2014 LEXUS LX570 stop start

451-2. Opening, closing and locking the doors
1
Before driving
LX570_OM_OM60L21U_(U) * 1
: A message will be shown on the multi-information display in the instrument
cluster.
* 2
: If the engine does not start when the electronic key is inside the vehicle, the
electronic key battery may be depleted or there may be difficulties receiving
signal from the key. (  P. 3 9 )■
If the smart access system with push-button start does not operate properly ●
Locking and unlocking the doors: Use the mechanical key. (  P. 8 6 7 )●
Starting the engine:  P. 8 6 8■
When the electronic key battery is fully depleted
 P. 7 8 0■
Customization
Settings (e.g. smart access system with push-button start) can be changed.
(Customizable features  P. 9 0 6 )Alarm Situation Correction procedure
Interior alarm pings
once
* 1
The electronic key has a low
battery Replace the electronic
key battery
An attempt was made to start
the engine without the elec-
tronic key being present, or
the electronic key was not
functioning normally Start the engine with the
electronic key
present
* 2
Interior alarm pings
once and exterior
alarm sounds 3
times
* 1
The driver’s door was closed
after the key was carried out-
side the vehicle, and the
“ENGINE START STOP”
switch was not turned OFF Tu r n t h e “ E N G I N E
START STOP” switch
OFF and close the
driver’s door again
An occupant carried the
electronic key outside the
vehicle and closed the door
while the “ENGINE START
STOP” switch was not OFF Bring the electronic key
back into the vehicle

491-2. Opening, closing and locking the doors
1
Before driving
LX570_OM_OM60L21U_(U) ■
Operation signals ●
Doors: A buzzer sounds and the emergency flashers flash to indicate that the
doors have been locked/unlocked. (Locked: Once; Unlocked: Twice)●
Windows and moon roof: A buzzer sounds to indicate that the windows and
moon roof are opening.■
Operating conditions
The wireless remote control will not operate when the “ENGINE START STOP”
switch is in any position other than OFF. ■
Door lock buzzer
If a door is not fully closed, a buzzer soun ds continuously for 5 seconds if an attempt
to lock the door is made. Fully close the do or to stop the buzzer, and lock the vehi-
cle once more. ■
Power back door operation
The power back door can be opened while the vehicle is locked. (one motion) ■
Alarm
Using the wireless remote control to lock the door will set the alarm system. ■
Electronic key battery depletion
 P. 4 1■
Security feature
 P. 4 3■
If the wireless remote control does not operate properly ●
Locking and unlocking the doors: Use the mechanical key. (  P. 8 6 7 )●
Starting the engine:  P. 8 6 8■
When the electronic key battery is fully depleted
 P. 7 8 0■
Conditions affecting operation
 P. 3 9■
Customization
Settings (e.g. unlocking function) can be changed.
(Customizable features  P. 9 0 6 )

521-2. Opening, closing and locking the doors
LX570_OM_OM60L21U_(U) Locking the driver’s door from the outside without a key
Move the inside lock button to the lock position.
Close the door.
The door cannot be locked if the “ENGINE START STOP” switch is in
ACCESSORY or IGNITION ON mode, or the electronic key is left
inside the vehicle. Depending on the position of the electronic key, the key may not be
detected correctly and the door may be locked.
Rear door child-protector lock
The door cannot be opened from
inside the vehicle when the locks
are set.
Unlock
Lock These locks can be set to prevent
children from opening the rear
doors. Push down on each rear
door switch to lock both rear
doors.STEP 1
STEP 2

531-2. Opening, closing and locking the doors
1
Before driving
LX570_OM_OM60L21U_(U) Automatic door locking and unlocking systems
The following functions can be set or canceled:
■ Setting and canceling the functions
To switch between setting and canceling, follow the procedure below:
Close all the doors and turn the “ENGINE START STOP” switch
to IGNITION ON mode. (Perform step 2 within 20 seconds.)
Shift the shift lever to “P” or “N”,
and press and hold the driver’s
door lock switch ( or )
for approximately 5 seconds then
release. The shift lever and switch positions
corresponding to the desired func-
tion to be set are shown as follows.
Use the same procedure to cancel
the function.Function Operation
Shift position linked door
locking function Shifting the shift lever out of “P” locks all doors.
Shift position linked door
unlocking function Shifting the shift lever to “P” unlocks all doors.
Speed linked door locking
function All doors are locked when the vehicle speed is
approximately 12 mph (20 km/h) or higher.
Driver’s door linked door
unlocking function All doors are unlocked when the driver’s door is
opened within 45 seconds after turning the
“ENGINE START STOP” switch OFF.STEP 1
STEP 2

591-2. Opening, closing and locking the doors
1
Before driving
LX570_OM_OM60L21U_(U) ■
The power back door can be opened/closed when
The back door can be opened automati cally when the power back door main
switch is on, and the following conditions are met. ●
The power back door is unlock ed (except closing operation)●
The lower back door is clos ed (closing operation only)●
To open the power back door when the “ENGINE START STOP” switch is in
IGNITION ON mode, the power back door is unlocked, the vehicle speed
must be lower than 1 mph (3 km/h) and the shift lever must be in “P”.■
If the back door opener is inoperative
The back door can be op erated from the inside.
Remove the cover on the back door trim.
Use a cloth to prevent scratches.
Push the lever for the back door motor, open
the back door.STEP 1
STEP 2

641-2. Opening, closing and locking the doors
LX570_OM_OM60L21U_(U) CAUTION■
Power back door
Observe the following precautions when operating the power back door.
Failure to do so may cause death or serious injury. ●
Check the safety of the surrounding area to make sure there are no obstacles or
anything that could cause any of your belongings to get caught. ●
If anyone is in the vicinity, make sure th ey are safe and let them know that the back
door is about to open or close. ●
If the power back door system is turned off with the main switch while the back
door is operating automatically, the automatic operation is stopped. The back
door then has to be operated manually. Take extra care when on an incline, as the
back door may open or close unexpectedly. ●
If the operating conditions of the power back door are no longer met, a buzzer
may sound and the back door may stop opening or closing. The back door then
has to be operated manually. Take extra ca re when on an incline, as the back door
may open or close abruptly. ●
On an incline, the back door may suddenl y shut after it opens. Make sure the
back door is fully open and secure. ●
In the following situations, the power b ack door may detect an abnormality and
automatic operation may be stopped. In this case, the back door has to be oper-
ated manually. Take extra care when on an incline, as the back door may open or
close abruptly.
• When the back door contacts an obstacle
• When the battery voltage suddenly drops, such as when the “ENGINE
START STOP” switch is turned to the IGNITION ON mode or the engine is
started during automatic operation●
If a bicycle carrier or similar heavy object is attached to the back door, the power
back door may not operate, causing itself to malfunction, or the back door may
suddenly shut again after being opened, causing someone’s hands, head or neck
to be caught and injured. When installing an accessory part to the back door,
using a genuine Lexus part is recommended.●
In cases such as when replacing tires, ma ke sure to turn off the power back door
main switch. Failure to do so may cause the back door to operate unintentionally
if the power back door switch is accidentally touched, resulting in hands and fin-
gers being caught and injured.

681-3. Adjustable components (s eats, mirrors, steering wheel)
LX570_OM_OM60L21U_(U) Power easy access system
When the driver enters and exits the ve hicle, the driver ’s seat and steer-
ing wheel will automatically perform the following operations:
Exiting the vehicle: When all of the
following actions have been per-
formed, the steering wheel will
move up and back to the point far-
thest away from the driver and the
seat will move backward (auto
away function): • The shift lever has been shifted to P
• The “ENGINE START STOP”
switch has been turned off
• The driver seat belt has been
unfastened
Entering the vehi cle: When either
of the following actions has been
performed, the steering wheel will
move toward the driver and seat
will move forward (auto return
function): • The “ENGINE START STOP”
switch has been turned to ACCES-
SORY mode
• The driver seat belt has been fas-
tened

791-3. Adjustable components (s eats, mirrors, steering wheel)
1
Before driving
LX570_OM_OM60L21U_(U) ■
Alarms and indicators
The following table describes circumstances and correction procedures when only
alarms are sound.
Indicator light and
buzzer Situation Correction procedure
Buzzer sounds for
10 seconds Indicator
light on
* Shift lever is not in the
“P” position with the
“ENGINE START
STOP” switch in IGNI-
TION ON mode.
Stop the switch opera-
tion during the auto-
matic third seat is in
motion. Move the shift lever in
the “P” position with the
“ENGINE START
STOP” switch in IGNI-
TION ON mode.
Return the third seat
from a halfway position
to tumbling position or
the original position with
the third seat return
switch or third seat tum-
bling switch.Indicator light flashes
* The seat movement is
stopped in a half way
when the back door is
opened.
