2014 NISSAN ROGUE light

*See your Owner’s Manual for information.01
VEHICLE INFORMATION DISPLAY*
02
HEADLIGHT AND TURN SIGNAL
CONTROL
03
LOW TIRE PRESSURE WARNING LIGHT
04
INSTRUMENT BRIGHTNESS

CONTROL SWITCH*
05
TWIN TRIP ODOMETER RESET BUTTON
06
WINDSHIELD WIPER / WASHER SWITCH
07
STEERING WHEEL SWITCHES
FO
R AUDIO CONTROL* / NAVIGATION/
VEHICLE INFORMATION DISPLAY
08
CRUISE CONTROL/ BLUETOOTH
®
SWITCHES
09
VEHICLE DYNAMIC CONTROL (VDC)
OFF SWITCH*
10
SPORT MODE SWITCH
11 POWER LIFTGATE SWITCH
12
POWER LIFTGATE MAIN SWITCH
13
SAFETY SHIELD BUTTON
14
AWD LOCK SWITCH*
15
HILL DESCENT CONTROL SWITCH
16
STEERING WHEEL TILT ADJUSTMENT
17
FUEL-FILLER DOOR RELEASE
18
HOOD RELEASE*
19
AUDIO AND NAVIGATION SYSTEM
20
AUTOMATIC CLIMATE CONTROLS
21
FRONT PASSENGER AIR BAG
STATUS LIGHT*
22
USB/AUX JACK/POWER OUTLET
01
10
03
04
11
19
12
16
05
06
18
17
02
07
08
14
13
21
22
20
09
15
BEHIND STEERING
WHEEL
1766904_14d_Rogue_QRG_062514.indd 46/25/14 3:29 PM

TABLE OF CONTENTS
NEW SYSTEM FEATURES Around View® Monitor with Moving Object Detection (MOD)
(if so equipped) ................................................2 Sport Mode ...................................................3 Blind Spot Warning (B

SW) System (if so equipped)

.....................
3 Lane Departure Warning (LD

W) System (if so equipped)

.................
4 Forward Collision W

arning (FCW) System (if so equipped)
................4 Hill Start Assist (H

SA) System
........................................4 Hill Descent Control (HD

C) System (if so equipped)
.....................5 All-Wheel Drive (A

WD) Indicator Lights
.................................5
ES

SENTIAL INFORMATION
Tire Pressure Monitoring System (TP

MS) with Easy Fill Tire Alert
.......6
Loose Fuel Cap................................................7 Fuel-filler Door.................................................7
Towing Y

our Vehicle
.............................................7
Outside Temperature Display.....................................8 Divide-N-Hide® Floor (if so equipped)..............................8 Clock Set/
Adjustment...........................................9
FIR
ST DRIVE FEATURES
NI

SSAN Intelligent Key
® System (if so equipped)...................10 Po
wer Liftgate (if so equipped)....................................11 Front Seat Adjustments.........................................11 2ND Row Seats................................................12 3RD Row Seats (if so equipped)..................................12 Outside Mirror Control Switch...................................12 Starting/Stopping the Engine....................................13
Headlight Control Switch .......................................13
Windshield W

iper and Washer Switch
............................14 Automatic Climate Controls (if so equipped) .......................15 F

M/AM/SiriusXM
® Satellite Radio with CD Player (if so equipped).....16 Cruise Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . 17 US

B (Universal Serial Bus) Connection Port/Aux Jack and iPod
® Interface 17 Power Panoramic Moonroof (if so equipped).......................18 Center Console Storage box ....................................18 Tilt and T

elescopic Steering Wheel Adjustments
....................18
SY

STEM GUIDE
Vehicle Information Display......................................19 Bluetooth® Hands-free Phone System ............................20 System Operating Tips.......................................20 Bluetooth® System without Navigation (if so equipped)...............20 Bluetooth® System with Navigation (if so equipped) .................21 Navigation System (if so equipped)...............................23 HomeLink® Universal Transceiver (if so equipped).......................24
Please see your Owner’s Manual for important safety
information and system operation limitations.
•
A cellular telephone should not be used for any purpose while
driving so full attention may be given to vehicle operation.
• Always wear your seat belt.
• Supplement

al air bags do not replace proper seat belt usage.
•
Children 12 and under should always ride in the rear seat
properly secured in c

hild restraints or seat belts according to
their age and weight.
• Do not drink and drive.
For more information, refer to the “Safety — Seats, seat belts and
supplemental restraint system (section 1)”, “Center display, heater,
air conditioner, audio, phone and voice recognition systems (section
4)” and “Starting and driving (section 5)” of your Owner’s Manual.
Additional information about your vehicle is also available in your
Owner’s Manual, Navigation System Owner’s Manual and at www.nissanusa.com.
To view detailed
instructional videos, go to
www.nissanownersinfo.mobi/
2014/rogue
or snap this barcode with an appropriate barcode reader.
1766904_14d_Rogue_QRG_062514.indd 56/25/14 3:29 PM

3
BLIND SPOT WARNING (BSW) SYSTEM
(if so equipped)
The BSW system helps alert the driver of other vehicles
in adjacent lanes when c
hanging lanes.
The system will operate when the vehicle is driven at
speeds of approximately 20 mph (32 km/h) and above.
When the system detects a vehicle in the detection
zone, the blind spot indicator light
01, located near the
outside mirrors, will illuminate. If the turn signal is then
activated, the system chimes twice and the blind spot
indicator light flashes to alert the driver. The blind spot
indicator light continues to flash until the detected vehicle leaves t\
he detection zone.
Push the warning systems switch 02 to temporarily turn the system off. When the system is
off, the indicator light
03 on the switch is off.
The indicator light will also be off if all of the warning systems are de\
activated using the
settings menu.
For more information, refer to the “Instruments and controls (section 2)” and “Starting and driving (section 5)” of your
Owner’s Manual.
SPORT MODE
In the
SPORT mode, the engine and transmission are
controlled to set the engine speed higher than in the
D (DRIVE) position. This enhances throttle response
for a sporty driving feeling.
The SPORT mode switch 01 is located on the left side of the instrument panel.
To turn the
SP ORT mode on, push the SPORT mode switch. The SPORT mode indicator
light in the instrument panel illuminates. To turn the SPORT mode off, push the SPORT
mode switch again. The SPORT mode indicator light on the instrument panel will extinguish.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
01
02
03
02
03
01
There are some areas where the system will not
detect objects.
• When in the front or the rear view display

, an object
below the bumper or on the ground may not be detected
02.
• When in the bird’

s-eye view, a tall object near the
seam of the camera detecting areas
03 will not
appear in the monitor.
The distance between objects viewed on the
Around V iew® Monitor differs from the actual distance.
Objects in the bird’s-eye view will appear further than the
actual distance.
For more information, refer to the “Center display, heater, air conditioner, audio, phone and voice recognition systems
(section 4)” of your Owner’s Manual.
1766904_14d_Rogue_QRG_062514.indd 36/25/14 3:29 PM
To view detailed instructional videos regarding these and other features, please go\
to www.nissanownersinfo.mobi.

4
HILL START ASSIST (HSA) SYSTEM
The HSA system allows time for the driver to release the brake pedal and apply the accelerator
when the vehicle is parked on a hill. The brakes are applied automatically for 2 seconds after the
driver releases the brake pedal.
The Hill Start Assist will operate automatically under these conditions:
• Th
e shift lever is shifted into a forward or a reverse gear.
• Th

e vehicle is stopped completely on a hill by applying the brake.
The Hill Start Assist will not operate when the shift lever is in the N ( Neutral) or P (Park)
position or on a flat and level road.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
NEW SYSTEM FEATURES
LANE DEPARTURE WARNING (LDW) SYSTEM (if so equipped)
The LDW system helps alert the driver when the
v
ehicle is traveling too close to either the left or the
right side of a traveling lane.
The system will operate when the vehicle is driven
a t speeds of approximately 45 mph (70 km/h) and
above, and only when the lane markings are clearly visible on the road.
When the vehicle approaches either the left or the right of the traveling
l ane, the LDW system will chime and the orange LDW light
01 on the
instrument panel will blink to alert the driver.
The LDW system can be turned on and off through the settings menu in the vehicle
i nformation display. To temporarily turn off the system, push the warning systems switch
02.
When the system is off, the indicator light 03 on the switch is off.For more information, refer to the “Instruments and controls (section 2)” and “Starting and driving (section 5)” of your
Owner’s Manual.
01
02
03
FORWARD COLLISION WARNING (FCW)
SYSTEM (if so equipped)
The FCW system helps warn the driver with a help
a
lert light and chime when the vehicle is getting close
to a vehicle ahead in the traveling lane.
The FCW system operates at speeds of approximately 10 mph (15 km/h) and above.
The FCW system can be turned on and off in the vehicle information display through the
D
riving Aids menu
01. For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
01
1766904_14d_Rogue_QRG_062514.indd 46/25/14 3:29 PM
To view detailed instructional videos regarding these and other features, please go\
to www.nissanownersinfo.mobi.

5
HILL DESCENT CONTROL (HDC) SYSTEM (if so equipped)
The HDC system is designed to apply the brakes to help
control the speed of the vehicle and reduce the workload
of the driver while descending steep hills. To activate
the system:
The AWD Lock switch 01 must be on.
The Hill Descent Control system switch 02 must be ON. To deactivate the Hill Descent
Control system, push the switch
02 to the OFF position.
The shift lever must be in a forward or reverse gear.
The Hill Descent Control system operates at speeds of 15 mph (25 km/h) and below.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
02
ALL-WHEEL DRIVE (AWD) INDICATOR LIGHTS
With the ignition switch in the ON position, the AWD indicator light illuminates and
stays illuminated. The AWD indicator light
staying illuminated is a normal condition
and does not indicate a malfunction with the All-Wheel Drive system. Distribution of
torque to the front and rear wheels changes automatically, depending on the road
conditions encountered.
When AWD Lock is selected, both the AWD indicator light and the AWD Lock light
will illuminate.
For more information, refer to the “Instruments and controls (section 2)” and the “Starting and driving (section 5)”
of your Owner’s Manual.
01
1766904_14d_Rogue_QRG_062514.indd 56/25/14 3:29 PM
To view detailed instructional videos regarding these and other features, please go\
to www.nissanownersinfo.mobi.

6
ESSE NTIAL I N FOR MATION
TIRE PRESSURE MONITORING SYSTEM (TPMS)
WITH EASY FILL TIRE ALERT
A Tire Pressure Low - Add Air warning message
w ill appear in the vehicle information display
01
and the low tire pressure warning light
02
will illuminate when one or more tires are
low in pressure and air is needed.
• Th

e tire pressures should be checked when the
tires are cold. The tires are considered cold after
the vehicle has been parked for 3 hours or more or
driven less than 1 mi (1.6 km) at moderate speeds.
When adding air to an under-inflated tire, the TPMS with Easy Fill Tire Alert provides visual
a nd audible signals outside the vehicle to help you inflate the tires to the recommended
COLD tire pressure.
To use the Easy Fill Tire Alert system:
1. M

ove the shift lever to the P (PARK ) position and apply the parking brake.
2. P

lace the ignition switch in the ON position. Do not start the engine.
3. Ad

d air to the under-inflated tire, and within a few seconds the hazard warning lights will
start flashing.
4. Wh

en the designated tire pressure is reached, the horn will beep once and the hazard
warning flashers will stop flashing.
5. R

epeat this procedure for any additional under-inflated tires.
After tire pressures are adjusted, drive the vehicle at speeds above 16 mph (25 km/h).
T he Tire Pressure Low - Add Air warning message and low tire pressure warning light
will extinguish.
In addition to the Tire Pressure Low - Add Air warning message you can view the
i ndividual tire’s pressure in the vehicle information display as well as the recommended
pressure, denoted by blue lettering, for each tire.
When the low tire pressure warning light flashes for 1 minute and then remains on, the
T PMS is not functioning properly. Have the system checked by a NISSAN dealer.
Tire pressure rises and falls depending on the heat caused by the vehicle’s operation and
the outside temperature. Low outside temperature can lower the temperature of the air
inside the tire, which can cause a lower tire inflation pressure. This may cause the low tire
pressure warning light to illuminate. If the warning light illuminates, check the tire pressure
in your tires.
• Ch

eck the tire pressure (including the spare tire) often and always prior to long
distance trips.
The Tire and Loading Information label contains valuable information. Please refer to
“ Technical and consumer information (section 9)”, in your Owner’s Manual for the location
of the Tire and Loading Information label.
For more information, refer to the “Instruments and controls (section 2)”, the “Starting and driving (section 5)” and the
“Maintenance and do-it-yourself (section 8)” of your Owner’s Manual.
02
01
Tire Pressure
Low - Add Air
1766904_14d_Rogue_QRG_062514.indd 66/25/14 3:29 PM
To view detailed instructional videos regarding these and other features, please go\
to www.nissanownersinfo.mobi.

7
LOOSE FUEL CAP
A Loose fuel cap warning mess age will appear in
the vehicle information display
01 when the fuel-filler
cap is not tightened correctly.
To tighten, turn the cap clockwise until a single click
is heard.
The warning message will disappear when the
vehicle detects the fuel-filler cap is properly tightened and the
button, located on the
steering wheel, is pressed.
If the cap is not properly tightened, the Malfunction Indicator Light may illuminate.
For more information, refer to the “Instruments and controls (section 2)” and the “Pre-driving checks and adjustments
(section 3)” of your Owner’s Manual.
01
TOWING YOUR VEHICLE
ALL-WHEEL DRIVE (AWD) VEHICLE ( if so equipped)
• An all-wheel drive vehicle must be towed with all wheels off the groun\
d.
For proper towing and to avoid accidental damage to your vehicle, NISSAN recommends
that a service operator tow your vehicle after carefully reading the Own\
er
’s Manual precautions.
For more information, refer to the “In case of emergency (section 6)” of your Owner’s Manual.
FUEL-FILLER DOOR
The fuel-filler door is located on the passenger
side of the vehicle.
To open the fuel-filler door, pull the release lever
01, located on the instrument panel to the left of
the steering wheel.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
01
1766904_14d_Rogue_QRG_062514.indd 76/25/14 3:29 PM
To view detailed instructional videos regarding these and other features, please go\
to www.nissanownersinfo.mobi.

9
CLOCK SET/ADJUSTMENT
To adjust the time and the appearance of the clock
on the display:
1. Press the button 01
2. Touch the “Settings” key.
3. Touc

h the “System” key.
4. Touc

h the “Clock” key.
The following settings can be adjusted:
• T
ime Format: The clock can be set to 12 hours or 24 hours.
• Date

Format: The date can be changed to one of 5 different formats.
• Clock Mode

: From here the clock mode options are:



· Manual: Allows for the option “Set Cloc
k Manually”. Touch this to begin setting the clock
manually using the “+” or “–“ to adjust the hours,
minutes, day and month up or down.
· T

ime Zone: Touch the “Time Zone” key
02 to
choose from the applicable time zone list, and/or
touch “Daylight savings time” to
switch between on and off.



· Auto

: Automatically sets the clock to the vehicles
current location.
Press the BACK button 03 to return to the previous screen.
For more information please refer to the “Monitor, climate, audio, phone and voice recognition systems (section 4)” of
your Owner’s Manual.
03
01
02
1766904_14d_Rogue_QRG_062514.indd 96/25/14 3:29 PM
To view detailed instructional videos regarding these and other features, please go\
to www.nissanownersinfo.mobi.
