
Cup holders.............................. 449
Curtain shield airbags ............... 41
Customizable features ............ 662 DAC (Downhill Assist
Control system).................... 304
Daytime running light system.................................... 242
Deck board ............................... 454
Defogger
Outside rear view mirrors ........................ 424, 430
Rear window ................. 424, 430
Windshield .................... 423, 430
Dimensions .............................. 632
Dinghy towing.......................... 224
Display
Drive information ............ 97, 103
Dynamic radar cruise control ................................ 266
LDA (Lane Departure
Alert)................................... 281
Multi-information display .......................... 97, 101
Warning message ................ 572
Do-it-yourself maintenance .... 498
Door lock Doors .................................... 121
Smart key system ................. 121
Wireless remote control ........ 122D

698Alphabetical index
HIGHLANDER_U (OM48A12U)
DoorsAutomatic door locking
and unlocking system ......... 126
Back door.............................. 129
Door lock............................... 121
Door windows ....................... 178
Open door warning buzzer ... 124
Open door warning light ............................. 565, 574
Outside rear view mirrors...... 176
Rear door child-protector ...... 126
Side doors............................. 121
Downhill assist control system (DAC)......................... 304
Driver’s seat position memory .................................. 164
Driving ...................................... 192 Break-in tips .......................... 193
Correct driving posture ........... 28
Procedures ........................... 192
Winter drive tips .................... 323
Dynamic radar cruise control .................................... 266
Dynamic Torque Control AWD system .......................... 299 Eco Driving Indicator .............. 107
EDR (Event data recorder)........ 10
Electric Power Steering
(EPS) ...................................... 299Function ................................ 299
Warning light......................... 564
Electronic key .......................... 114 Battery-saving function ......... 149
If the electronic key does not operate properly ................. 618
Replacing the battery............ 532
Emergency flashers ................ 554
Emergency, in case of If a warning buzzer sounds................................ 563
If a warning light turns on ..... 563
If a warning message is displayed ............................ 572
If the battery is discharged ... 621
If the electronic key does not operate properly ........... 618
If the engine will not start ...... 615
If the shift lever cannot be shifted from P ..................... 617
If you have a flat tire ............. 590
If you think something is wrong ................................. 561
If your vehicle becomes stuck................................... 629
If your vehicle has to be
stopped in an emergency ... 555
If your vehicle needs to be towed.................................. 557
If your vehicle overheats....... 626E
