2014 MITSUBISHI LANCER bluetooth

Instruments and controls (Driver’s area) 1-1
1
Overview
N00100202498
Instruments and controls (Driver’s area) Except for RALLIART
Instrument cluster P.5-110
Sportronic steering wheel paddle shifter (if so equipped) P.5-67
Multi-information meter switch P.5-113
Combination headlights and dimmer switch P.5-149 Turn signal lever P.5-154Front fog light switch (if so equipped) P.5-156
Wiper and washer switch P.5-156 Cruise control switches (if so equipped) P.5-99
Steering wheel audio remote control switches (if so equipped) P.5-163
Ignition switch P.5-54
Headlight leveling switch (if so equipped) P.5-154
Supplemental restraint system - air- bag (for driver’s seat) P.4-22 Horn switch P.5-161
Active stability control (ASC) OFF switch (if so equipped) P.5-95
Fuses P.9-28
Steering wheel tilt lock lever P.5-51
Supplemental restraint syst
em - driver’s knee airbag
P.4-22
Bluetooth
® 2.0 interface (if so equipped) P.5-161
Engine hood rele
ase lever P.9-3

Instruments and controls (Driver’s area)
Overview 1-2
1
RALLIART
Instrument cluster P.5-110
Sportronic steering wheel paddle shifter P.5-77
Multi-information meter switch P.5-113
Combination headlight
s and dimmer switch
P.5-149 Turn signal lever P.5-154 Front fog light switch P.5-156
Wiper and washer switch P.5-156 Cruise control switches P.5-99
Steering wheel audio remote control switches P.5-163
Ignition switch P.5-54
Headlight leveling switch (if so equipped) P.5-154
Supplemental restraint system - airbag (for driver’s seat) P.4-22Horn switch P.5-161
Active stability control (ASC) OFF switch P.5-95
Steering wheel tilt lock lever P.5-51
Fuses P.9-28
Supplemental restraint system
- driver’s knee airbag
P.4-22
Bluetooth
® 2.0 interface P.5-161
Engine hood release lever P.9-3

Interior
Overview 1-6
1
N00100302242
Interior
Electric remote-con- trolled outside mirror switch P.5-53
Dome light (Front)/R
eading lights (if so
equipped) P.5-188, 9-35, 9-46
Sunroof switch (if so equipped) P.5-47
Window lock switch P.5-47 Power window switches P.5-45
Power door lock switch P.5-38
Bluetooth
® 2.0 interface microphone (if so equipped) P.5-161
Adjustable seat belt shoulder anchor (for front seats) P.4-12Seat belts P.4-8
Inside rearview mirror P.5-51 Sun visors P.5-186 Vanity mirror P.5-186
Bottle holder (for front seat) P.5-193
Front seats P.4-3
Supplemental restraint
system - side airbag
(for front seats, if so equipped) P.4-33
Head restraints P.4-6

5
Features and controlsBluetooth
® 2.0 interface (if so equipped) .................................... 5-161
USB input terminal (if so
equipped) ............................................ 5-183
Sun visors ................................
..................................................... 5-186
12 V power outlet .........
............................................................... 5-187
Interior lights .................
............................................................... 5-188
Storage spaces .........................
..................................................... 5-190
Cup holder ...............................
..................................................... 5-192
Bottle holder ..................
............................................................... 5-193
Assist grip......................
............................................................... 5-194
Coat hook (if so equippe
d) ........................................................... 5-194

Horn switch
Features and controls 5-161
5
N00523800156
To honk the horn, press around the “ ” mark on the steering wheel.
N00563701079
The Link System takes overall control of thedevices connected via the USB input terminal or the Bluetooth
® 2.0 interface allowing the
connected devices to be operated by using theswitches in the vehicle or voice commands.See the following section for details on how to operate. Refer to “Bluetooth
® 2.0 interface” on page
5-161.Refer to “USB input terminal” on page 5-183. Refer to “Listen to Audio Files on a USB Device” on page 7-49.Refer to “Listen to Bluetooth Audio” on page 7-52.
Bluetooth
® is a registered trademark of
BLUETOOTH SIG, INC.
N00563800015
You have acquired a device that includes soft- ware licensed by Mitsubishi Motors Corpora- tion from JOHNSON CONTROLS Inc (theautomotive experien
ce business unit), and
their subsequent 3rd party suppliers. For a complete list of these 3rd party products and their end user license agreements, please goto the following website. http://www.jciblueconnect.com/faq/fulldis- closure.pdf
N00563901172
The Bluetooth
® 2.0 interface allows for mak-
ing/receiving hands-free calls in the vehicle using a Bluetooth
® compatible cellular phone
based on the wireless communication tech- nology commonly known as Bluetooth
®. It
also allows the user to
play music, saved in a
Bluetooth
® music player, from the vehicle’s
speakers.
 Do not place stickers, tape, or other items that are attached with adhesive over the grid wires on the rear window. When cleaning the inside rear window, use a soft cloth and wipe lightly over the grid wires.NOTE
 If your vehicle is equipped with heated mir- rors, mist can also be removed from the out-side rearview mirrors when the rear window defogger switch is pressed. (Refer to “Heated mirror” on page 5-54.)
Horn switch
CAUTION
Type 1
Link System
(if so equipped)
Type 2
Link System End User License Agreement

Bluetooth
® 2.0 interface
(if so
equipped)

Bluetooth® 2.0 interface (if so equipped) 5-162 Features and controls
5
The system is equipped with a voice recogni- tion function, which allows you to make hands-free calls by simple switch operations and voice command operations using adefined voice tree. The Bluetooth
® 2.0 interface can be used
when the ignition switch is in the “ON” or “ACC” position. Before you can use the Bluetooth
® 2.0 inter-
face, you must pair the Bluetooth
® device
and Bluetooth
® 2.0 interface. Refer to “Con-
necting the Bluetooth
® 2.0 interface and
Bluetooth
® device” on page 5-169.
Bluetooth
® is a registered trademark of
BLUETOOTH SIG, INC.
Steering control switch and microphone

P.5-163Voice recognition function
 P.5-165
Useful voice commands
 P.5-165
Speaker enrollment function
 P.5-167
Connecting the Bluetooth
® 2.0 interface and
the Bluetooth
® device
 P.5-169
Operating a music player connected via Blue- tooth
®  P.5-173
How to make or receive hands-free calls

P.5-173 Phonebook function
 P.5-176
WA R N I N GAlthough the Bluetooth
® 2.0 interface
allows you to make hands-free calls, if you choose to use the cellular phone whiledriving, you must not allow yourself to be distracted from the safe operation of your vehicle. Anything, including cellularphone usage, that di
stracts you from the
safe operation of your vehicle increases your risk of an accident. Refer to and comply with all state and local laws in your area regarding cellularphone usage while driving.
NOTE
 If the ignition switch is left in the “ACC” position, the accessory power will automati- cally turn off after a
certain period of time
and you will no longer be able to use the Bluetooth
® 2.0 interface. The accessory
power comes on again if the ignition switch is turned from the “ACC” position. Refer to “ACC power auto-cutout function” on page5-55.  The Bluetooth
® 2.0 interface cannot be used
if the Bluetooth
® device has a dead battery
or the device power is turned off.  Hands-free calls will not be possible if your phone does not have service available.  Some Bluetooth
® devices are not compatible
with the Bluetooth
® 2.0 interface.
 You can confirm the Link System software version by pressing the HANG-UP button 3 times (press and hold 2 times and then press briefly) within 10 seconds.
 For detail of the Bluetooth
® 2.0 interface,
refer to the following web site:[For vehicles sold in U.S.A.] You can see to access the MITSUBISHI MOTORS NORTH AMERICA web site.[For vehicles sold in Canada and Mexico] You can see to access via the MITSUBISHI MOTORS web site.Please read and agree the “Warning about Links to the Web Site
s of Other Companies”
because it connects other than MITSUBISHIMOTORS web site. http://www.mitsubishi-motors.com/en/prod- ucts/index.html  Software updates by cellular phone/digital audio device manufacturers maychange/alter device connectivity.NOTE

Bluetooth® 2.0 interface (if so equipped)
Features and controls 5-163
5
N00564001082
Press this button to increase the volume. Press this button to decrease the volume.
 Press this button to change to voice recog- nition mode. While the system is in voice recognitionmode, “Listening” will appear on the audio display.  If you press the button briefly while in voice recognition mode, it will interrupt prompting and allow voice commandinput. Pressing the button longer will deactivate the voice recognition mode.  Pressing this button briefly during a call will enable voice recognition and allow voice command input.
Steering control switch and microphone

Type 1
1- Volume up button 2- Volume down button3- SPEECH button 4- PICK-UP button 5- HANG-UP button6- MicrophoneVolume up button

Volume down button

Type 2
SPEECH button

NOTE
 On a vehicle equipped with a Mitsubishi Multi-Communication System, pressing the SPEECH button will beep and activated thevoice recognition mode of Mitsubishi Multi- Communication System. When you use the voice recognition of the Bluetooth
® 2.0
interface, press the PICK-UP button.

Bluetooth® 2.0 interface (if so equipped) 5-164 Features and controls
5
 Press this button when an incoming call is received to answer the telephone.  When another call is received during a call, press this button to put the first calleron hold and talk to the new caller. • In such circumstances, you can press the button briefly to switch between callers.You will switch to the first caller and the other caller will be put on hold. • To establish a three-way call in such situ-ations, press the SPEECH button to enter voice recognition mode and then say “Join calls.”
 Press this button when an incoming call is received to refuse the call.
 Press this button during a call to end the current call. When another call is on hold, you will switch to that call. If this button is pressed in the voice recog- nition mode, the voice recognition mode will be deactivated.
N00575800025
Your voice will be recognized by a micro-phone in the overhead console, allowing you
to make hands-free calls with voice com- mands.
PICK-UP button

NOTE
 On a vehicle equipped with a Mitsubishi Multi-Communication System, pressing the PICK-UP button except when an incomingcall is received to answer the telephone will activate the voice recognition of the Blue- tooth
® 2.0 interface.
HANG-UP button

NOTE
 When you press the SPEECH button (except for vehicles with Mitsubishi Multi-Commu-nication System) or PICK-UP button (for vehicles with Mitsubishi Multi-Communica- tion System) to enter voice recognition modewith a cellular phone paired to the system, current information on the cellular phone, such as “remaining battery life,” “signalstrength” or “roaming,” will be displayed on the audio display.
*
* : Some cellular phones will not send this information to the Bluetooth
® 2.0 interface.
 Call waiting and three-way calls can be used by the Bluetooth
® 2.0 interface, only if it is
possible to use those services with your cel-lular phone.
Microphone

NOTE
 If a cellular phone is within close proximity of the microphone, it may distort the sound quality. In this case, place the cellular phoneas far as possible from the microphone.
