2014 LEXUS LX570 maintenance

8074-3. Do-it-yourself maintenance
4
Maintenance and care
LX570_OM_OM60L21U_(U) ■
Condensation build-up on the inside of the lens
Temporary condensation build-up on the insi de of the headlight lens does not indi-
cate a malfunction. Contact your Lexus deal er, for more information in the following
situations: ●
Large drops of water are built up on the inside of the lens. ●
Water has built up in side the headlight.■
LED lights
The front side marker lights, parking light s, daytime running lights, front fog lights,
stop/tail lights, tail lights, rear side mark er lights, high mounte d stoplight and license
plate lights consist of a number of LEDs. If any of the LEDs burn out, take your vehi-
cle to your Lexus dealer to have the light replaced. ■
Discharge headlights
If voltage to the discharge bulbs is insufficient, the bulbs may not come on, or may
go out temporarily. The discharge bulbs will come on when normal power is
restored.

8084-3. Do-it-yourself maintenance
LX570_OM_OM60L21U_(U) CAUTION■
Replacing light bulbs ●
Turn off the headlights. Do not attempt to replace the bulb immediately after turn-
ing off the headlights.
The bulbs become very hot and may cause burns. ●
Do not touch the glass portion of the li ght bulb with bare hands. When it is
unavoidable to hold the glass portion, use and hold with a clean dry cloth to avoid
getting moisture and oils on the bulb.
Also, if the bulb is scratched or dr opped, it may blow out or crack.●
Fully install light bulbs and any parts used to secure them. Failing to do so may
result in heat damage, fire, or water en tering the headlight unit. This may damage
the headlights or cause condensation to build up on the lens. ●
While the low beam headlights are turned
on, and for a short time after they have
been turned off, metal components at the
rear of the headlight assembly will be
extremely hot.
To prevent burns, do not touch these metal
components until you are certain they have
cooled down.Metal components

8094-3. Do-it-yourself maintenance
4
Maintenance and care
LX570_OM_OM60L21U_(U) CAUTION■
Discharge headlights ●
Contact your Lexus dealer be fore replacing discharge he adlights (including light
bulbs). ●
Do not touch the high-intensity discharg e headlight’s high voltage socket when
the headlights are turned on.
An extremely high voltage of 30000 V will be discharged and could result in
serious injury or death by electric shock. ●
Do not attempt to take apart or repair the low beam discharge headlight bulbs,
connectors, power supply circuits, or related components.
Doing so could result in electric shock and serious injury or death.■
To prevent damage or fire
Make sure bulbs are fully seated and locked.

8104-3. Do-it-yourself maintenance
LX570_OM_OM60L21U_(U)

8305-2. Steps to take in an emergency
LX570_OM_OM60L21U_(U) CAUTION■
Maintenance of the tires
Each tire, including the spare (if provided ), should be checked monthly when cold
and inflated to the inflation pressure re commended by the vehicle manufacturer on
the vehicle placard or tire inflation pressu re label (tire and load information label).
(If your vehicle has tires of a different size than the size indicated on the vehicle
placard or tire inflation pressure label [t ire and load information label], you should
determine the proper tire inflation pressure for those tires.)
As an added safety feature, your vehicl e has been equipped with a tire pressure
monitoring system (TPMS-tire pressure wa rning system) that illuminates a low tire
pressure telltale (tire pressure warning light) when one or more of your tires is sig-
nificantly under-inflated. Accordingly, when the low tire pressure telltale (tire pres-
sure warning light) illuminates, you should stop and check your tires as soon as
possible, and inflate them to the proper pressure. Driving on a significantly under-
inflated tire causes the tire to overheat and can lead to tire failure. Under-inflation
also reduces fuel efficiency and tire tread life, and may affect the vehicle’s handling
and stopping ability.
Please note that the TPMS (tire pressure warning system) is not a substitute for
proper tire maintenance, and it is the driver’s responsibility to maintain correct tire
pressure, even if under-inflation has not reached the level to trigger illumination of
the TPMS low tire pressure telltale (tire pressure warning light).

8325-2. Steps to take in an emergency
LX570_OM_OM60L21U_(U) If a warning message is displayed The multi-information display shows warnings of system malfunctions,
incorrectly performed operations, or shows messages that indicate a need
for maintenance.
If a warning is shown on the instrument cluster, stay calm and perform the
following actions:
Master warning light The master warning light also
comes on or flashes in order to
indicate that a message is cur-
rently being displayed on the
multi-information display.
Multi-information display
If any of the warning lights comes on again after the following actions
have been performed, contact your Lexus dealer.

5
When trouble arises
8395-2. Steps to take in an emergency
LX570_OM_OM60L21U_(U) * : Refer to the separate “Scheduled Ma intenance Guide” or “Owner’s Manual
Supplement” for the maintenance interval applicable to your vehicle. (U.S.A. only) Indicates that all mainte-
nance according to the
driven distance on the
maintenance schedule
*
should be performed
soon. If necessary, perform
maintenance.
Comes on approximately
4500 miles (7200 km)
after the maintenance
data has been reset.
(U.S.A. only) Indicates that all mainte-
nance is required to cor-
respond to the driven
distance on the mainte-
nance schedule
* . Perform the necessary
maintenance.
Please reset the mainte-
nance data after
the maintenance is per-
formed (  P. 7 3 7 )Comes on approximately
5000 miles (8000 km)
after the maintenance
data has been reset.
(The indicator will not
work properly unless the
maintenance data has
been reset.)Wa r n i n g m e s s a g e Details Correction procedure

Vehicle specifications
6
879
LX570_OM_OM60L21U_(U) 6-1. Specifications
Maintenance data
(fuel, oil level, etc.) ............. 880
Fuel information ...................... 891
Tire information...................... 895
6-2. Customization
Customizable features ........ 906
6-3. Initialization
Items to initialize ..................... 917
