4-3. Do-it-yourself maintenance
4
Maintenance and care
■
After recharging/reconnecting the 12-volt battery
●Unlocking the doors using the smart key system may not be possible
immediately after reconnecting the 12-volt battery. If this happens, use
the wireless remote control or the mechanical key to lock/unlock the
doors.
● Start the hybrid system with the “POWER” switch in ACCESSORY mode.
The hybrid system may not start with the “POWER” switch turned off.
However, the hybrid system will operate normally from the second
attempt.
● The “POWER” switch mode is recorded by the vehicle. If the 12-volt bat-
tery is reconnected, the vehicle will return the “POWER” switch mode to
the status it was in before the 12-volt battery was disconnected. Make
sure to turn off the power before disconnect the 12-volt battery. Take
extra care when connecting the 12-volt battery if the “POWER” switch
mode prior to discharge is unknown.
If the system will not start even after multiple attempts, contact your Toyota
dealer.
CAUTION
■ Chemicals in the 12-volt battery
The 12-volt battery contains poisonous and corrosive sulfuric acid and may
produce hydrogen gas which is flammable and explosive. To reduce the risk
of death or serious injury, take the following precautions while working on or
near the 12-volt battery:
●Do not cause sparks by touching the 12-volt battery terminals with tools.
● Do not smoke or light a match near the 12-volt battery.
● Avoid contact with eyes, skin and clothes.
● Never inhale or swallow electrolyte.
● Wear protective safety glasses when working near the 12-volt battery.
● Keep children away from the 12-volt battery.
■ Where to safely charge the 12-volt battery
Always charge the 12-volt battery in an open area. Do not charge the 12-volt
battery in a garage or closed room where there is insufficient ventilation.

459
4-3. Do-it-yourself maintenance
4
Maintenance and care
■
Use a CR2032 lithium battery
●Batteries can be purchased at your Toyota dealer, local electrical appli-
ance shops or camera stores.
● Replace only with the same or equivalent type recommended by the
manufacturer.
● Dispose of used batteries according to local laws.
■ If the key battery is depleted
The following symptoms may occur:
●The smart key system and wireless remote control will not function prop-
erly.
● The operational range will be reduced.
CAUTION
■Removed battery and other parts
These parts are small and if swallowed by a child, they can cause choking.
Keep away from children. Failure to do so could result in death or serious
injury.
NOTICE
■ For normal operation after replacing the battery
Observe the following precautions to prevent accidents:
●Always work with dry hands.
Moisture may cause the battery to rust.
● Do not touch or move any other components inside the remote control.
● Do not bend either of the battery terminals.

577
6-2. Customization
6
Vehicle specifications
ItemFunctionDefault set-
tingCustomizedsetting
Smart key
system and
wireless
remote
control
(
P. 51,
64) Operation sig-
nal
(Emergency
flashers)
On Off — O O
Operation sig-
nal
(Buzzer) On Off — — O
Operation
buzzer volume Level 5 Off to level 7 O O O
Time elapsed
before auto-
matic door lock
function is acti-
vated if door is
not opened
after being
unlocked 60 seconds
Off
—O O
30 seconds
120 seconds
Open door
warning buzzer On
Off — — O
Smart key
system
(
P. 5 1 ) Smart key sys-
tem
On Off — — O
Number of per-
missible times
of continuous
smart lock Twice Unlimited — — O

578 6-2. Customization
Wireless
remote
control
(
P. 64)Wireless
remote control
On Off — — O
Unlocking
operation Driver's door
unlocked in
one step, all doors
unlocked in two steps All doors
unlocked in one step. OOO
Panic function On Off — — O
Trunk unlock-
ing operation Press and
hold (short) Off
—— O
Press twice
One short press
Press and
hold (long)
ItemFunctionDefault set- tingCustomizedsetting

581
6-2. Customization
6
Vehicle specifications
*: If equipped
Power win-
dow
(driver’s
door) &
moon roof
*
(
P. 95,
98) Key linked
opening
Off On — — O
Wireless
remote control
linked opening Off On — — O
Key linked clos-
ing Off On — — O
Wireless
remote control
linked opening
buzzer On Off — — O
Moon roof
*
( P. 98) Linked opera-
tion of compo-
nents when
door key is
used
Slide only Tilt only
—— O
Linked opera-
tion of compo-
nents when
wireless
remote control
is used Slide only Tilt only
—— O
ItemFunctionDefault set-
tingCustomizedsetting

603
Alphabetical index
Garage door opener ................ 391
Gas station information .......... 612
Gauges ..................................... 174
Glove box ................................. 368
Grocery bag hooks ................. 390
Hazard lights
Switch ................................... 484
Head restraints Adjusting ................................ 81
Headlights Replacing light bulbs ............ 471
Switch ................................... 192
Wattage ................................ 560
Heaters Outside rear view mirror ....... 248
Seat heater ........................... 383
Hill-start assist control ........... 207
Hood ......................................... 426
Hooks Grocery bag hooks ............... 390
Horn .......................................... 173
Hybrid system
Emergency shut off system .... 36
Energy monitor/consumption screen .................................. 41
High voltage components ....... 35
Hybrid system indicator ........ 180
“POWER” switch .................. 157
Vehicle Proximity Notification System .............. 31 I/M test.......................................422
Identification number
Electric motor ........................551
Engine ...................................551
Vehicle ..................................551
Ignition switch ..........................157
Illuminated entry system .........366
Immobilizer system..................106
Indicator lights .........................180
Initialization Items to initialize....................582
Inside rear view mirror ..............91
Interior lights Interior lights..........................364
Switch....................................365
Wattage .................................560
Jack Positioning a floor jack ..........427
Vehicle-equipped jack ...........519
Jack handle ..............................519
Keyless entry..............................64
Keys Electronic key ..........................48
If the electronic key does not operate properly............ 535
If you lose your keys .............534
Ignition switch........................157
Key number .............................48
Keyless entry...........................64
Keys ........................................48
Mechanical key .......................48
“POWER” switch ...................157
Wireless remote control key ....64G
H
I
J
K

608 Alphabetical index
Warning buzzersBrake system ........................ 490
Electric power steering
system ................................ 491
Open door ............................. 493
Seat belt reminder ................. 493
Warning lights Anti-lock brake system .......... 491
Brake assist system .............. 491
Brake system ........................ 490
Charging system .... ............... 491
Electric power steering system ................................ 491
Engine coolant
temperature ........................ 491
Engine oil pressure ............... 491
Low fuel level ........................ 493
Low tire pressure warning light ..................................... 493
Malfunction indicator lamp .... 491
Master warning light .............. 493
Open door ............................. 493
Pretensioners ........................ 491
Seat belt reminder light ......... 493
Slip indicator.......................... 491
SRS airbags .......................... 491
Tire pressure warning light .... 493
Warning messages Blind Spot monitor ......... 502, 503
Cruise control ........................ 502
EV drive mode....................... 503
Headlight ............................... 503
Hood...................................... 503
Hybrid system ....................... 501
Hybrid system overheat ........ 503
Maintenance.......................... 503
Moon roof .............................. 503
N position .............................. 503
Open door ............................. 503
Parking brake ........................ 503
P position .............................. 503
Smart key system.......... 502, 510
Steering lock ......................... 502 Traction battery ..................... 503
Trunk ..................................... 503
Washer fluid .......................... 503
Washer Preparing and checking
before winter ....................... 229
Refilling ................................. 438
Switch ................................... 200
Washing and waxing ............... 410
Weight Cargo capacity ...................... 224
Load limits ............................. 228
Weight ................................... 550
Wheels ...................................... 453
Window glasses ........................ 95
Window lock switch................... 95
Windows
Power windows ....................... 95
Rear window defogger .......... 248
Washer.................................. 200
Windshield wipers ................... 200
Wireless remote control key Replacing the battery ............ 458
Wireless remote control .......... 64
WMA disc.................................. 274W
