For further brake fluid information, see the
following section. (“Capacities and recom-
mended fuel/lubricants” page 9-2)
WARNING
. Use only new fluid from a sealed
container. Old, inferior or contami-
nated fluid may damage the brake
system. The use of improper fluids
can damage the brake system and
affect the vehicle’s stopping ability.
. Clean the filler cap before removing.
. Brake fluid is poisonous and should
be stored carefully in marked con-
tainers out of the reach of children.
CAUTION
Genuine NISSAN Brake Fluid R35 Spe-
cial II is the factory fill brake fluid. The
Vehicle Dynamic Control (VDC) unit and
other related parts were specially de-
signed for this brake fluid and NISSAN
cannot ensure proper operation of the
vehicle if other brake fluid is used.
NOTICE
Do not spill the fluid on any painted
surfaces. This will damage the paint. If
fluid is spilled, wash the surface with
water.
Check the fluid level in the reservoir. If the fluid is
below the MIN line
*1or the brake warning
light comes on, add Genuine NISSAN Brake
Fluid R35 Special II fluid up to the MAX line
*2.
If fluid must be added frequently, the system
should be checked by a GT-R certified NISSAN
dealer.
Maintenance and do-it-yourself8-15
BRAKE FLUID

*4: For additional information, see the following section. (“Air conditioner specification label” page 9-13)
*5: DEXRONTMVI type ATF may also be used.
*6: For additional information, see the following section. (“Engine cooling system” page 8-10)
*7: Genuine NISSAN Brake Fluid R35 Special II is the factory fill brake fluid. The Vehicle Dynamic Control (VDC) unit and other related parts were specially designed for this brake fluid and NISSAN cannot ensure the best performance and proper operation of the vehicle if other brake fluid is used.
*8: All of the fluid cannot be removed when servicing the transmission. The actual refill amount may be less than shown.
Technical and consumer information9-3

This vehicle is equipped with an Event Data
Recorder (EDR) . The main purpose of an EDR is
to record, in certain crash or near crash-like
situations, such as an air bag deployment or
hitting a road obstacle, data that will assist in
understanding how a vehicle’s systems per-
formed. The EDR is designed to record data
related to vehicle dynamics and safety systems
for a short period of time, typically 30 seconds
or less. The EDR in this vehicle is designed to
record such data as:
.How various systems in your vehicle were
operating;
. Whether or not the driver and passenger
safety belts were buckled/fastened;
. How far (if at all) the driver was depressing
the accelerator and/or brake pedal; and,
. How fast the vehicle was traveling.
. Sounds are not recorded.
These data can help provide a better under-
standing of the circumstances in which crashes
and injuries occur. NOTE: EDR data are
recorded by your vehicle only if a nontrivial
crash situation occurs; no data are recorded by
the EDR under normal driving conditions and no
personal data (e.g. name, gender, age and crash
location) are recorded. However, other parties,
such as law enforcement, could combine the EDR data with the type of personally identifying
data routinely acquired during a crash investiga-
tion.
To read data recorded by an EDR, special
equipment is required and access to the vehicle
or the EDR is needed. In addition to the vehicle
manufacturer and NISSAN dealer, other parties,
such as law enforcement, that have the special
equipment, can read the information if they have
access to the vehicle or the EDR. EDR data will
only be accessed with the consent of the vehicle
owner or lessee or as otherwise required or
permitted by law.The Vehicle Status Data Recorder (VSDR) is
different from the Event Data Recorder de-
scribed in “Event Data Recorder” in this section.
The VSDR is not a crash-activated device, but it
records and accumulates vehicle data while
driving.
Examples are:
.
Vehicle operating information such as the
wheel speeds of the front and rear wheels
. Engine control information such as the
engine speed and boost pressure
The VSDR always records and stores vehicle
operating data between periodic inspections,
which can assist and be used for servicing,
diagnosing and performing warranty repairs.
The VSDR does not record sounds, conversa-
tions or images.
To read data recorded by the VSDR, special
equipment is required and access to the vehicle
or the VSDR is needed.
HANDLING OF DATA
NISSAN and third parties affiliated with NISSAN
can acquire and use the data recorded by the
VSDR in order to confirm the part replacement
history to improve the quality of NISSAN
vehicles.
With the exception of the following cases,
Technical and consumer information9-21
EVENT DATA RECORDERS (EDR) VEHICLE STATUS DATA RECORDER
(VSDR)

T
Tachometer ..................................................................... 2-7
Temperature A, B and C........................................... 9-18
Terms.............................................................................. 9-14
Three-point type seat belt with retractor ................ 1-9
Three-way catalyst........................................................ 5-3
Tight corner braking phenomenon.......................... 5-42
Tilt/telescopic steering column................................ 3-26
TireChanging wheels and tires................................ 8-40
Checking the tire pressure................................ 8-35
Flat tire....................................................................... 6-3
Front/rear tire size discrepancy warning........ 2-38
Low tire pressure warning ................................. 2-39
Run-flat tire warning............................................ 2-39
Run-flat tires............................................................. 6-4
Tire and loading information label......... 8-34, 9-13
Tire chains.............................................................. 8-40
Tire dressing............................................................. 7-4
Tire equipment...................................................... 5-52
Tire labeling ........................................................... 8-36
Tire pressure ......................................................... 8-32
Tire Pressure Monitoring System............... 5-4, 6-3
Tire Pressure Monitoring System warning..... 2-39
Tires......................................................................... 5-43
Types of tires......................................................... 8-38
Uniform tire quality grading ............................... 9-18
Wheels and tires......................................... 8-32, 9-9
Tires and road wheels ........................................... GTR-5
To protect your vehicle from corrosion.................... 7-8 Towing
Flat towing ............................................................. 9-17
Towing a trailer ..................................................... 9-17
Towing recommended by NISSAN .................... 6-9
Towing your vehicle................................................ 6-9
Traction AA, A, B and C........................................... 9-18
Transmission
Dual clutch transmission .................................... 5-15
Transmission clutch high
temperature warning............................................ 2-36
Transmission oil ..................................... GTR-4, 8-14
Transmission oil high temperature warning.... 2-35
Transmission position indicator ........................... 2-9
Transmission system check display................. 2-14
Transmission system warning ........................... 2-35
VDC, transmission and suspension
setup switches...................................................... 5-24
Transmission operation characteristics............ GTR-29
Transmission settings............................................. GTR-9
Treadwear...................................................................... 9-18
Troubleshooting guide ............................................... 3-17
Trunk............................................................................... 3-20
Trunk lid release switch............................................. 3-20
Trunk open request switch ....................................... 3-20
Trunk release power cancel switch........................ 3-21
Turbocharger system.................................................. 5-30
Turning off the heaters............................................... 2-54
Turning on the heaters............................................... 2-53
Types of tires................................................................ 8-38
U
Underbody....................................................................... 7-3
Uneven wear of tires ............................................ GTR-25
Uniform tire quality grading ...................................... 9-18
Upshift indicator ............................................................ 2-9
Using the washer ........................................................ 2-49
Using the wipers ......................................................... 2-48
V
Vanity mirror.................................................................. 3-29
Vanity mirror lights ...................................................... 2-63
VDC, transmission and suspension
setup switches............................................................. 5-24
Vehicle Dynamic Control (VDC) OFF mode .... GTR-10
Vehicle Dynamic Control (VDC) warning light .... 2-31
Vehicle Dynamic Control system ............................ 5-49
Vehicle Dynamic Control system warning ............ 2-37
Vehicle identification................................................... 9-11 Vehicle identification number ............................ 9-12
Vehicle Identification Number plate................. 9-11
Vehicle information display........................................ 2-12
Vehicle load capacity.................................................. 9-15
Vehicle loading information....................................... 9-14
Vehicle recovery........................................................... 6-10
Vehicle security system ............................................. 2-45
Vehicle speed............................................................... 2-16
Vehicle status data recorder .................................... 9-21
10-7

10-8
W
WarningAnti-lock Braking System warning................... 2-37
AWD clutch high temperature warning.......... 2-37
AWD system warning ......................................... 2-38
AWD warning light .............................................. 5-40
Brake pad wear warning.................................... 8-23
Cruise control system warning......................... 2-40
Door/trunk open warning ................................... 2-41
Engine oil low pressure warning...................... 2-34
Engine system warning....................................... 2-34
Front/rear tire size discrepancy warning........ 2-38
Hazard warning flasher switch............................. 6-2
Low brake fluid warning ..................................... 2-36
Low fuel warning.................................................. 2-40
Low tire pressure warning ................................. 2-39
Low washer fluid warning.................................. 2-41
No key warning..................................................... 2-41
Parking brake release warning ......................... 2-36
“PUSH” warning................................................... 2-43
Run-flat tire warning............................................ 2-39
Shift lever position warning............................... 2-35
Shift “P” warning.................................................. 2-43
Supplemental air bag warning labels.............. 1-46
Supplemental air bag warning light................. 1-47
Tire Pressure Monitoring System warning..... 2-39
Transmission clutch high
temperature warning............................................ 2-36
Transmission oil high temperature warning.... 2-35
Transmission system warning ........................... 2-35 Vehicle Dynamic Control system warning ..... 2-37
Warning (drive computer).................................. 2-23
Warning display.................................................... 2-33
Warning lights....................................................... 2-25
Warning signals.................................................... 3-16
Warning/indicator lights and
audible reminders................................................. 2-25
Warranty information .............................................. GTR-3
Washing........................................................................... 7-2
Waxing............................................................................. 7-3
Wheel alignment ....................................... GTR-10, 5-38
Wheel alignment inspection and adjustment
(if necessary) (including tire
pressure adjustment) ............................................. GTR-8
Wheels............................................................................. 7-3
Wheels and tires............ GTR-17, GTR-23, 8-32, 9-9
When traveling or registering your vehicle in
another country............................................................ 9-11
Where to go for service.............................................. 8-3
Window washer fluid ................................................. 8-16
Windows ....................................................................... 2-59
Windshield wiper and washer switch.................... 2-47
Windshield wiper blades........................................... 8-21
Wiper Replacing the wiper blades............................... 8-22
Using the wipers .................................................. 2-48
Windshield wiper and washer switch............. 2-47
Windshield wiper blades.................................... 8-21
X
Xenon headlights......................................................... 2-50
