6
SEAT ADJUSTMENTS
To slide the seat forward or backward, pull up on the lever
01 under the front of the seat and slide
forward or backward. Release the lever to lock the
seat in position.
To recline the seatback, pull up on the lever 02
and lean back. To bring the seatback forward, pull
the lever up and lean your body forward. Release
the lever to lock the seatback in position.
S
EA
T
LIFTER
(if so equipped for driver
’s seat)
Turn either dial 03 to adjust the angle and height of
the seat cushion to the desired position.
LU M BAR SU PPORT (if so equipped for driver’s seat)
To adjust the seat lumbar area, move the lever 04
forward or backward.
For more information, refer to the “Safety –– Seats, seat belts and
supplemental restraint system (section 1)” of your Owner’s Manual.
REMOTE KEYLESS ENTRY SYSTEM
The Remote keyless Entry System allows you to lock or
unlock your vehicle and turn on the interior lights.
To lock the vehicle, press the
button on your key fob.
To unlock the driver’s door, press the
button on
your key fob.
Press the button again within 5 seconds and all doors will unlock.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
LIFTGATE RELEASE
Unlock the liftgate by pressing the
button on the
key fob twice.
To open the liftgate, pull up on the handle 01.
For more information, refer to the “Pre-driving checks and adjustments
(section 3)” of your Owner’s Manual.01
02
04
01
03
first drive features
1631777_14b_Xterra_NAM_QRG_120413.indd 612/4/13 11:30 AM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
