2014 Ram ProMaster clock setting

▫Uconnect® RH3 Display .................155
▫ General Functions And Settings ...........156
▫ Tuner Mode (AM/FM Radio) .............159
▫ Setup Menu ........................ .162
▫ Clock ............................. .163
▫ USB Mode (MP3/WMA/AAC) ...........163
 Uconnect® SETTINGS ....................171
▫ Hard-Keys ......................... .172
▫ Soft-Keys .......................... .172
▫ Customer Programmable Features —
Uconnect® 5.0/5.0N Settings .............172
Uconnect® RADIOS .....................182

iPod®/USB/MP3 CONTROL — IF EQUIPPED . . .182
▫ USB Charging Port ....................183
 STEERING WHEEL AUDIO CONTROLS ......184
▫ Radio Operation ..................... .185
 CD DISC MAINTENANCE ...............185

RADIO OPERATION AND MOBILE PHONES . . .186
 CLIMATE CONTROLS ...................186
▫ Manual Heating And Air Conditioning ......186
124 UNDERSTANDING YOUR INSTRUMENT PANEL

•Auto Lock
• Units (Distance, Fuel Economy, Temperature)
• Language
• Buzzer Volume
• Seat Belt Buzzer — If Equipped
• Passenger Air Bag — If Equipped
NOTE:
• If equipped with Uconnect® 5.0 radio, some customer
programmable features will display in the Uconnect®
5.0 system. Refer to the radio supplement for further
Uconnect® 5.0 information.
• The EVIC clock setting and Uconnect® 5.0 clock set-
ting procedure can be done through the radio or the
EVIC Selecting An Option Of The Main Menu Without
Submenu
1. Briefly press the
MODEbutton to select the main
menu option to set.
2. Press the UP
or DOWNbutton (by single
presses) to select the new setting.
3. Briefly press the MODEbutton to store the new
setting and go back to the main menu option previ-
ously selected.
Selecting An Option Of The Main Menu With
Submenu
1. Briefly press the MODEbutton to display the first
submenu option.
2. Press the UP
or DOWNbutton (by single
presses) to scroll through all the submenu options.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 145

General
•Separate BASS and TREBLE settings
• BALANCE/FADE (balances left/right and front/rear
channels)
• Equalizer
• Loudness
• Digital clock in 24-hour format with weekday setting
• Illuminated buttons and display
• LCD display
• Extended functions field (Setup MENU) allows you to
change the default settings
Uconnect® RH3 Display
Description Of Commands
Rotary Knob: Turn radio on and off, volume, forward/
reverse track, confirm selected option.
Display Panel
4
UNDERSTANDING YOUR INSTRUMENT PANEL 155

And Buttons: Station search in automatic mode,
station search in manual mode, forward/reverse tracks,
forward/reverse within track.
Mute/Pause Button: Interrupts the sound by muting or
pausing the audio.
DISP Button: Switches between display modes, clock
display.
SRC Button: Switches the audio source to TUNER.
switches the audio source to USB.
Fast Track Buttons (F-Trk): Fast forward/reverse track
(used with the ROTARY knob).
Audio Button: Activates audio setting functions.
Preset Buttons (1 To 6): Store station in memory, access
preset stations.
Buttons 1 And 2: Forward/reverse folder. Band/AS Button:
Select tuned frequency band, preset
best stations.
Menu Button: Access setup menu.
General Functions And Settings
Turn The Radio On Or Off
To turn the radio on or off, push the ROTARY knob (press
once to turn on and hold for about three seconds to turn
off), not dependent on the ignition position.
The default radio configuration is Auto Switchand
OFF (see SETUP MENU section). In this configuration,
the radio will only consider the ignition switch position
when it executes the 60 min function: when the ignition is
turned off, the radio will display the message 60 MIN
for three seconds and switch off automatically after
60 minutes if no buttons are pressed.
156 UNDERSTANDING YOUR INSTRUMENT PANEL

Setup Menu
You can use the Setup menu to change the various factory
settings to suit your own preferences.
Press MENU to activate the Maximum Volume function.
Repeatedly pressing this button will activate the other
functions in the following sequence: Maximum Volume
(MVOL)
Auto Switch (AUTO)Beep (BEEP)
Set Clock (SEG 00:00)Maximum Volume
(MVOL). If this button or the button for adjusting the
selected function is not pressed for five seconds or if
the ROTARY knob is pressed, the display returns to
the previous view and the changes will be saved.
Maximum Volume
This function allows you to set the maximum permissible
volume. Turn the ROTARY knob to set the volume. The
display will show a message in the format MVOL 26
indicating the maximum volume selected. When the maximum volume selected is the maximum radio vol-
ume, the display will show
MVOL OFF.
Auto Switch
This function changes the on/off sequence of the radio as
described in the section: Turning the device on and off.
To enable it, turn the ROTARY knob clockwise. The
display will show AUTO ON. To disable it, turn the
ROTARY knob counterclockwise and the display will
show AUTO OFF.
Beep
With this feature is enabled, the radio will emit a beep
when any knob is activated.
Clock settings
When you select this function, the display will show the
clock. To select the field to be set, press
or. Turn
the ROTARY knob to adjust the selected field.
162 UNDERSTANDING YOUR INSTRUMENT PANEL

Hard-Keys
Hard-Keys are located below the Uconnect® system in
the center of the instrument panel. In addition, there is a
Scroll/Enter control knob located on the right side. Turn
the control knob to scroll through menus and change
settings (i.e., 30, 60, 90), press the center of the control
knob one or more times to select or change a setting (i.e.,
ON, OFF).
Your Uconnect® system may also have a Screen Off and
Back hard-keys located on the radio.
Press the Screen Off hard-key to turn off the Uconnect®
screen. Press the Screen Off hard-key a second time to
turn the screen on.
Press the Back hard-key to exit out of a Menu or certain
option on the Uconnect® system.
Soft-Keys
Soft-Keys are accessible on the Uconnect® display.
Customer Programmable Features — Uconnect®
5.0/5.0N Settings
Press the Settings hard-key to display the menu setting
screen. In this mode the Uconnect® system allows you to
access programmable features that may be equipped
such as Display, Clock, Safety/Assistance, Lights, Doors
& Locks, Audio and Phone/Bluetooth®.
NOTE:Only one touchscreen area may be selected at a
time.
When making a selection, press the soft-key to enter the
desired mode. Once in the desired mode, press and
release the preferred setting until a check-mark appears
next to the setting, showing that setting has been se-
lected. Once the setting is complete, either press the Back
Arrow soft-key or the Back hard-key to return to the
previous menu or press the X soft-key to close out of the
settings screen. Pressing the Up or Down Arrow soft-keys
172 UNDERSTANDING YOUR INSTRUMENT PANEL

•Touchscreen Beep
When in this display, you may turn on or shut off the
sound heard when a touch screen button (soft-key) is
pressed. Touch the Touchscreen Beep soft-key until a
check-mark appears next to the setting, showing that
setting has been selected. Touch the arrow back / Done
soft-key to return to the previous menu.
• Display Trip B
Press the relevant button to activate/deactivate the dis-
playing of the Trip B on the instrument panel display.
Clock & Date
After pressing the Clock soft-key the following settings
will be available:
• Time and Format
When in this display, you may set the time and choose
the format to display the time. Touch the 12h/24h AM and/or PM soft-key until a check-mark appears next to
the setting, showing that setting has been selected. Touch
the arrow back/Done soft-key to return to the previous
menu. If 24h is selected, AM/PM soft-keys will be greyed
out (unavailable).
•
Sync Date
When in this display, you may choose to set the date
automatically. Touch the Sync Date soft-key until a
check-mark appears next to the setting, showing that
setting has been selected. Touch the arrow back/Done
soft-key to return to the previous menu.
• Set Date
When in this display, you may set the date manually.
Touch the Set Date soft-key until a check-mark appears
next to the setting, showing that setting has been se-
lected. Touch the arrow back/Done soft-key to return to
the previous menu.
174 UNDERSTANDING YOUR INSTRUMENT PANEL

exclude undesirable channels while scanning. To make
your selection, touch the “Channel Skip” soft-key, select
the channels you would like to skip followed by pressing
the back arrow soft-key.
•Subscription Information
New vehicle purchasers or lessees will receive a free
limited time subscription to SiriusXM Satellite Radio
with your radio. Following the expiration of the free
services, it will be necessary to access the information on
the Subscription Information screen to re-subscribe.
Touch the “Subscription Info” soft-key to access the
Subscription Information screen.
Write down the SIRIUS ID numbers for your receiver.
To reactivate your service, either call the number listed on
the screen or visit the provider online.
NOTE: SiriusXM Travel Link is a separate subscription
and is available for U.S. residents only.Restore Settings
After pressing the Restore Settings soft-key the following
settings will be available:
• Restore Settings
When this feature is selected it will reset Display, Clock,
Audio, and Radio Settings to their default. To restore the
settings to their default setting touch the Yes or No
soft-key. A check mark will appear in the box when
selected. Then touch the arrow back/Done soft-key.
System Information
After pressing the “System Information” button on the
touchscreen the following settings will be available:
• System Information
When System Information is selected, a System Informa-
tion screen will appear displaying the system software
version.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 181
