12
SEAT ADJUSTMENTS
To slide the front seat forward or backward, pull up
on the bar
01 under the front of the seat and slide
forward or backward. Release the bar to lock the
seat in position.
To recline the seatback, pull up on the lever
02
and lean back. To bring the seatback forward, pull
the lever up and lean your body forward. Release
the lever to lock the seatback in position.
SEAT LIFTER (driver’s seat only)
Pull up or push down the adjusting lever
03 to
adjust the seat height to the preferred position.
FOLDING THE REAR SEATBACKS DOWN
Secure the seat belt on the seat belt hooks
04
located on the side wall.
To fold the seatback down, pull the release knob
05.
To return the seatback to the seating position, lift up
each seatback and push it to the upright position
until it is latched. Then return the seat belt to its
original position.
For more information, refer to the “Safety – Seats, seat belts and
supplemental restraint system (section 1)” of your Owner’s Manual.
0203
OUTSIDE MIRROR CONTROL SWITCH
To select the right or left side mirror, turn the control
switch
01 right or left.
To adjust the mirror angle, move the control switch
01 up, down, right or left.
To prevent accidentally moving the mirror, turn and
set the switch to the middle (neutral) position.
For more information, refer to the “Pre-driving checks and adjustments
(section 3)” of your Owner’s Manual.
01
FIRST DRIVE FEATURES
04
05
01
1700496_14b_Leaf_QRG_021114.indd 122/11/14 3:48 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
