2014 NISSAN 370Z COUPE ECO mode

NEW SYSTEM FEATURES
RearView Monitor (if so equipped) ................................. 2
Opening the Soft Top (Roadster models) ...........................2
USB/iPod
® Interface (if so equipped) .............................. 2
ESSENTIAL INFORMATION
Tire Pressure Monitoring System (TPMS) ...........................3
Loose Fuel cap ................................................ 3
Engine Oil Temperature Gauge ................................... 4
Automatic Power Windows ...................................... 4
FIRST DRIVE FEATURES
NISSAN Intelligent k ey
® System.................................. 5
Rear Hatch/Trunk Lid Release .................................... 6
Soft Top Operation (Roadster models) .............................6
Power Seat Adjustments (if so equipped) ...........................7
Power Outside Mirror control Switch ..............................7
Starting/Stopping the Engine ..................................... 8
Headlight control Switch ........................................ 9
Windshield Wiper and Washer Switch ............................. 9
Automatic climate controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. 10
FM/AM/SiriusXM Satellite Radio with c D/DVD Player (if so equipped) 11
cruise control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . 12
clock Set/Adjustment .......................................... 12
Fuel-Filler Door ............................................... 13
SYSTEM GUIDE
Trip computer ................................................ 14
Bluetooth
® Hands-free Phone System (if so equipped) .............. 14
System Operating Tips ....................................... 14
Bluetooth
® System with Navigation (if so equipped) ...............15
Bluetooth® System without Navigation (if so equipped) ............ 17
Navigation System (if so equipped) ............................... 18
HomeLink
® Universal Transceiver (if so equipped) ...................20
• A cellular telephone should not be used for any purpose while
driving so full attention may be given to vehicle operation.
• Always wear your seat belt.
• Supplemental air bags do not replace proper seat belt usage.
• children 12 and under should always ride in the rear seat
properly secured in child restraints or seat belts according to
their age and weight.
• Do not drink and drive.
For more information, refer to the “Safety –– Seats, seat belts and supple-
mental restraint system (section 1)”, the “Center display, heater, air
conditioner, audio, phone and voice recognition systems (section 4)”
and the “Starting and driving (section 5)” of your Owner’s Manual.
Additional information about your vehicle is also available in your Owner’s Manual, Navigation System Owner’s Manual and at www.nissanusa.com.
To view detailed
instructional videos, go to
www.nissanownersinfo.mobi/2014/370z or snap this barcode with an appropriate barcode reader.
TABLE OF c ONTENTS

2
OPENING THE SOFT TOP (Roadster models)
It is important to make sure the Nissan Intelligent k ey®
is with you (that is, in your pocket or purse).

The soft top can be opened from outside the vehicle
using the door handle request switch

01 as follows:
• The ignition switch must be in the OFF position.
• Push and hold the door handle request switch

01
until the soft top is fully opened.
For more information, refer to the “Pre-driving checks and adjustments
(section 3)” of your Owner’s Manual.
USB/iPod® Interface (if so equipped)
The USB jack is located in the center console under the armrest.

When a compatible USB memory device or iPod® is plugged into the USB jack, compatible
audio and video files stored on the device can be played through the v\
ehicle’s audio system
and front display.
For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (section 4)” of your
Owner’s Manual.
01
new system features
To view detailed instructional videos regarding these and other features, please go\
to www.nissanownersinfo.mobi
REARVIEW MONITOR (if so equipped)
When the shift lever is shifted into the R (REVERSE
position, the monitor display shows a rearward view
from the vehicle.

The colored guide lines on the display screen
indicate vehicle width and approximate distances to
objects with reference to the vehicle body line.:
• Red 1.5 ft (0.5 m); Yellow 3 ft (1 m);
Green 7 ft (2m) and 10 ft (3 m).
For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (section 4)” of your
Owner’s Manual.

3
LOOSE FUEL CAP
A LOOSE FUEL CAP warning message will
appear in the vehicle information display

01 when

the fuel-filler cap is not tightened correctly.

To tighten, turn the cap clockwise until a single click
is heard.

The warning message will disappear when the vehicle
detects the fuel-filler cap is properly tightened and the
reset button

02 is pressed for about 1 second.

If the cap is not properly tightened, the Malfunction
Indicator Light

may illuminate.
For more information, refer to the “Instruments and controls (section 2)”
and the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
02
01
TIRE PRESSURE MONITORING SYSTEM (TPMS)
A
CHEC k TIRE PRESSURE warning message
will appear in the vehicle information display
01 and

the low tire pressure warning light 02 will illuminate

when one or more tires are low on pressure and air
is needed.
• The tire pressures should be checked when the
tires are cold. The tires are considered cold after
the vehicle has been parked for 3 hours or more or
driven less than 1 mi (1.6 km) at moderate speeds.

After tire pressures are adjusted, press the reset
button
03 to turn off the
CHEC k TIRE PRESSURE
warning message. To turn off the warning light, drive
the vehicle at speeds above 16 MPH (25 km/h).

When the low tire pressure warning light flashes for 1 minute and then \
remains on, the
TPMS is not functioning properly. Have the system checked by a NISSAN dealer.

Tire pressure rises and falls depending on the heat caused by the vehicle\
’s operation and the
outside temperature. Low outside temperature can lower the temperature o\
f the air inside
the tire, which can cause a lower tire inflation pressure. This may cause the low tire pressure
warning light to illuminate. If the warning light illuminates, check the tire pressure in your tires.
• check the tire pressure (including the spare tire) often and always prior \
to long
distance trips.

The Tire and Loading Information label contains valuable information. Please refer to
section 9, “Technical and consumer information”, in your Owner’s Manual for the location
of the Tire and Loading Information label.
For more information, refer to the “Instruments and controls (section 2)”, the “Starting and driving (section 5)” and the
“Maintenance and do-it-yourself (section 8)” of your Owner’s Manual.
03
01
02
esse ntial i n for mation

8
STARTING/STOPPING THE ENGINE
It is important to make sure the NISSAN Intelligent
key® is with you (that is, in your pocket or purse).
AUTOMATI c TRANSMISSION (if so equipped)

Depress the brake pedal.
• If the brake pedal is not depressed, pushing the
ignition switch once will activate the ACC mode.
• Pushing the ignition switch a second time will
activate the ON mode.

Move the shift lever to P (PAR k).

Press the ignition switch START/STOP button to start the engine.
MANUAL TRANSMISSION (if so equipped)

Depress the brake pedal.

Move the shift lever to N (NEUTRAL).

Depress the clutch pedal to the floor.
• If the clutch pedal is not depressed, pushing the ignition switch once will activate the
ACC mode.
• Pushing the ignition switch a second time will activate the ON mode.

Press the ignition switch START/STOP button to start the engine.
TURNING THE ENGINE OFF

For an automatic transmission, move the shift lever to the P (PAR k) position, apply the
parking brake and press the ignition switch START/STOP button to turn the engine off.

For a manual transmission, move the shift lever to the N (NEUTRAL) position, apply the
parking brake, place the vehicle in 1st gear and press the ignition switch START/STOP
button to turn the engine off.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
To view detailed instructional videos regarding these and other features, please go\
to www.nissanownersinfo.mobi
first drive features

10
AUTOMATIC CLIMATE CONTROLS
01 A/C BUTTON/FAN SPEED CONTROL DIAL

Push the A/C button to turn the A/c on or off. Turn the fan speed control dial to the left to
decrease fan speed or to the right to increase fan speed.
02 AUTO BUTTON/TEMPERATURE CONTROL DIAL

The auto mode may be used year-round. Push the AUTO button to turn the system on
and the system will automatically control the inside temperature (autom\
atic cooling and/
or dehumidified heating), air flow distribution and fan speed.
03 MODE/MANUAL AIR FLOW CONTROL BUTTON


Push the MODE button
to cycle through the following air flow outlets:

Air flows from the center and side vents.

Air flows from the center, side, and foot vents.

Air flows mainly from the foot vents.

Air flows from the defroster and foot vents.
04 DEFROSTING/DEFOGGING FRONT AND SIDE WINDOWS

Press the front window defroster button
to turn the system on. The A/c automatically

turns on when the defroster mode is selected. This feature removes humidity from the air.

Set the fan speed control dial
01 and the temperature control dial 02 to their

maximum settings.
05 AIR RECIRCULATION BUTTON

Press the air recirculation button
to recirculate air inside the vehicle. The indicator

light on the button will illuminate. This system is used to avoid certain outside odors and
helps to adjust the inside vehicle temperature more effectively.

Press the air recirculation button
again to turn air recirculation off. This allows outside

air to be drawn into the passenger compartment to prevent fogging in def\
rost, floor or
defrost/floor modes.
06 REAR WINDOW AND OUTSIDE MIRROR DEFROSTER SWITCH

Push the rear window defroster switch
to turn the system on or off.

The rear window defroster automatically turns off after approximately 15 minutes.
07 OFF BUTTON

Press the OFF button to turn the climate control system off.
For more information, refer to the “Instruments and controls (section 2)” and the “Center display, heater, air conditioner,
audio, phone and voice recognition systems (section 4)” of your Owner’s Manual.
01
04
060307
05
02
To view detailed instructional videos regarding these and other features, please go\
to www.nissanownersinfo.mobi
first drive features

14
TRIP COMPUTER
When the button
01 is pressed, the following

modes will appear on the vehicle information
display
02 :
• MPG – Displays the current fuel consumption.
• MPG/MPH – Displays the average fuel
consumption and speed since the last reset.
• TIME/ MILES – Displays the elapsed time and
total distance the vehicle has been driven since
the last reset.
• RANGE – Displays the estimated distance to empty (dte) the vehicle can be driven
before refueling.
• OUTSIDE TEMP – Displays the exterior air temperature including a low temperature
warning feature.
• SETTING – Allows you to set reminders for alerts and maintenance intervals o\
r change
the language and units used in the system.
— Press the

button
03 to cycle through the various setting modes.
— Press the

button
01 to choose the selected menu.
• WARNING – If there are any.

To reset TIME/MILES go to the desired mode on the trip computer and hold the
button 03 for more than 1 second.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
01
03
02
BLUETOOTH® HANDS-FREE PHONE SYSTEM* (
if so equipped)
With an overhead microphone and sound
transmitted through the audio system speakers,
the Bluetooth
® Hands-free Phone System utilizes
Bluetooth wireless technology and voice recognition
to provide hands-free cellular phone communication.

A cellular telephone should not be used while driving
so full attention may be given to vehicle operation.*
SYSTEM OPERATING TIPS

The “Help” command can be used to hear a list of
available commands at any time.

Reduce background noise as much as possible by closing windows and pointing
HVA c vents away from the ceiling.

Say commands after the tone, or press the
or
button to say a command
at any time.
Bluetooth® Controls
To view detailed instructional videos regarding these and other features, please go\
to www.nissanownersinfo.mobi
s ystem guide
*Some jurisdictions prohibit the use of cellular telephones while drivin\
g.

15
Speak naturally without long pauses and without
raising your voice.

When speaking Phonebook names, please be aware
some phones require the last name to be spoken
before the first name. For example, “Michael Smith”
may be spoken as “Smith Michael”.

To cancel a voice recognition session with navigation,
simply wait 5 seconds, say “Exit” or press and hold the

button for 5 seconds.

To cancel a voice recognition session without navigation, simply wait 5 s\
econds, say “cancel”
or “Quit,” or press and hold the
button for 5 seconds.

To increase or decrease the volume of the voice prompts, push the volume \
control switches
+ or -
on the steering wheel or turn the control dial on the audio system while\
the audio system
is responding.

If the Voice Recognition system does not recognize your voice commands, train th\
e system
using the Voice Adaptation Mode. See your Owner’s Manual for detailed information.

For more detailed information and instructions, refer to your cellular phone Owner’s Manual and visit
www.nissanusa.com/bluetooth.
Bluetooth® System with Navigation*
(if so equipped)
cONNEc TING PROcEDURE

The vehicle must be stationary when connecting
the phone.

Bluetooth Streaming Audio (available with
Navigation System only) allows you to use a
compatible Bluetooth phone to play audio files on
your device. Your compatible cellular phone can be
connected to the vehicle’s audio system allowing
audio files to play through the vehicle’s speakers.
1. Press the PHONE button on the instrument panel or
the

button on the steering wheel and select the

“connect Phone” key.
Microphone
To view detailed instructional videos regarding these and other features, please go\
to www.nissanownersinfo.mobi
*Some jurisdictions prohibit the use of cellular telephones while drivin\
g.
