772. Instrument cluster
2
Instrument cluster
COROLLA_TMMMS_TMMC_U (OM12F00U)
Tachometer
Displays the engine speed in revolutions per minute.
Speedometer
Fuel gauge
Drive monitor display
The drive monitor display presents the driver with a variety of driving-
related data including the current outside air temperature.
Gauges and meters (drive monitor display)
The displayed content may differ depending on the type of
meter.
1
2
3
4

782. Instrument cluster
COROLLA_TMMMS_TMMC_U (OM12F00U)
Engine coolant temperature
gauge
Displays the engine coolant tem-
perature.
Eco Driving Indicator Zone Dis-
play
* (P. 9 0 )
Outside temperature display
(P. 404)
Shift position and gear position indicator
* (P. 172, 174)
Trip information (P. 7 9 )
*: Except vehicles with a manual transmission
When the tail lights are on, the brightness of the instrument panel
lights can be adjusted. (On vehicles with an automatic light control
system, the instrument panel lights can be adjusted when the sur-
rounding area is dark and the tail lights are on.)
The brightness of the clock light can be adjusted regardless of
whether the tail lights are on or off.
Brighter
Darker
Drive monitor display
1
2
3
Instrument panel light control
4
5
1
2

822. Instrument cluster
COROLLA_TMMMS_TMMC_U (OM12F00U)
Tachometer
Displays the engine speed in revolutions per minute.
Speedometer
Fuel gauge
Multi-information display
The multi-information display presents the driver with a variety of driving-
related data including the current outside air temperature.
Display change button
Switches the trip information.
Engine coolant temperature gauge
Displays the engine coolant temperature.
Gauges and meters (multi-information dis-
play)
The displayed content may differ depending on the type of
meter.
1
2
3
4
5
6

882. Instrument cluster
COROLLA_TMMMS_TMMC_U (OM12F00U)
CAUTION
■The display at low temperatures
Allow the interior of the vehicle to warm up before using the display. At
extremely low temperatures, the display monitor may respond slowly, and
display changes may be delayed.
For example, there is a lag between the driver’s shifting and the new gear
number appearing on the display. This lag could cause the driver to down-
shift again, causing rapid and excessive engine braking and possibly an
accident resulting in death or injury.
■Cautions during setting up the display
As the engine needs to be running during setting up the display, ensure that
the vehicle is parked in a place with adequate ventilation. In a closed area
such as a garage, exhaust gases including harmful carbon monoxide (CO)
may collect and enter the vehicle. This may lead to death or a serious
health hazard.
NOTICE
■To prevent damage to the engine and its components
●Do not let the indicator needle of the tachometer enter the red zone, which
indicates the maximum engine speed.
●The engine may be overheating if the engine coolant temperature gauge
are in the red zone. In this case, immediately stop the vehicle in a safe
place, and check the engine after it has cooled completely. (P. 537)

4908-2. Steps to take in an emergency
COROLLA_TMMMS_TMMC_U (OM12F00U)
●Fluid leaks under the vehicle.
(Water dripping from the air conditioning after use is normal.)
●Flat-looking tires or uneven tire wear
●Vehicles without a multi-information display: High engine coolant
temperature warning light comes on.
●Vehicles with a multi-information display: Engine coolant tempera-
ture gauge needle continually points higher than normal.
●Changes in exhaust sound
●Excessive tire squeal when cornering
●Strange noises related to the suspension system
●Pinging or other noises related to the engine
●Engine missing, stumbling or running roughly
●Appreciable loss of power
●Vehicle pulls heavily to one side when braking
●Vehicle pulls heavily to one side when driving on a level road
●Loss of brake effectiveness, spongy feeling, pedal almost touches
the floor
If you think something is wrong
If you notice any of the following symptoms, your vehicle proba-
bly needs adjustment or repair. Contact your Toyota dealer as
soon as possible.
Visible symptoms
Audible symptoms
Operational symptoms

5378-2. Steps to take in an emergency
8
When trouble arises
COROLLA_TMMMS_TMMC_U (OM12F00U)
●Vehicles without a multi-information display: The high engine cool-
ant temperature warning light (P. 492) comes on or a loss of
power is experienced.
Vehicles with a multi-information display: The engine coolant tem-
perature gauge (P. 82) enters the red zone or a loss of power is
experienced.
●Steam comes out from under the hood.
Stop the vehicle in a safe place and turn off the air conditioning sys-
tem, and then stop the engine.
If you see steam:
Carefully lift the hood after the steam subsides.
If you do not see steam:
Carefully lift the hood.
After the engine has cooled
down sufficiently, inspect the
hoses and radiator core (radia-
tor) for any leaks.
Radiator
Cooling fan
If a large amount of coolant
leaks, immediately contact your
Toyota dealer.
The coolant level is satisfactory
if it is between the “F” and “L”
lines on the reservoir.
Reservoir
“F” line
“L” line
Radiator cap
If your vehicle overheats
The following may indicate that your vehicle is overheating.
Correction procedures
1
2
3
1
2
4
1
2
3
4

603Alphabetical index
COROLLA_TMMMS_TMMC_U (OM12F00U)
Eco drive mode ........................ 175
Eco Driving Indicator ................ 89
Electric Power Steering
(EPS)....................................... 211
Function ................................ 211
Warning light ......................... 493
Electronic key ............................ 92
Battery-saving function ......... 114
If the electronic key does not
operate properly ................. 529
Replacing the battery ............ 464
Emergency, in case of
If a warning buzzer
sounds ................................ 492
If a warning light turns on...... 492
If a warning message or
indicator is displayed .......... 504
If the battery is discharged.... 532
If the electronic key does not
operate properly ................. 529
If the engine will not start ...... 526
If the shift lever cannot be
shifted from P ..................... 528
If you have a flat tire ............. 514
If you think something is
wrong.................................. 490
If your vehicle becomes
stuck ................................... 540
If your vehicle has to be
stopped in an emergency ... 483
If your vehicle needs to be
towed .................................. 485
If your vehicle overheats ....... 537Emergency flashers ................ 482
Engine ...................................... 546
Compartment ........................ 435
Engine switch ............... 161, 164
Hood ..................................... 431
How to start the
engine ........................ 161, 164
Identification number ............ 545
If the engine will not start ...... 526
Ignition switch
(engine switch) ........... 161, 164
Overheating .......................... 537
Engine coolant......................... 440
Capacity................................ 548
Checking............................... 440
Preparing and checking
before winter ...................... 216
Engine coolant temperature
gauge ................................. 77, 82
Engine immobilizer system ...... 66
Engine oil ................................. 436
Capacity................................ 546
Checking............................... 436
Preparing and checking
before winter ...................... 216
Engine switch .................. 161, 164
EPS
(Electric Power Steering) ..... 211
Function ................................ 211
Warning light......................... 493
