CLIMATE CONTROLS
01 FAN SPEED CONTROL DIAL
Turn the fan speed control dial to the left (low) or right (high) to control fan speed.
02 TE MPERATURE CONTROL DIAL
Turn the temperature control dial left for cooler air or right for warmer\
air.
03 AIR FLOW CONTROL BUTTONS
Select the air flow outlets by pressing the corresponding air flow c\
ontrol button:
Air flows from the center and side vents.
Air flows from the defroster and foot vents.
Air flows mainly from the foot vents.
Air flows from the center, side and foot vents.
04 D EFROSTING/DEFOGGING FRONT AND SIDE WINDOWS
Press the front window defroster button to turn the system on. The A/C automatically
turns on when the defroster mode is selected. This feature removes humidity from the air.
Set the fan speed control dial 01 and the temperature control dial 02 to their maximum settings.
05 R EAR WINDOW DEFROSTER BUTTON
Push the rear window defroster switc
h to turn the system on or off.
The rear window defroster automatically turns off after approximately 15 minutes.
06 Pull the lever toward you to activate the washer .
The front wipers will operate several times.
REAR WIN
d
S
HIEL
d W
IPER AN d
W
ASHER
07 Intermittent (I NT) - Rear wiper operates
intermittently.
08 Low (ON) - Rear wiper operates at a continuous
low-speed.
09 Push the lever forward to activate the rear washer .
The rear wiper will operate several times.
For more information, refer to the “Instruments and controls (section 2)”
of your Owner’s Manual.
INT
ON07
08
0609
1631777_14b_Xterra_NAM_QRG_120413.indd 912/4/13 11:30 AM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
11
03 SEEK BUTTONS
To tune and stop at the next or previous broadcast station, press the seek buttons or .
For satellite radio, to switch to the first channel of the previous or next category,
press the seek buttons
or .
To change tracks on a Cd , press the seek buttons or .
To fast forward or rewind a track on a Cd , press and hold the seek buttons or .
04 STATION SELECT BUTTONS
Twelve stations can be set for the FM band, six for the AM band and eighteen for
satellite radio.
To store a station in a preset, you must first select a radio band by pressing the \
FM•AM button
05 or SXM button 06 then tune to the desired FM, AM or XM satellite
radio station.
For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (section 4)” of your
Owner’s Manual.
USB/ AUX JACK AND iPOD® INTERFACE
(if so equipped)
The USB/Aux jack 01 is located inside the center
console storage box.
When a compatible USB memory device, iPod® or
auxiliary device is plugged into the USB/Aux jack,
compatible audio files stored on the device can be
played through the vehicle’s audio system.
For more information, refer to the “Monitor, climate, audio, phone and
voice recognition systems (section 4)” of your Owner’s Manual.
