2014 TOYOTA DYNA 100/150 tow

STARTING AND DRIVING123
Section 3
STARTING AND DRIVING
DBefore starting the engine 124..........................
DHow to start the engine 124.............................
DPrecautions for turning off an engine
with turbocharger 126..................................
DPre−trip safety check 126..............................
DTips for driving in various conditions 127.................
DDriving in the rain 128..................................
DWinter driving tips 129.................................
DTrailer towing 130......................................
DHow to save fuel and make your vehicle last longer 138...
Dyna100/150_EE

130STARTING AND DRIVING
Keep the door locks from freezing.
Squirt lock de−icer or glycerine into the
locks to keep them from freezing. To open
a frozen lock, try heating the key before
inserting it.
Use a washer fluid containing an anti-
freeze solution.
This product is available at any authorized
Toyota dealer or repairer and most auto
parts stores or another qualified professio-
nal. Follow the manufacturer ’s directions
for how much to mix with water.
NOTICE
Do not use engine antifreeze or any
other substitute because it may dam-
age your vehicle’s paint.
Do not use your parking brake when
there is a possibility it could freeze.
When parking, put the transmission into
first or reverse and block the front
wheels. Do not use the parking brake, or
snow or water accumulated in and around
the parking brake mechanism may freeze,
making it hard to release.
Keep ice and snow from accumulating
under the fenders.
Ice and snow built up under your fenders
can make steering difficult. During bad
winter driving, stop and check under the
fenders occasionally.
Depending on where you are driving,
we recommend you carry some emer-
gency equipment.
Some of the things you might put in the
vehicle are tire chains, window scraper,
bag of sand or salt, flares, small shovel,
jumper cables, etc.Your vehicle is designed primarily as a
passenger−and−load−carrying vehicle. Tow-
ing a trailer will have an adverse effect on
handling, performance,braking,durability
and driving economy (fuel consumption,
etc.). Your safety and satisfaction depend
on the proper use of correct equipment
and cautious driving habits. For your safe-
ty and the safety of others, you must not
overload your vehicle or trailer. Ask your
local authorized Toyota dealer or repairer,
or another duly qualified and equipped
professional, for further details before tow-
ing, as there are additional legal require-
ments in some countries.
WEIGHT LIMITS
Before towing, confirm the towing capacity,
gross vehicle mass (GVM), maximum per-
missible axle capacity (MPAC) and draw-
bar load. They are listed on page 214 in
Section 8.
When towing a trailer, observe the follow-
ing:
DThe total trailer weight (trailer weight
plus its cargo load) is within the towing
capacity.
DWhen the total trailer weight is greater
than the vehicle weight, we recommend
the use of a friction stabilizer (sway
control device).
DWhen the total trailer weight is over
2000 kg (4409 lb.), a friction stabilizer
(sway control device) is required.
Dyna100/150_EE
Trailer towing

STARTING AND DRIVING131
Total trailer weight Drawbar load
DThe trailer cargo load should be distrib-
uted so that the drawbar load is more
than 25 kg (55.1 lb.) and more than
4% of the towing capacity. However,
the drawbar load must not exceed the
weight specified on page 214 in Sec-
tion 8.
DThe sum weight of the total curb mass,
driver, passengers, cargo, towing hitch
and drawbar load must not exceed
gross vehicle mass.
DThe load on the rear axle must not
exceed the maximum permissible rear
axle capacity.
Towing capacity has been tested at sea−
level. If you have to go to a high moun-
tain area, keep in mind that the engine
power and towing capacity will decrease.
Manufacturer’s label or plate
Gross vehicle mass
Maximum permissible rear
axle capacity
CAUTION
DThe total trailer weight must not
exceed the towing capacity speci-
fied on page 214 in Section 8. Ex-
ceeding this weight is dangerous.
DTrailer hitch assemblies have differ-
ent weight capacities established by
the hitch manufacturer. Even though
the vehicle may be physically capa-
ble of towing a higher weight, the
operator must determine the maxi-
mum weight rating of the particular
hitch assembly and never exceed
the maximum weight rating speci-
fied for the trailer−hitch. Exceeding
the maximum weight rating set by
the trailer hitch manufacturer can
cause an accident resulting in seri-
ous injuries.
Dyna100/150_EE

132STARTING AND DRIVING
DThe sum weight of the total curb
mass, driver, passengers, cargo,
towing hitch, and drawbar load
must not exceed the gross vehicle
mass. Exceeding this weight is dan-
gerous.
DThe load on the rear axle must not
exceed the maximum permissible
rear axle capacity. Exceeding this
weight is dangerous.
TOWING HITCH BRACKETS
Toyota recommends using a Toyota genu-
ine hitch and bracket. Another hitch and
bracket of matching quality can also be
used.
Installation positions for towing hitch
brackets and towing hitch ball overhang:
Dyna100/150_EE

STARTING AND DRIVING135
KDY261 models

mm (in.)
A
375 (14.8)
B400 (15.7)
C370 (14.6)
D540 (21.3)
E170 (6.7)
F200 (7.9)
G220 (8.7)
H240 (9.4)
I400 (15.7)
J365 (14.4)
K535 (21.1)
L615 (24.2)
M670 (26.4)
N835 (32.9)
O2010 (79.1)

: See “Model code” on page vi in the
beginning of this manual if you are not
sure of your vehicle model.
KDY261 models
TOWING BRACKETS
Toyota recommends using a Toyota genu-
ine bracket. Another bracket of matching
quality can also be used.
Dyna100/150_EE

136STARTING AND DRIVING
TIRES
DEnsure that your vehicle’s tires are
properly inflated. See page 193 in Sec-
tion 7−2 and page 218 in Section 8 for
instructions.
DThe trailer tires should be inflated to
the pressure recommended by the trail-
er manufacturer in respect to the total
trailer weight.
TRAILER LIGHTS
DCheck for correct operation of the turn
signals and stop lights each time you
hitch up. Direct splicing may damage
your vehicle’s electrical system and
cause a malfunction of your lights.
BREAK−IN SCHEDULE
DToyota recommends that you do not
tow a trailer with a new vehicle or a
vehicle with any new power train com-
ponent (engine, transmission, differen-
tial, wheel bearing, etc.) for the first
800 km (500 miles) of driving.
MAINTENANCE
DIf you tow a trailer, your vehicle will
require more frequent maintenance due
to the additional load.
DRetighten all fixing bolts of the towing
ball and bracket after approximately
1000 km (600 miles) of trailer driving.
PRE−TOWING SAFETY CHECK
DBe sure not to exceed designated max-
imum load for the ball coupling of the
towing bracket. Please remember that
the ball coupling load will increase the
load on the vehicle. Maximum permissi-
ble rear axle capacity must not be ex-
ceeded.
DMake sure the trailer cargo is securely
loaded so that it cannot shift.
DIf the traffic behind the trailer cannot
be seen properly with the standard rear
view mirrors, additional outside mirrors
will be necessary. Both outside mirrors
must be fitted on folding arms and ad-
justed to give a good rear view at all
times.
TRAILER TOWING TIPS
Your vehicle will handle differently
when towing a trailer. In order to avoid
accident, death or serious injury, keep
the following in mind when towing:
DBefore starting out, check operation of
the lights and all vehicle−trailer connec-
tions. After driving a short distance,
stop and recheck the lights and con-
nections. Before actually towing a trail-
er, practice turning, stopping and back-
ing with a trailer in an area away from
traffic until you learn the feel.
DBecause stopping distance may be in-
creased, vehicle−to−vehicle distance
should be increased when towing a
trailer. For each 10 km/h (6 mph) of
speed, allow at least one vehicle and
trailer length between you and the ve-
hicle ahead. Avoid sudden braking as
you may skid, resulting in jackknifing
and loss of control. This is especially
true on wet or slippery surfaces.
DAvoid jerky starts or sudden accelera-
tion. Prevent excessive clutch slippage
by keeping engine rpm low and not
racing the engine. Always start out in
first gear.
DAvoid jerky steering and sharp turns.
The trailer could hit your vehicle in a
tight turn. Slow down before making a
turn to avoid the necessity of sudden
braking.
Dyna100/150_EE

138STARTING AND DRIVING
CAUTION
DObserve the legal maximum speeds
for trailer towing.
DSlow down and downshift before
descending steep or long downhill
grades. Do not make sudden down-
shifts while descending steep or
long downhill grades.
DAvoid holding the brake pedal down
too long or too frequently. This
could cause the brakes to overheat
and result in reduced braking effi-
ciency.
Improving fuel economy is easy—just take
it easy. It will help make your vehicle last
longer, too. Here are some specific tips
on how to save money on both fuel and
repairs:
DKeep your tires inflated at the cor-
rect pressure.Underinflation causes
tire wear and wastes fuel. See page
193 in Section 7−2 for instructions.
DDo not carry unneeded weight in
your vehicle.Excess weight puts a
heavier load on the engine, causing
greater fuel consumption.
DAvoid lengthy warm−up idling.Once
the engine is running smoothly, begin
driving—but gently. Remember, howev-
er, that on cold winter days this may
take a little longer.
DAccelerate slowly and smoothly.
Avoid jackrabbit starts. Get into high
gear as quickly as possible.
DAvoid long engine idling.If you have
a long wait and you are not in traffic,
it is better to turn off the engine and
start again later.
DAvoid engine lugging or over−rev-
ving.Use a gear position suitable for
the road on which you are travelling.
DAvoid continuous speeding up and
slowing down.Stop−and−go driving
wastes fuel.
DAvoid unnecessary stopping and
braking.Maintain a steady pace. Try
to time the traffic signals so you only
need to stop as little as possible or
take advantage of through streets to
avoid traffic lights. Keep a proper dis-
tance from other vehicles to avoid sud-
den braking. This will also reduce wear
on your brakes.
DAvoid heavy traffic or traffic jams
whenever possible.
DDo not rest your foot on the clutch
or brake pedal.This causes premature
wear, overheating and poor fuel econo-
my.
Dyna100/150_EE
How to save fuel and make
your vehicle last longer

IN CASE OF AN EMERGENCY141
Section 4
IN CASE OF AN EMERGENCY
DIf your vehicle will not start 142..........................
DIf your engine stalls while driving 147....................
DIf you cannot increase engine speed 147.................
DIf your vehicle overheats 148...........................
DIf you have a flat tire 149...............................
DIf your vehicle becomes stuck 162.......................
DIf your vehicle needs to be towed 163....................
DIf you lose your keys 166...............................
DIf your vehicle has to be stopped in an emergency 167....
Dyna100/150_EE
