2014 NISSAN LEAF climate control

*See your Owner’s Manual for information.01 POWER METER02 HEADLIGHT AND TURN SIGNAL CONTROL03 LI-ION BATTERY TEMPERATURE GAUGE*04 VEHICLE INFORMATION DISPLAY*05 DRIVING RANGE*06 LI-ION BATTERY AVAILABLE
CHARGE GAUGE07 LI-ION BATTERY CAPACITY LEVEL GAUGE08 WINDSHIELD WIPER/WASHER SWITCH
09 TRIP COMPUTER SWITCHES10 DRIVING RANGE BUTTON*11 TRIP/RESET SWITCH*12 INSTRUMENT BRIGHTNESS
CONTROL SWITCH*13 CHARGE TIMER OFF SWITCH*14 CHARGE CONNECTOR LOCK SWITCH*15 CHARGE PORT LID OPENER SWITCH16 HEATED STEERING WHEEL SWITCH*
17 STEERING WHEEL SWITCHES FOR AUDIO CONTROL*/BLUETOOTH
®/NAVIGATION
18 CRUISE CONTROL/ECO BUTTON19 POWER SWITCH20 VEHICLE DYNAMIC CONTROL (VDC) OFF SWITCH*21 STEERING WHEEL TILT ADJUSTMENT*22 HOOD RELEASE*23 CONTROL PANEL*
24 ZERO EMISSION BUTTON25 CLIMATE CONTROLS26 FRONT PASSENGER AIR BAG STATUS LIGHT*27 12-VOLT POWER OUTLET*28 USB/iPOD
® CONNECTOR*
29 AUXILIARY INPUT JACK*30 FRONT HEATED SEAT SWITCHES*31 ELECTRIC SHIFT CONTROL SYSTEM
01
03
04
02
05
13
15
10
11
06
07
23
2629
27
3031
24
25
22
09
12
08
20
21
14
16
19
17
18
2830
1700496_14b_Leaf_QRG_021114.indd 32/11/14 3:47 PM

TABLE OF CONTENTS
NEW SYSTEM FEATURES
C ARWINGS™/Remote Functions (if so equipped) ..................2
Approac

hing Vehicle Sound for Pedestrians (VSP) System
............2

Around V

iew
® Monitor (if so equipped).............................2 Shift Control System............................................4
Heated Seats..................................................4
E

SSENTIAL INFORMATION
Cold W

eather Range
............................................5 Parking in Extremely Cold W

eather
................................5 Quic

k Charge in Cold Weather (if so equipped) .....................
5 Li-ion B

attery Temperature Gauge
.................................6

Li-ion B

attery Gauges
...........................................6 P

ower Limitation Indicator Light
...................................6

Charge P

ort Lid/Charge Connector Lock Switch ....................
7 Li-ion B

attery Charging .........................................
8

T

ire Pressure Monitoring System (TPMS) with Easy Fill Tire Alert
......10 Cloc

k Set/Adjustment
..........................................10
FI

RST DRIVE FEATURES
N

ISSAN Intelligent Key
® System.................................11 Rear Hatc
h Release............................................11
Seat Adjustments

.............................................
12

Outside Mirror Control Switc

h
...................................12

P

ower Meter
.................................................
13

Electric V

ehicle (EV) System Warning Light
........................13

St

arting/Stopping the Electric Vehicle (EV) System .................
14

Headlight Control Switc

h .......................................
14

W

indshield Wiper and Washer Switch ............................
15

Automatic Climate Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. 16




FM/AM/SiriusXM
® Satellite Radio with CD Player (if so equipped).....17 Cruise Control (if so equipped)
..................................18


USB/iPod
® Interface...........................................18
Pandora® Operation (if so equipped)...........................18
S
YSTEM GUIDE
T

rip Computer ................................................
19

Bluetooth
® Hands-free Phone System.............................20
System Operating T ips .....................................20

Bluetooth
® System without Navigation (if so equipped)...............20
Bluetooth® System with Navigation (if so equipped) .................22 Navigation System (if so equipped)...............................23


HomeLink
® Universal Transceiver (if so equipped)...................24
Please see your Owner’s Manual for impor tant safety
information and system operation limitations.
•
A c

ellular telephone should not be used for any purpose while
driving so full attention may be given to vehicle operation.
• Always wear your seat belt.
• Supplemental air bags do not replace proper seat belt usage.
•

C
hildren 12 and under should always ride in the rear
seat properly secured in child restraints or seat belts
according to their age and weight.
• Do not drink and drive.
For more information, refer to the “Safety — Seats, seat belts and
supplemental restraint system (section 1)”, “Heater, air conditioner,
audio and phone systems (section 4)” and the “Starting and driving
(section 5)” of your Owner’s Manual and the “Bluetooth
® hands-free
phone system (section 7)” and the “Audio systems (section 4)” of
your Navigation System Owner’s Manual.
Additional information about your vehicle is also available in your Owner’s Manual, Navigation System Owner’s Manual and at www.nissanusa.com.
To view detailed instructional videos, go to
www.nissanownersinfo.mobi/2014/leaf or snap this barcode with an appropriate barcode reader.
1700496_14b_Leaf_QRG_021114.indd 12/11/14 3:47 PM

2
AROUND VIEW® MONITOR
(if so equipped)
With the ignition switch in the ON position, the
Around View® Monitor is activated by pressing the
CAMERA button
01, located on the navigation
unit, or by moving the vehicle to the R (REVERSE)
position. The monitor displays various views of the position of the vehicle.
When the vehicle is in the P (PARK), N (NEUTRAL) or D (DRIVE) position and the CAMERA button
01 is pressed, the following views will display in order:
01
NEW SYSTEM FEATURES
APPROACHING VEHICLE SOUND FOR PEDESTRIANS
(VSP) SYSTEM

The VSP system helps alert pedestrians to the presence of the vehicle when it \
is being
driven at a low speed.
When the vehicle starts to move, it produces a sound. The sound stops when the vehicle
speed reaches approximately 19 MPH (30 km/h) while accelerating.
For more information, refer to the “EV overview (section EV)” of your Owner’s Manual.
CARWINGS™/REMOTE FUNCTIONS* (if so equipped)
Vehicle telematic capabilities enable you to perform remote functions fro\
m a compatible
internet-enabled smart phone or personal computer such as:
Battery status – The status of the battery can be checked even if you are not in the vehicle.
Unplugged st atus and charging status – A notification e-mail and/or text message can be
sent if the charge connector is not connected or if battery charging is stopped mid-charge.
Remote charge and remote climate control – Start battery charging or set a time to turn on
your climate controls.
Li-ion battery warmer st atus - When the ambient temperature is low, the Li-ion battery
warmer operates automatically and an e-mail notification will be sent \
to remind you of
connecting your vehicle to a charging station.
POIs powered by Google™ - Allows you to search from locations near your vehicle’s
current location, near a plotted destination, near the map’s scroll position or near a
searched city center.
*Remote functions are only available when the following conditions are m\
et: Optional C ARWINGS™ (if so equipped) subscription service has been established. Your vehicle and smart phone are in a compatible cellular phone coverage \
area and your personal computer is connected
to the internet.
For more information, refer to the “Charging (section CH)” of your Owner’s Manual and the “ LEAF navigation system
overview (section IT)” of your Navigation System Owner’s Manual.
1700496_14b_Leaf_QRG_021114.indd 22/11/14 3:48 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

5
ESSE NTIAL I N FOR MATION
QUICK CHARGE IN COLD WEATHER (if so equipped)
It may take more time to charge the Li-ion battery using the quick charger if the vehicle is
parked in a cold location (for example 32°F (0°C)) for a long period of time.
The Li-ion battery temperature gauge can be used to estimate the approximate time needed to charge the Li-ion battery to 80%.
For more information, refer to the “Charging (section CH)” and the “Starting and driving (section 5)” of your
Owner’s Manual.
E
D
C
B
A
Li-ion battery
temperature gauge
A 3 or less segments
illuminated
B 4-5 segments illuminated
C 6- 7 segments
illuminated
D 8-9 segments illuminated
E 1 0 or more segments
illuminated Estimated
charge time
More than approximately

90 minutes
Approximately
30-90 minutes
Approximately
30 minutes
Approximately
30-60 minutes
More than approximately
60 minutes
PARKING IN EXTREMELY COLD WEATHER
Do not store the vehicle in temperatures below -13°F (-25°C) for\
over seven days. If the
outside temperature is -13°F (-25°C) or lower
, the Li-ion battery may freeze and it cannot
be charged or provide power to run the vehicle.
The Li-ion battery heater does not operate if the available Li-ion batter\
y charge is less than approximately 30% and the charger is not connected to the vehicle. To help prevent the
Li-ion battery from freezing, do not leave the vehicle in an environment\
where temperatures
may go below -1°F (-17°C) unless the vehicle is connected to a charger.
For more information, refer to the “EV overview (section EV)” of your Owner’s Manual.
COLD WEATHER RANGE
Vehicle range may be reduced when the temperature drops below -4°F (-\
20°C).
Using the climate control system to heat the cabin when the outside temp\
erature is below
32°F (0°C) uses more electricity and affects vehicle range more \
than using the heater at
temperatures above 32°F (0°C).
For more information, refer to the “EV overview (section EV)” and the “Starting and driving (section 5)” of
your Owner’s Manual.
1700496_14b_Leaf_QRG_021114.indd 52/11/14 3:48 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

16
FIRST DRIVE FEATURES
AUTOMATIC CLIMATE CONTROLS
01 ON-OFF BUTTON Press the ON-OFF button to turn the climate control system on or off.
02 AUTO BUTTON The AUTO mode may be used year-round. Press the AUTO button and the system will
automatically control the inside temperature (automatic cooling and/or \
dehumidified
heating), air flow distribution and fan speed.
03 TEMPERATURE CONTROL BUTTON Press the temperature control button up for warmer air or down for cooler air.04 FAN SPEED CONTROL BUTTON Press the fan speed control button to manually adjust the fan speed
up
or
down .
05 MODE BUTTON Push the
M ODE button to cycle through the following air flow outlets:



Air flows from the center and side vents.

Air flows from the center , side and foot vents.

Air flows mainly from the foot vents.


Air flows from the defroster and foot vents.
06 HEAT BUTTON Press the H E AT button to manually turn the heater on and off.
07 A/C BUTTON Press the A/C button when you want to manually turn the A/C on or off.
08 AIR RECIRCULATION BUTTON Press the air recirculation button to recirculate air inside the vehicle. The indicator
light on the button will illuminate. This system is used to avoid certain outside odors and
helps to adjust the inside vehicle temperature more effectively.
Press the air recirculation button again to turn air recirculation off. This allows
outside air to be drawn into the passenger compartment to prevent foggin\
g in defrost,
floor, or defrost/floor modes.
The air recirculation mode cannot be activated when the climate control s\
ystem is in the front defrosting mode or the front defrosting and foot vent mode .
09 DEFROSTING/DEFOGGING FRONT AND SIDE WINDOWS Press the front window defroster button to turn the system on. The A/C automatically
turns on when the defroster mode is selected. To remove fog or moisture from the front
window quickly, press the
H E AT button and ensure that the A/C button is selected.
Set the temperature control buttons and the fan speed control buttons to\
their
maximum settings.
10 REAR WINDOW AND OUTSIDE MIRROR DEFROSTER SWITCH Push the rear window defroster button to turn the system on or off.
The rear window defroster automatically turns off after approximately 15 minutes.
11 CLIMATE CONTROL TIMER INDICATOR The climate control timer indicator light will illuminate when the timer \
has been set to
operate. The climate control timer may be set to a specific date and time.
For more information, refer to the “Heater, air conditioner, audio and phone systems (section 4)” of your Owner’s Manual.
03
01
11
02
05
04
071008
0609
1700496_14b_Leaf_QRG_021114.indd 162/11/14 3:48 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

18
CRUISE CONTROL (if so equipped)
The cruise control system enables you to set a constant cruising speed once the vehicle has
reached 25 MPH (40 km/h).
The system will automatically maintain the set speed
until you tap the brake pedal, accelerate, cancel or
turn the system off.
To activate the cruise control, push the CRUISE
ON/OFF switch
01. The CRUISE indicator light
in the instrument panel will illuminate.
To set cruising speed, accelerate the vehicle to the desired speed, push \
the COAST/SET
switch
02 and release. Take your foot off the accelerator pedal. Your vehicle will maintain
the set speed.
To reset at a faster cruising speed, push and hold the ACCEL/RES switch
03.
When the vehicle attains the desired speed, release the switch.
To reset at a slower cruising speed, push and hold the COAST/SET switch 02.
Release the switch when the vehicle slows to the desired speed.
To cancel the preset speed, push the CANCEL switch 04.
To turn off cruise control, push the CRUISE ON/OFF switch
01. The CRUISE indicator
light in the instrument panel will turn off.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
FIRST DRIVE FEATURES
03
02
01
04
USB/ iPOD® INTERFACE
T he USB jack
01 is located on the instrument
panel below the climate controls.
When a compatible USB memory device or iPod®
is plugged into the USB jack, compatible audio files
stored on the device can be played through the
vehicle’s audio system.
PANDORA
® OPERATION (if so equipped)
With an iPhone® connected via USB/iPod® interface and the Pandora app installed on
the iPhone® there is a Pandora screen that will display. This acts as an extension of the
iPhone’s® Pandora interface that will display the station, album artwork if available and
menu, “Thumbs Down”, “Bookmark”, “Thumbs Up” and play/pause buttons.
For a full list of compatible devices, refer to Audio system (section 4)\
of your Navigation System
Owner’s Manual.
For more information, refer to the “Heater, air conditioner, audio and phone systems (section 4)” of your Owner’s
Manual, and “Audio system (section 4)” of your Navigation System Owner’s Manual.
01
1700496_14b_Leaf_QRG_021114.indd 182/11/14 3:48 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
